4 Communication and Control 4.3.7 File Name Codes for Downloading 4.3 CAN Bus Student Guide SIPLACE D-Series (FSE) 67 4.3.6.1 4 . 3 . 6 . 1 C A N I / O M o d u le - I n p u t s a n d O u t p u t s CAN I/O Module - Inputs…
4 Communication and Control
4.3 CAN Bus 4.3.6 CAN I/O Module and Interface – Differences Between the Various D/Di-
66 Student Guide SIPLACE D-Series (FSE)
I/O module sector 4
Overview CAN I/O module
Legend
DIP Switch on the Main- and Sub Distributor
The switches on the CAN-E/A-Moduls are used to set he correct settings for the various machine types.
These setting are different from machine type to machine type
X1 CAN interface X2 Analog interface, bootstrap loader interface
X3, X4, X5 Digital inputs 24V X6 Power supply 5V
X7, X8 Digital outputs 24V X9 Power supply 24V
RS232 Analog interface, bootstrap loader
interface
S Main dis-
tributor
sector 2
Subdis-
tributor
sector 4
Comments
1O
N
ON Gateway (activate)
2OFF OFF ON: Slio emulation, OFF: CAN I/O module
3OFF OFF Transmission rate sub CAN bus for location: D1/D1i/D2/D2i: ON
(1 Mbit/s), D4/D4i: OFF (500 Kbit/s)
4O
N
OFF ON: Location sector 2, OFF: Location sector 4 (D1/D1i/D2/D2i:
OFF)
5OFF OFF Not in use
6OFF OFF ON: 1-Wire MA, OFF: 1-Wire PC
7OFF OFF Not in use
8OFF OFF Terminating resistor OFF (not used) (D1/D1i/D2/D2i: ON)
4 Communication and Control
4.3.7 File Name Codes for Downloading 4.3 CAN Bus
Student Guide SIPLACE D-Series (FSE) 67
4.3.6.1
4.3.6.1 CAN I/O Module - Inputs and Outputs
CAN I/O Module - Inputs and Outputs
4.3.7
4.3.7 File Name Codes for Downloading
File Name Codes for Downloading
The mentioned subassemblies need to be loaded with software. For details refer to SITEST.
File name codes for downloading
File name codes for downloading
NOTICE
Cause of Hazard
For the assignment of inputs and outputs on D/Di-series machines, refer to the applicable circuit
diagrams or respective texts in the SITEST I/O menu.
File name Firmware ver-
sion in SIT-
EST
Meaning of bold letters in file names
A0100208.bh
x
0.1.02.08 Machine part here 'A' general for all axis controllers
A0100208.bh
x
1 means axis controller A 362 (for S20-> HS60)
3 means axis controller A 363 (for HF series)
4 means axis controller A 364 (for D/Di and X series)
A0100208.bh
x
These "target
numbers" are
not present for
DL with SIT-
EST
0 means BIOS
A0110308.bh
x
1 means application 1
A01202DE.b
hx
2 means application 2 for VC controller of axis controller
A01202DE.b
hx
02DE means firmware version
A01202DE.b
hx
bhx is not a
ZIP file!
bhx or hex is the file name extension
File name Other descrip-
tion
HW components as letters
HW version details
B0100201.he
x
Auto down-
load if re-
quired
B means communication unit on changeover table.
B01xxxxx.he
x
SIPLACE changeover table on HM/HS/D4/D4i machine
(500Kbit/s)
B02xxxxx.he
x
SIPLACE changeover table on HF/ D1/2 / D1i/2i machine (1Mbit/
s)
B04xxxxx.he
x
X changeover table on X machine
C0100201.he
x
* C means star axis C&P 20
D03200DE.b
hx
D means D-axes C&P12/6
E0100200.bh
x
E means I/O assembly controller
4 Communication and Control
4.3 CAN Bus 4.3.7 File Name Codes for Downloading
68 Student Guide SIPLACE D-Series (FSE)
E01xxxxx.bh
x
I/O assemblies HF/X/D3
E02xxxxx.bh
x
I/O assemblies D4/D4i/D2/D2i/D1/D1i
F0100200.bh
x
F means axis controller FREE axis
G0100201.bh
x
G means tape cutter
G01xxxxx.bh
x
Tape cutter (01 HS-/D4/D4i machine)
G02xxxxx.bh
x
Tape cutter (02 for HF/ X/D1-D3 /D1i/D2i machine)
G03xxxxx.bh
x
Tape cutter (03 for tape cutter modules with NC connection /
downwards compatibility) (only for X machines)
H0100201.bh
x
H means head processor C&P20
I0100200.bhx I means TWIN Head (main board on segment)
I01xxxxx.bhx TWIN head on X machine
I02xxxxx.bhx TWIN segment on D1/D1i machine
J0100200.bh
x
* J means D-axes C&P20
K0300101.he
x
K means C&P12/6 head CAN controller
K01xxxxx.he
x
K02xxxxx.he
x
C&P12/6 on base. Head board S/F machine
K03xxxxx.he
x
C&P12/6 on base. Head board HS machine
K04xxxxx.he
x
C&P12/6 on modular head board HS/S/F machine
K05xxxxx.he
x
C&P12/6 on HF machines with 8 bit CAN controller
K06xxxxx.he
x
C&P12/6 on HF/X machines with 16 bit CAN controller
K07xxxxx.he
x
C&P12/6 +TWIN Head D1/D1i/D2/D2i/D4/D4i
L0300101.he
x
L: digital pressure control valve
L0200101.he
x
02 Pressure control valve with analog controller
L0300101.he
x
03 Pressure control valve with digital controller
M0200200.b
hx
M means CAN controller on MTC (02 MTC2)
P0100208.bh
x
P means axis controller Z-axis TWIN
File name Other descrip-
tion
HW components as letters
HW version details
