A-131 A33-1 【 RX-7 】カバー ASSY-1 【 RX-7 】 Cover assy - 1 3 2 4 5 6 8 9 10 11 12 1 12 7 17 17 14 14 15 15 16 18 20 13 25 23 22 22 23 25 24 26 28 27 30 33 30 33 31 31 32 34 18 26 34 35 36 29 41 38 40 39 38 41 39 42 42 43 44 …
A-130
A32-2
【RX-7R】PC UNIT
【RX-7R】PC UNIT
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ1-458-642-11 MEMORY 4GB(TS512MLK64V3N) ﾒﾓﾘ 4GB (TS512MLK64V3N) 1
2 EZ1-474-020-11 POWER, ATX (ENSP3-450P-S20-H1V) ATX ﾃﾞﾝｹﾞﾝ (ENSP3-450P-S20-H1V) 1
3 EZ2-149-018-01 BRACKET HOLDING (SFA-101) ﾎｼﾞ ｶﾅｸﾞ (SFA-101) 1
4 EZ1-756-676-11 BATTERY (BS10A-H24/2.0L) ﾊﾞﾂﾃﾘ (BS10A-H24/2.0L) 1
5 EZ1-969-103-11 HARNESS (CAN1 2-CONV) ﾊ-ﾈｽ (CAN1 2-CONV) 1
6 EZ1-805-664-11 INDICATOR LIGHT, LED (UP06-67G
LED ﾋﾖｳｼﾞﾄｳ (UP06-67G)
1
7 EZ1-805-664-21 NDICATOR LIGHT, LED (UP06-67R LED ﾋﾖｳｼﾞﾄｳ (UP06-67R) 1
8 401-96521 DISK ASSY (P) DISK ASSY (P) 1
9 401-91456 MOTHER BOARD(RUBY-PB6511) ﾏｻﾞｰ ﾎﾞｰﾄﾞ(RUBY-PB6511) 1
10 EZ6-720-331-01 IC CM8062301044204S-R05Y IC CM8062301044204S-R05Y 1
11 EZ2-149-019-01 BRACKET, CABLE LOCK (KT01S-KTN ｹ-ﾌﾞﾙ ﾛﾂｸ ｶﾅｸﾞ (KT01S-KTN6) 1
12 EZ3-659-757-02 SPACER (4X8.5)
ｽﾍﾟ-ｻ- 4X8.5
4
13 EZ4-453-747-02 PANEL, PC UNIT (MAIN) PC ﾕﾆﾂﾄ ﾒｲﾝ ﾊﾟﾈﾙ 1 Ver.2
14 EZ4-453-748-01 BRACKET, PCI PC BOARD FIXED PCI ｷﾊﾞﾝ ｺﾃｲ ﾌﾞﾗｹﾂﾄ 1 Ver.2
15 EZA-192-221-6A (M) MC3 COMPL (M) MC3 COMPL 1
16 EZ4-453-750-02 BRACKET, PC UNIT (LOWER SIDE) PC ﾕﾆﾂﾄ ｼﾀｶﾞﾜ ﾌﾞﾗｹﾂﾄ 1
17 EZ4-529-919-01 BRACKET HDD SIDE HDD ｿｸﾒﾝ ﾌﾞﾗｹﾂﾄ 2
18 EZ4-453-752-03 PANEL (PC) FRONT COVER
ｼﾖｳﾒﾝ ﾊﾟﾈﾙ (PC)
1
19 EZ4-453-753-01 BRACKET, HDD FITTING HDD ﾄﾘﾂｹ ﾌﾞﾗｹﾂﾄ 1
20 EZ1-837-828-11 CABLE PC UNIT MC3 SERIAL PC ﾕﾆﾂﾄ MC3 ｼﾘｱﾙ ｹ-ﾌ 1
21 EZ4-453-755-01 BRACKET, PC BOARD RETAINER ｷﾊﾞﾝ ｵｻｴ ﾌﾞﾗｹﾂﾄ 1 Ver.2
22 EZ4-462-937-01 RUBBER (VB-1209-80BK) ﾎﾞｳｼﾝ ｺﾞﾑ (VB-1209-80BK) 4
23 EZ4-613-955-01 SCREW (+) B 6-32 ﾕﾆﾌｱｲ ｺﾈｼﾞ 6
24 EZ4-969-071-01 HOLDER (EHP-6U), EDGE
ｴﾂｼﾞ ﾎﾙﾀﾞ- (EHP-6U)
4
25 EZ7-682-948-01 SCREW +PSW 3X8 +PSW 3X8 43
26 EZ7-682-961-01 SCREW +PSW 4X8 +PSW 4X8 24
27 EZ7-682-965-01 SCREW +PSW 4X16 +PSW 4X16 4
28 EZ1-855-270-11 CPU COOLER CPU ｸ-ﾗ- (RR-V211-15FK-R2) 4
29 EZ7-682-973-11 SCREW +PSW 5X10 +PSW 5X10 5
30 EZ7-684-023-04 N 3 TYPE 2
N 3 TYPE 2
2
31 EZ4-453-764-11 RAIL, DIN(NS35/7, 5PERF40MM/Z) DIN ﾚ-ﾙ (NS35/7, 5PERF40MM/Z) 1
32 HB-0015800-00 RELAY ﾘﾚ- 1
33 EZ1-895-351-11 FRAME GRABBER ﾌﾚ-ﾑ ｸﾞﾗﾊﾞ- (ASP-8514X-S 1
34 EZ1-755-538-11 RELAY (RU4S-D-D24) ﾘﾚ- (RU4S-D-D24) 1
35 EZ1-755-539-11 SOCKET, RELAY (SY4S-05B) ﾘﾚ- ｿｹﾂﾄ (SY4S-05B) 1
36 EZ1-857-162-13 BOARD ASSY CAN IO (CART)
CAN IO ﾎﾞｰﾄﾞ ｸﾐ (CART)
2
37 EZ4-453-736-02 PANEL (PC), SIDE ｿｸﾒﾝ ﾊﾟﾈﾙ (PC) 1 Ver.2
38 EZ7-682-167-01 SCREW +P 4X25 +P 4X25 2
39 401-58284 MOTION CONTROLER ﾓｰｼｮﾝｺﾝﾄﾛｰﾗｰ 1
40 EZ1-458-642-11 MEMORY 4GB(TS512MLK64V3N) ﾒﾓﾘ 4GB (TS512MLK64V3N) 1
41 EZ1-474-020-11 POWER, ATX (ENSP3-450P-S20-H1V) ATX ﾃﾞﾝｹﾞﾝ (ENSP3-450P-S20-H1V) 1
42 EZ2-149-018-01 BRACKET HOLDING (SFA-101)
ﾎｼﾞ ｶﾅｸﾞ (SFA-101)
1
43 EZ1-756-676-11 BATTERY (BS10A-H24/2.0L) ﾊﾞﾂﾃﾘ (BS10A-H24/2.0L) 1
44 EZ1-969-103-11 HARNESS (CAN1 2-CONV) ﾊ-ﾈｽ (CAN1 2-CONV) 1
45 EZ1-805-664-11 INDICATOR LIGHT, LED (UP06-67G LED ﾋﾖｳｼﾞﾄｳ (UP06-67G) 1
A-131
A33-1
【RX-7】カバー ASSY-1
【RX-7】Cover assy - 1
3
2
4
5
6
8
9
10
11
12
1
12
7
17
17
14
14
15
15
16
18
20
13
25
23
22
22
23
25
24
26
28
27
30
33
30
33
31
31
32
34
18
26
34
35
36
29
41
38
40
39
38
41
39
42
42
43
44
37
46
47
48
45
51
52
53
54
55
55
53
54
52
60
61
61
63
62
59
65
64
66
68
69
70
71
72
73
74
75
76
78
A
A
77
19
49
50
51
B
B
21
56
57
C
C
D
D
58
67
83
84
87
85 90
86
79
80
81
82
88
89
91
104
105
95
92
93
106
106
103
102
105
101
99
99
99
97
96
94
98
100
95
E
E
101
101
104
A-132
A33-1
【RX-7】カバー ASSY-1
【RX-7】Cover assy - 1
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 401-43839 UPPER_SIDE_COVER_L_ASM ｱｯﾊﾟｰ_ｻｲﾄﾞｶﾊﾞｰ_L_ｸﾐ 1
2 401-43377 COVER_SUL ｶﾊﾞｰ_SUL (1)
3 SL-6051092-TN SCREW M5 L=10 座金付き六角穴ﾎﾞﾙﾄ M5 L=10 (4)
4 400-81751 B_COVER_SCREW B ｶﾊﾞｰｽｸﾘｭｳ (5)
5 401-43381 COVER_SCL ｶﾊﾞｰ_SCL (1)
6 400-81751 B_COVER_SCREW B ｶﾊﾞｰｽｸﾘｭｳ (10)
7 401-43840 UPPER_SIDE_COVER_R_ASM ｱｯﾊﾟｰ_ｻｲﾄﾞｶﾊﾞｰ_R_ｸﾐ 1
8 401-43378 COVER_SUR ｶﾊﾞｰ_SUR (1)
9 SL-6051092-TN SCREW M5 L=10 座金付き六角穴ﾎﾞﾙﾄ M5 L=10 (4)
10 400-81751 B_COVER_SCREW B ｶﾊﾞｰｽｸﾘｭｳ (5)
11 401-43382 COVER_SCR ｶﾊﾞｰ_SCR (1)
12 400-81751 B_COVER_SCREW B ｶﾊﾞｰｽｸﾘｭｳ (10)
13 401-43841 UPPER_FRONT_COVER_L_ASM ｱｯﾊﾟｰ_ﾌﾛﾝﾄｶﾊﾞｰ_L_ｸﾐ 1
14 401-43394 FRONT_COVER_BRACKET_A ﾌﾛﾝﾄ_ｶﾊﾞｰ_ﾌﾞﾗｹｯﾄ_A (2)
15 SL-6041092-TN SCREW M4 L=10 座金付き六角穴ﾎﾞﾙﾄ M4 L=10 (4)
16 401-43392 COVER_FUL ｶﾊﾞｰ FUL (1)
17 NM-3060810-SF FLANGE NUT M6 ﾌﾗﾝｼﾞ付きﾅｯﾄ M6 (2)
18 400-81751 B_COVER_SCREW B ｶﾊﾞｰｽｸﾘｭｳ (2)
19 401-43398 COVER_FUL_LID ｶﾊﾞｰ FUL_ﾘｯﾄﾞ (1)
20 400-81751 B_COVER_SCREW B ｶﾊﾞｰｽｸﾘｭｳ (5)
21 401-43842 UPPER_FRONT_COVER_R_ASM ｱｯﾊﾟｰ_ﾌﾛﾝﾄｶﾊﾞｰ_R_ｸﾐ 1
22 401-43394 FRONT_COVER_BRACKET_A ﾌﾛﾝﾄ_ｶﾊﾞｰ_ﾌﾞﾗｹｯﾄ_A (2)
23 SL-6041092-TN SCREW M4 L=10 座金付き六角穴ﾎﾞﾙﾄ M4 L=10 (4)
24 401-43393 COVER_FUR ｶﾊﾞｰ FUR (1)
25 NM-3060810-SF FLANGE NUT M6 ﾌﾗﾝｼﾞ付きﾅｯﾄ M6 (2)
26 400-81751 B_COVER_SCREW B ｶﾊﾞｰｽｸﾘｭｳ (2)
27 401-43399 COVER_FUR_LID ｶﾊﾞｰ FUR_ﾘｯﾄﾞ (1)
28 400-81751 B_COVER_SCREW B ｶﾊﾞｰｽｸﾘｭｳ (5)
29 401-43843 UPPER_REAR_COVER_L_ASM ｱｯﾊﾟｰ_ﾘｱｶﾊﾞｰ_L_ｸﾐ 1
30 401-43405 REAR_COVER_BRACKET_A ﾘｱ_ｶﾊﾞｰ_ﾌﾞﾗｹｯﾄ_A (2)
31 SL-6041092-TN SCREW M4 L=10 座金付き六角穴ﾎﾞﾙﾄ M4 L=10 (4)
32 401-43403 COVER_RUL ｶﾊﾞｰ RUL (1)
33 NM-3060810-SF FLANGE NUT M6 ﾌﾗﾝｼﾞ付きﾅｯﾄ M6 (2)
34 SL-6040892-TN SCREW M4 L=8 座金付き六角穴ﾎﾞﾙﾄ M4 L=8 (2)
35 401-44545 MAGNET_LATCH ﾏｸﾞﾈｯﾄ_ﾗｯﾁ (1)
36 SL-6030842-TN SCREW M3 L=8 座金付き六角穴ﾎﾞﾙﾄ M3 L=8 (4)
37 401-43844 UPPER_REAR_COVER_R_ASM ｱｯﾊﾟｰ_ﾘｱｶﾊﾞｰ_R_ｸﾐ 1
38 401-43405 REAR_COVER_BRACKET_A ﾘｱ_ｶﾊﾞｰ_ﾌﾞﾗｹｯﾄ_A (2)
39 SL-6041092-TN SCREW M4 L=10 座金付き六角穴ﾎﾞﾙﾄ M4 L=10 (4)
40 401-43404 COVER_RUR ｶﾊﾞｰ RUR (1)
41 NM-3060810-SF FLANGE NUT M6 ﾌﾗﾝｼﾞ付きﾅｯﾄ M6 (2)
42 SL-6040892-TN SCREW M4 L=8 座金付き六角穴ﾎﾞﾙﾄ M4 L=8 (2)
43 401-44545 MAGNET_LATCH ﾏｸﾞﾈｯﾄ_ﾗｯﾁ (1)
44 SL-6030842-TN SCREW M3 L=8 座金付き六角穴ﾎﾞﾙﾄ M3 L=8 (4)
45 401-43845 UPPER_REAR_COVER_C_ASM ｱｯﾊﾟｰ_ﾘｱｶﾊﾞｰ_C_ｸﾐ 1
46 401-43406 COVER_RUC ｶﾊﾞｰ RUC (1)
47 SL-6040892-TN SCREW M4 L=8 座金付き六角穴ﾎﾞﾙﾄ M4 L=8 (4)
48 400-69189 EMBEDDED PULLS ｳﾒｺﾐﾄｯﾃ (1)
49 401-43846 REAR_ACCESS_COVER_ASM ﾘｱｱｸｾｽｶﾊﾞｰ_ｸﾐ 1
50 401-43409 REAR_ACCESS_COVER ﾘｱｱｸｾｽｶﾊﾞｰ (1)
51 401-43363 SMALL_WINDOW_PLATE ｺﾏﾄﾞ_ﾌﾟﾚｰﾄ (2)
52 NM-3040520-SF FLANGE NUT M4 ﾌﾗﾝｼﾞ付きﾅｯﾄ M4 (8)
53 L128E-421-000 SAFETY COVER HINGE ｾｰﾌﾃｨ ｶﾊﾞｰ ﾋﾝｼﾞ (2)
54 SL-3061232-TN SCREW M6 L=12 座金付きﾎﾞﾀﾝﾎﾞﾙﾄ M6 L=12 (8)
