Alarm reset When an alarm is generated, a messa ge will appear on the monitor in the me ssage box at the bottom of the screen. An alarm icon will also appear on the icon bar at the top of the screen. Click on this icon t…
The following are some examples of alarm messages:
ALARM
DESCRIPTION
EMERGENCY STOP E-stop switch pushed (or electrical cabinet open)
CONVEYOR STOPPED The conveyor is not moving
COMMUNICATIONS FAILURES
-WITH CONTROLLER
-PORT TO CONTROLLER COULD NOT BE
OPENED
-CONTROLLER GIVES ERROR
The oven controller is not functioning /
communicating
The oven controller is not functioning /
communicating
Non specific communications error
BOARD DROPPED
An expected board did not arrive at the off load
sensor
OIL LEVEL LOW The oil level is low in the Lubrication Reservoir
COOLANT FLOW The coolant flow low or stopped. (or tank level low)
COOLANT TEMP The enhanced cool coolant temp is too high
GAS PRESSURE LOW
The gas pressure is below switch setpoint and too
low to maintain the gas atmosphere in the tunnel
CONVECTION LOW
A cell fan(s) has stopped, Inverter failure, or exhaust
sensing detects low facilities exhaust flow
EXHAUST FAILURE The facilities exhaust is below specifications
RAIL WIDTH
Rail width position is outside the acceptable
tolerance
BOARD JAM
A circuit board is under the exit sensor for a time
period that exceeds the jam length in the product file
IAS
The IAS Unit detected a temperature alarm
condition, or a High Temperature Switch has opened
SYSTEM READY TIME OUT
The countdown timer has expired and the machine
has not reached the Process Ready state
UPS BATTERY LOW
The UPS battery is low an requires charging
or replacement
Operator manual 23 August 2003
Alarm reset
When an alarm is generated, a message will appear on the monitor in the message box at the bottom of the
screen. An alarm icon will also appear on the icon bar at the top of the screen. Click on this icon to view the
alarm message dialog box. There will be a button to reset the alarm within this dialog box. The alarm condition
must be cleared before the alarm condition can be reset.
The Reset menu provides the ability to reset alarms, reset E-Stop, reset the board tracking, and reset the total
board count.
z
Reset Alarms
resets the alarm condition to all operation of the oven. This function is the same as using
the reset button in the alarm dialog box.
z
Reset E-Stop
clears the emergency stop condition after the emergency stop buttons have been set to the
run position. This function is similar to clicking on the E-Stop icon, but it does not provide the option to
restart the oven.
z
Reset Board Tracking
clears the display of boards and sets the count for boards in the tunnel to zero.
z
Reset Total Board Count
resets the total boards count number display.
alarm acknowledgement and the reset menu
Operator manual 24 August 2003
Oven status
SYSTEM SETUP
The oven enters the system setup state any time an action is performed such as calibrations, during
QUICK COOL, MANUAL RAIL WIDTH ADJUST
, and other similar functions. This occurs automatically to
temporarily disable any non-critical alarms which may be affected, and the Yellow light on the light tower
will be on.
The Oven Status Bar will display: SETUP
ALARM SHUTDOWN
When a Critical Alarm condition is detected in the oven, an alarm message will be displayed and shutdown
will occur. An alarm shutdown can occur when any parameter set for critical alarm goes over
(or under) acceptable limits.
The Color of the zone's temparature bar indicates the deviation to the setpoint. Green = OK, Blue =
too cold, Red = too Hot
The Oven Status Bar will display: SHUTDOWN: ALARM
The Event & Alarm log will display the reason for the alarm shutdown.
Status messages, and Oven Control Actions are based on the following definitions for the
Status Terms
used:
Status Terms
Status
DESCRIPTION
OFF
The oven is not running
SHUTDOWN
The oven is in the process of shutting down.
STABILIZING
The oven is trying to reach the set points of the present
recipe. See Oven Status Bar.
COUNTDOWN
The oven has stabilized and is in a "final countdown delay"
before going to "process ready".
READY
The oven is "process ready".
WARNING
A process variable is outside limits. See Alarm/Event Log
CRITICAL WARNING
A process variable is outside limits. See Alarm/Event Log
ALARM
A process variable is outside limits. See Alarm/Event Log
CRITICAL ALARM
A process variable is outside limits. See Alarm/Event Log
