A-198
A51
【共通】RF フィーダ用 一括交換台車-3
【COMMON】Replacing overall changer truck for RF feeder - 3
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
54 EZ4-453-560-01 FILTER(FSL200-66-B) INLINE ｲﾝﾗｲﾝ ﾌｲﾙﾀ(FSL200-66-B) (1)
55 SL-6030692-TN SCREW M3 L=6 座金付き六角穴ﾎﾞﾙﾄ M3 L=6 (2)
56 401-67589 SOLENOID_BR ｿﾚﾉｲﾄﾞ BR (1)
57 SM-0030601-SC SCREW M3X6 ﾄﾗｽﾈｼﾞ M3X6 (2)
58 401-68969 CUTTER SOLENOID VALVE ASM ｶｯﾀｰ ｿﾚﾉｲﾄﾞ ﾊﾞﾙﾌﾞ ｸﾐ (1)
59 EZ4-426-151-01 SILENCER(AN10-01) ｻｲﾚﾝｻ(AN10-01) (2)
60 EZ4-447-092-01 UNION (KQ2L04-01NS) ELBOW ｴﾙﾎﾞ ﾕﾆｵﾝ (KQ2L04-01NS) (2)
61 PJ-3010651-03 HALF UNION 6XPT1/8 ﾊｰﾌ ﾕﾆｵﾝ 6XPT1/8 (1)
62 SM-6030602-TN SCREW M3X6 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3X6 (2)
63 BT-0400251-EA URETHANE TUBE BLUE 4X2.5 ﾎﾟﾘｳﾚﾀﾝ ﾁｭｰﾌﾞ 青 4X2.5 (0.2)
64 BT-0600400-EC URETHANE TUBE BLUE 6X4 ﾎﾟﾘｳﾚﾀﾝ ﾁｭｰﾌﾞ 青 6X4 (0.3)
65 401-67590 COVER_CUTTER ｶﾊﾞｰｶｯﾀｰ (1)
66 SM-0040601-SC SCREW M4X0.7 L=6 ﾄﾗｽｺﾈｼﾞ M4X0.7 L=6 (4)
67 E9635-455-000 REVISION SEAL REV ﾒｲﾊﾝ (1)
A-199
A52
【共通】ISLITE (ISM/MES 連携)
【COMMON】ISLITE (ISM/MES Cooperation)
1
2
