A-17
A5-2
【RX-7R】架台 ASSY-2
【RX-7R】Base frame assy - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
51 EZ4-478-175-01 CONNECTOR BRACKET UPPER L ｺﾈｸﾀｰ ﾌﾞﾗｹｯﾄｱｯﾊﾟｰ L (MOLD) 2
52 EZ4-455-639-01 CONNECTOR BRACKET BOTTOM ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ ﾎﾞﾄﾑ 2
53 EZ4-455-640-01 CONNECTOR BRACKET SPACER ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ ｽﾍﾟ-ｻ 2
54 EZ4-478-176-01 CONNECTOR BRACKET UPPER R ｺﾈｸﾀｰ ﾌﾞﾗｹｯﾄｱｯﾊﾟｰ R (MOLD) 2
55 EZ4-463-738-01 CONNECTOR BRACKET R BOTTOM ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ R ﾎﾞﾄﾑ 2
56 EZ4-463-739-01 CONNECTOR BRACKET R SPACER ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ R ｽﾍﾟ-ｻ 2
57 EZ4-472-320-01 CONNECTOR COVER ｺﾈｸﾀ- ｶﾊﾞ- 2
58 EZ4-531-184-01 PROTECTION CUSHION (L) ﾎｺﾞ ｸﾂｼﾖﾝ (L) 2
59 EZ4-531-184-11 PROTECTION CUSHION (R) ﾎｺﾞ ｸﾂｼﾖﾝ (R) 2
60 EZ4-705-597-41 PIN (DIA. 5) PARALLEL ﾍｲｺｳ ﾋﾟﾝ (ﾌｱｲ 5) 8
61 EZ4-716-434-21 TIE INSULOCK (AB150 BLACK) ｲﾝｼﾕﾛﾂｸ ﾀｲ (AB150 ｸﾛ) 37
62 EZ4-716-434-31 TIE INSULOCK (AB200 BLACK) ｲﾝｼﾕﾛﾂｸ ﾀｲ (AB200 ｸﾛ) 13
63 EZ4-720-203-01 PIN TOOL POSITIONING ｼﾞｸﾞ ﾖｳ ｲﾁｷﾞﾒ ﾋﾟﾝ (JPDPA10-14) 1
64 EZ4-722-956-01 LABEL(SILVER) BLANK ﾌﾞﾗﾝｸ ﾗﾍﾞﾙ ｷﾞﾝ(TTC82YS-10) 4
65 EZ7-682-265-04 SCREW +K 4X16 ﾈｼﾞ +K 4X16 8
66 EZ7-683-403-04 BOLT HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 8
67 EZ7-683-420-04 BOLT HEXAGON SOCKET 4X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X10 20
68 EZ7-683-421-04 BOLT HEXAGON SOCKET 4X12 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ(C4X12) 16
69 EZ7-683-422-04 BOLT HEXAGON SOCKET 4X14 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X14 4
70 EZ7-683-425-04 BOLT HEXAGON SOCKET 4X20 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X20 4
71 EZ7-683-435-04 BOLT HEXAGON SOCKET 5X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 5X10 16
72 EZ7-684-024-04 N 4 TYPE 2 N 4 TYPE 2 24
73 EZ7-688-004-11 W 4 MIDDLE W 4 MIDDLE 32
74 EZ7-688-005-11 W 5 MIDDLE W 5 MIDDLE 12
75 401-46468 TROLLEY CONTACT(M)A PCB ASM ﾄﾛﾘｰ CONTACT(M)A 基板組 1
76 401-72762 TROLLEY CONTACT(M)A ORI PCB ASM ﾄﾛﾘｰ CONTACT(M)A ORI 基板組 1
77 401-46472 TROLLEY CONTACT(M)B PCB ASM ﾄﾛﾘｰ CONTACT(M)B 基板組 2
78 402-09890 PARTITION_PLATE 仕切り板 2
79 402-11539 TROLLEY_SW_BR_ASM 台車上昇ｽｲｯﾁﾌﾞﾗｹｯﾄ組 2
80 SM-6041602-TN SCREW M4X16 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X16 (2)
81 402-08045 SENSOR_SHAFT_F ｾﾝｻｰｼｬﾌﾄ F (1)
82 RE-0400000-K0 E-RING 4 E 形止め輪 4 (1)
83 402-08376 SHAFT_HOLDER ｼｬﾌﾄﾎﾙﾀﾞｰ (1)
84 402-08064 SENSOR_BRACKET_F ｾﾝｻｰﾌﾞﾗｹｯﾄ F (1)
85 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (2)
86 SM-6040602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (1)
A-18
A6-1
【RX-7】架台 ASSY-3
【RX-7】Base frame assy - 3
12
24
24
26
8
28
23
24
38
8
26
36
35
26
37
37
18
3
27
20
28
7
17
21
27
16
16
23
15
26
25
22
22
21
2
24
6
22
13
22
31
34
33
22
22
31
34
33
14
10
15
11
25
26
23
9
24
5
1
4
26
20
24
3
30
22
19
29
32
