A-114
A29-1
【RX-7】搬送部 バックアップユニット
【RX-7】Backup unit
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ4-454-399-01 BASE, BACK UP ﾊﾞﾂｸ ｱﾂﾌﾟ ﾍﾞ-ｽ 1
2 EZ4-454-393-01 SUPPORT, FIXED ｺﾃｲ ｻﾎﾟ-ﾄ 1
3 EZ4-454-392-01 SUPPORT, SUPPORT ｼｼﾞ ｻﾎﾟ-ﾄ 1
4 EZ4-454-390-01 PLATE (L), LM LM ﾌﾟﾚ-ﾄ (L) 1
5 EZ4-454-390-11 PLATE (R), LM LM ﾌﾟﾚ-ﾄ (R) 1
6 EZ4-454-528-01 GUIDE (LWL15C2R280BCSH/MN) ｶﾞｲﾄﾞ (LWL15C2R280BCSH/MN) 2
7 EZ4-461-217-01 BEARING (7900A5TYNSULP4) ﾍﾞｱﾘﾝｸﾞ (7900A5TYNSULP4) 2
8 EZ4-454-396-01 RETAINER, BEARING ﾍﾞｱﾘﾝｸﾞ ｵｻｴ 1
9 EZ4-454-402-01 PLATE (L), SLIDE ｽﾗｲﾄﾞ ﾌﾟﾚ-ﾄ (L) 1
10 EZ4-454-402-11 PLATE (R), SLIDE ｽﾗｲﾄﾞ ﾌﾟﾚ-ﾄ (R) 1
11 EZ4-454-397-01 BRACKET, MOTOR ﾓ-ﾀ ﾌﾞﾗｹﾂﾄ 1
12 EZ1-492-224-12 MOTOR ASSY (BACK UP) ﾓ-ﾀ ASSY (BACK UP) 1
13 EZ4-454-391-01 LINK, SLIDE ｽﾗｲﾄﾞ ﾘﾝｸ 1
14 EZ4-454-395-01 SUPPORT, NUT ﾅﾂﾄ ｻﾎﾟ-ﾄ 1
15 EZ4-454-529-01 COLLAR (GY/W-C10) ｶﾗ- (GY/W-C10) 1
16 EZ4-453-821-01 SCREW (GY1210AS-HULR-0221) ﾎﾞ-ﾙﾈｼﾞ(GY1210AS-HULR-0221X0*) 1
17 EZ2-022-823-01 BEARING, MINIATURE (608ZZMC3E) ﾐﾆﾁﾕｱ ﾍﾞｱﾘﾝｸﾞ (608ZZMC3E) 1
18 EZ4-454-524-01 COUPLING (SFC-020DA2-5B-8B) ｶﾂﾌﾟﾘﾝｸﾞ (SFC-020DA2-5B-8B) 1
19 EZ4-454-400-01 BASE (L), SLIDE ｽﾗｲﾄﾞ ﾍﾞ-ｽ (L) 2
20 EZ4-454-400-11 BASE (R), SLIDE ｽﾗｲﾄﾞ ﾍﾞ-ｽ (R) 2
21 EZ4-454-527-01 GUIDE (LWL15C1R81BCST1HS1/MN) ｶﾞｲﾄﾞ (LWL15C1R81BCST1HS1/MN) 4
22 EZ4-454-401-01 SLIDE (L), CAM ｶﾑ ｽﾗｲﾄﾞ (L) 2
23 EZ4-454-525-01 FOLLOWER (CF6BR), CAM ｶﾑ ﾌｵﾛｱ (CF6BR) 4
24 EZ4-454-401-11 SLIDE (R), CAM ｶﾑ ｽﾗｲﾄﾞ (R) 2
25 EZ1-492-223-11 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾞﾂｸ ｱﾂﾌﾟ ﾘﾐﾂﾄ 1) 1
26 EZ1-492-222-11 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾞﾂｸ ｱﾂﾌﾟ ｹﾞﾝﾃﾝ 1) 1
27 EZ4-454-394-01 DOG (4R), SENSOR ｾﾝｻ- ﾄﾞｸﾞ (4R) 1
28 EZ4-454-398-01 PLATE, TOP ﾄﾂﾌﾟ ﾌﾟﾚ-ﾄ 1
29 EZ4-454-389-01 PLATE (M), BACK UP ﾊﾞﾂｸ ｱﾂﾌﾟ ﾌﾟﾚ-ﾄ M 1
30 EZ4-701-529-01 TIE MOUNT (MB1) ﾀｲﾏｳﾝﾄ (MB1) 3
31 EZ4-431-981-31 PIN (DIA. 4), PARALLEL ﾍｲｺｳ ﾋﾟﾝ ﾌｱｲ 4 ｼﾘ-ｽﾞ 22
32 EZ4-454-526-01 NUT (LNM10X1), LOCK ﾛﾂｸ ﾅﾂﾄ (LNM10X1) 1
33 EZ7-624-198-01 STOP RING 8, TYPE C C ｶﾞﾀ ﾄﾒﾜ 8 (ｼﾞｸﾖｳ) 1
34 EZ7-682-247-09 SCREW +K 3X6 SCREW +K 3X6 3
35 EZ2-584-960-01 BOLT (CBSST4-8) ﾃｲﾄｳ ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ (CBSST4-8) 12
36 EZ7-683-403-04 BOLT,HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 36
37 EZ7-683-404-04 BOLT,HEXAGON SOCKET 3X8 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X8 26
38 EZ7-683-405-04 BOLT,HEXAGON SOCKET 3X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X10 12
39 EZ7-683-419-04 BOLT HEXAGON SOCKET 4X8 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X8 8
40 EZ7-683-420-04 BOLT,HEXAGON SOCKET 4X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X10 12
41 EZ7-683-440-04 BOLT,HEXAGON SOCKET 5X20 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 5X20 6
42 EZ4-456-321-01 BLOCK, BACK UP ﾊﾞﾂｸ ｱﾂﾌﾟ ﾌﾞﾛﾂｸ 1
43 EZ4-456-322-01 BACK UP, SHAFT ｼﾔﾌﾄ ﾊﾞﾂｸ ｱﾂﾌﾟ 5
44 EZ4-456-323-01 BACK UP, PLATE ﾌﾟﾚ-ﾄ ﾊﾞﾂｸ ｱﾂﾌﾟ 1
45 EZ7-683-420-04 BOLT,HEXAGON SOCKET 4X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X10 10
46 EZ4-456-320-01 MAGNET (HXN6-6) ﾏｸﾞﾈﾂﾄ (HXN6-6) 6
47 EZ4-718-767-01 SET-SCREW (M4X5 SUS), HEAD ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ (M4X5 SUS) 6
48 EZ2-664-098-01 SPONGE (BLUE), BACK UP ﾊﾞﾂｸｱﾂﾌﾟ ｽﾎﾟﾝｼﾞ (ｱｵ) 1
49 EZ4-456-347-01 BACK UP PIN ﾌﾞﾛﾂｸ ﾊﾞﾂｸ ｱﾂﾌﾟ ﾋﾟﾝ 1
50 EZ4-722-700-01 PIN, BACK UP ﾊﾞﾂｸｱﾂﾌﾟ ﾋﾟﾝ 2
A-115
A29-1
【RX-7】搬送部 バックアップユニット
【RX-7】Backup unit
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
51 EZ7-624-104-04 STOP RING 2.0, TYPE -E E ｶﾞﾀ ﾄﾒﾜ 2.0 2
52 EZ4-456-320-01 MAGNET (HXN6-6) ﾏｸﾞﾈﾂﾄ (HXN6-6) 4
53 EZ4-718-767-01 SET-SCREW (M4X5 SUS), HEAD ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ (M4X5 SUS) 4
