A-187 A48 【共通】 IFS-NX ユニット -2 【 COMMON 】 IFS-NX unit - 2 ｲﾗｽﾄ番号 Ref.No. 品番 Part Number Description 品名 個数 Q'ty 備考 Remarks 109 401-58881 SHOOT _NI ｼｭｰﾄ_Ni (1) 1 10 401-51345 SHOOT_SUPPORT ｼｭｰﾄｻﾎﾟｰﾄ (1) 1 1 1 SM-303055…

100%1 / 296
A-186
A48
【共通】IFS-NX ユニット-2
【COMMON】IFS-NX unit - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
55 401-43523 DUMMY_ANTENNA ﾀﾞﾐｰｱﾝﾃﾅ (1)
56 SM-6030602-TN SCREW M3X6 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3X6 (3)
57 HX-0029400-00 FIXED BASE ｺﾃｲ ﾍﾞｰｽ (2)
58 HX-0034400-00 FIXED BASE ｿｸｾﾝﾊﾟｰﾂ (2)
59 SM-4040601-SC SCREW M4X0.7 L=6 ﾅﾍﾞｺﾈｼﾞ M4X0.7 L=6 (4)
60 PJ-3010605-03 HALF UNION ﾊｰﾌ ﾕﾆｵﾝ (1)
61 PH-0300062-C0 PARALLEL PIN TYPE B 3X6 平行ﾋﾟﾝ B 種 3X6 (4)
62 SM-6041402-TN SCREW M4X0.7 L=14 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=14 (2)
63 SM-6030502-TN SCREW M3 L=5 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3 L=5 (4)
64 ST-4020521-SN TAPPING SCREW D=2 L=5 ﾀｯﾋﾟﾝねじ D=2 L=5 (8)
65 SL-4030881-SC SCREW M3 L=8 座金付きなべ小ねじ M3 L=8 (12)
66 401-43365 ETF_POSITION_LABEL ETF_ﾎﾟｼﾞｼｮﾝ_ﾗﾍﾞﾙ (2)
67 BT-0600401-EB URETHANE TUBE BLACK 6X4 ﾎﾟﾘｳﾚﾀﾝ ﾁｭｰﾌﾞ 黒 6X4 (0.4)
68 SL-4040891-SC SCREW M4X8 ｻﾞｶﾞﾈﾂｷﾅﾍﾞｺﾈｼﾞ M4 L=8 (4)
69 401-46480 TROLLEY CONTACT(T)B PCB ASM ﾄﾛﾘｰ CONTACT(T)B 基板組 (1)
70 EZ4-000-207-02 PIN (2) LOCATE ﾛｹ-ﾄ ﾋﾟﾝ (2) (2)
71 EZ4-453-564-01 PLUG TAPER SCREW ﾃ-ﾊﾟ ｽｸﾘﾕ- ﾌﾟﾗｸﾞ (1)
72 EZ4-455-727-01 TABLE PLUG ﾃ-ﾌﾞﾙ ﾌﾟﾗｸﾞ (1)
73 EZ4-463-630-01 TABLE SPACER (R B) ﾃ-ﾌﾞﾙ ｽﾍﾟ-ｻ- R B (1)
74 EZ4-705-470-11 RING O (CO 0006A P9) O ﾘﾝｸﾞ (CO 0006A P9) (2)
75 EZ4-477-023-01 CONNECTOR BRACKET L ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ L (MOLD) (1)
76 EZ4-478-177-01 CLAMP CONNECTOR HARNESS ｺﾈｸﾀ- ﾊ-ﾈｽ ｸﾗﾝﾊﾟｰ (MOLD) (2)
77 EZ4-477-022-01 CONNECTOR BRACKET R ｺﾈｸﾀｰ ﾌﾞﾗｹｯﾄ R (MOLD) (1)
78 401-43635 TABLE_BASE_L_ASSY ﾃｰﾌﾞﾙﾍﾞｰｽ L ｱｯｼｰ 1
79 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (2)
80 401-43525 SLIDE_BLOCK_L ｽﾗｲﾄﾞﾌﾞﾛｯｸ L (1)
81 SM-6051602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (4)
82 SM-6051002-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (2)
83 401-43527 SP_SHAFT ｽﾌﾟﾘﾝｸﾞｼｬﾌﾄ (1)
84 SL-6041292-TN SCREW M4 L=12 座金付き六角穴ﾎﾞﾙﾄ M4 L=12 (1)
85 401-43524 TABLE_BASE_L ﾃｰﾌﾞﾙﾍﾞｰｽ L (1)
86 401-43529 CUTTER_RAIL ｶｯﾀｰﾚｰﾙ (1)
87 EZ4-113-107-01 FOLLOWER (CF8VB) CAM ｶﾑ ﾌｵﾛｱ (CF8VB) (2)
88 EZ4-453-803-01 CUSHION CUTTER UNIT ｶﾂﾀ- ﾕﾆﾂﾄ ｸﾂｼﾖﾝ (1)
89 401-43636 TABLE_BASE_R_ASSY ﾃｰﾌﾞﾙﾍﾞｰｽ R ｱｯｼｰ 1
90 401-43529 CUTTER_RAIL ｶｯﾀｰﾚｰﾙ (1)
91 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (2)
92 401-43530 SLIDE_BLOCK_R_ ｽﾗｲﾄﾞﾌﾞﾛｯｸ R (1)
93 SM-6051602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (4)
94 SM-6051002-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (2)
95 401-43532 ACT_BRACKET ACT ﾌﾞﾗｹｯﾄ (1)
96 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (5)
97 401-43527 SP_SHAFT ｽﾌﾟﾘﾝｸﾞｼｬﾌﾄ (1)
98 SL-6041292-TN SCREW M4 L=12 座金付き六角穴ﾎﾞﾙﾄ M4 L=12 (1)
99 HX-0015000-00 CABLE CLAMP ｹｰﾌﾞﾙｸﾘｯﾌﾟ (1)
100 WT-0430002-KN WASHER M4 ﾊﾂｷｻﾞｶﾞﾈ M4 (1)
101 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (2)
102 401-43528 TABLE_BASE_R ﾃｰﾌﾞﾙﾍﾞｰｽ R (1)
103 EZ4-149-845-01 ACTUATOR (D40A-A1) SWITCH ﾄﾞｱ ｽｲﾂﾁ ｱｸﾁﾕｴ-ﾀ (D40A-A1) (1)
104 EZ4-113-107-01 FOLLOWER (CF8VB) CAM ｶﾑ ﾌｵﾛｱ (CF8VB) (2)
105 EZ4-453-803-01 CUSHION CUTTER UNIT ｶﾂﾀ- ﾕﾆﾂﾄ ｸﾂｼﾖﾝ (1)
106 SM-6051602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ 3
107 SM-6051602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ 3
108 401-43638 SHOOT_ASSY ｼｭｰﾄｱｯｼｰ 1
A-187
A48
【共通】IFS-NX ユニット-2
【COMMON】IFS-NX unit - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
109 401-58881 SHOOT_NI ｼｭｰﾄ_Ni (1)
110 401-51345 SHOOT_SUPPORT ｼｭｰﾄｻﾎﾟｰﾄ (1)
111 SM-3030552-TN SCREW M3 L=5 ﾏﾙﾈｼﾞ M3 L=5 (2)
112 401-58883 TAPE_GUIDE_PLATE ﾃｰﾌﾟｶﾞｲﾄﾞﾌﾟﾚｰﾄ (1)
113 401-58885 TAPE_GUIDE_CHAIN ﾃｰﾌﾟｶﾞｲﾄﾞﾁｪｰﾝ (2)
114 SM-6020602-TN SCREW M2 L=6 ﾛｯｶｸｱﾅﾎﾞﾙﾄ M2 L=6 (4)
115 NM-6020001-SC NUT M2 ﾛﾂｶｸﾅﾂﾄ M2 1 ｼﾕ (6)
116 401-58882 TAPE_GUIDE_CHAIN_BR ﾃｰﾌﾟｶﾞｲﾄﾞﾁｪｰﾝﾌﾞﾗｹｯﾄ (1)
117 401-58884 TAPE_GUDE_FIX_PLATE ﾃｰﾌﾟｶﾞｲﾄﾞﾌｨｸｽﾌﾟﾚｰﾄ (1)
118 SL-6030692-TN SCREW M3 L=6 座金付き六角穴ボルト M3 L=6 (2)
119 NM-6030003-SC NUT M3X0.5 TYPE3 六角 ﾅｯﾄ M3X0.5 3 種 (4)
120 WP-0320501-SC WASHER M3 ﾋﾗｻﾞｶﾞﾈ M3 (4)
121 WS-0310002-KN SPRING WASHER M3 ﾊﾞﾈｻﾞｶﾞﾈ 3.1X5.9X0.7 (4)
122 SM-3040652-TN SCREW M4 L=6 ﾏﾙﾈｼﾞ M4 L=6 2
123 SM-3030552-TN SCREW M3 L=5 ﾏﾙﾈｼﾞ M3 L=5 2
124 401-43537 SUPPORT_BAR ｻﾎﾟｰﾄﾊﾞｰ 1
125 SM-3040552-TN SCREW M4 L=5 ﾏﾙﾈｼﾞ M4 L=5 2
126 401-43538 DISPOSAL_DUCT_BRACKET ﾃﾞｨｽﾎﾟｰｻﾞﾙﾀﾞｸﾄﾌﾞﾗｹｯﾄ 2
127 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 8
128 401-43539 STAND_COVER_TOP ｽﾀﾝﾄﾞｶﾊﾞｰﾄｯﾌﾟ 1
129 SM-1040801-SC SCREW M4X0.7 L=8 ｻﾗｺﾈｼﾞ M4X0.7 L=8 4
130 EZ4-453-863-01 DISPOSAL DUCT ﾊｲｷ ﾀﾞｸﾄ 1
131 401-54185 CUTTER_UNIT ｶｯﾀｰﾕﾆｯﾄ 1
A-188
A49
【共通】RF フィーダ用 一括交換台車-1
【COMMON】Replacing overall changer truck for RF feeder - 1
32
33
37
38
23
23
14
31
10
11
36
12
4
5
8
9
10
11
3
18
15
16
17
17
16
13
66
24
24
21
20
22
25
26
26
27
19
34
30
40
35
41
B
B
42
39
42
29
45
46
44
43
28
47
49
50
51
48
60
55
56 57
61
58 59
62
62
53 54
63 64
65
1 2
92
68
72
73
74
74
69
74
76
77
78
80
79
80
75
80
81
81
82
70
71
82
82
82
83
83
83
83
83
83
83
83
84
87
85
87
86
86
86
86
86
86
86
86
86
86
86
86
86
86
86
86
86
86
88
89 90
91
52
67
A
A
C
C
D
D
F
F
G
H
G
H
7
7
6
E
E
93
