B-23 B7 【 RX-7R 】 SYSTEM DIAGRAM (7) 【 RX-7R 】 SYSTEM DIAGRAM (7) ｲﾗｽﾄ番号 Ref.No. 品番 Part Number Description 品名 個数 Q'ty 備考 Remarks 1 EZ1-969-340-13 HARNESS (C CAN-C CNT) ﾊ-ﾈｽ (C CAN-C CNT) 1 2 401-46464 CONVEYO R CON…
B-22
B7
【RX-7R】SYSTEM DIAGRAM (7)
【RX-7R】SYSTEM DIAGRAM (7)
B-23
B7
【RX-7R】SYSTEM DIAGRAM (7)
【RX-7R】SYSTEM DIAGRAM (7)
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ1-969-340-13 HARNESS (C CAN-C CNT) ﾊ-ﾈｽ (C CAN-C CNT) 1
2 401-46464 CONVEYOR CONT PCB ASM ｺﾝﾍﾞｱ CONT 基板組 1
3 EZA-191-678-0A CONVEYOR CONT COMPL ｺﾝﾍﾞｱ CONT COMPL 1
4 401-58045 BOX-DRV POW CABLE ASM BOX-DRV POW ｹｰﾌﾞﾙｸﾐ 1
5 EZ1-969-356-12 HARNESS (C CNT1-C CNT2 (+) ) ﾊ-ﾈｽ (C CNT1-C CNT2 (+) ) 1
6 EZ1-969-356-22 HARNESS (C CNT1-C CNT2 (G) )
ﾊ-ﾈｽ (C CNT1-C CNT2 (G) )
1
7 EZ1-969-356-32 HARNESS (C CNT2-C CNT3 (+) ) ﾊ-ﾈｽ (C CNT2-C CNT3 (+) ) 1
8 EZ1-969-356-42 HARNESS (C CNT2-C CNT3 (G) ) ﾊ-ﾈｽ (C CNT2-C CNT3 (G) ) 1
9 EZ1-969-383-12 HARNESS (BOX IO2-AIRSUP MNT) ﾊ-ﾈｽ (BOX IO2-AIRSUP MNT) 1
10 402-07800 C CNT1-DRV1_PWB DET CABLE ASM C CNT1-DRV1_PWB DET ｹｰﾌﾞﾙｸﾐ 1
11 402-10303 CCB JP CABLE ASM CCB JP ｹｰﾌﾞﾙｸﾐ 1
12 402-07801 C CNT1-DRV4 CABLE ASM
C CNT1-DRV4 ｹｰﾌﾞﾙｸﾐ
1
13 401-61069 HARNESS(C CNT1-PWBST) ﾊ-ﾈｽ (C CNT1-PWBST) 1
14 402-07802 C CNT2-DRV5 CABLE ASM C CNT2-DRV5 ｹｰﾌﾞﾙｸﾐ 1
15 EZ1-969-345-11 HARNESS (C CNT2-NZL MV) ﾊ-ﾈｽ (C CNT2-NZL MV) 1
16 402-07806 C CNT2-NZL OT CABLE ASM C CNT2-NZL OT ｹｰﾌﾞﾙｸﾐ 1
17 402-07809 BU PIN DET(S) CABLE ASM BU PIN DET(S) ｹｰﾌﾞﾙｸﾐ 1
18 402-07804 C CNT3-DRV9 CABLE ASM
C CNT3-DRV9 ｹｰﾌﾞﾙｸﾐ
1
19 402-07803 C CNT3-DRV7 CABLE ASM C CNT3-DRV7 ｹｰﾌﾞﾙｸﾐ 1
20 402-07808 C CNT3-CLAMP MV(S) CABLE ASM C CNT3-CLAMP MV(S) ｹｰﾌﾞﾙｸﾐ 1
21 402-07807 C CNT3-CLAMP CS(S) CABLE ASM C CNT3-CLAMP CS(S) ｹｰﾌﾞﾙｸﾐ 1
22 EZ1-969-350-12 HARNESS (C CNT3-BACKUP) ﾊ-ﾈｽ (C CNT3-BACKUP) 1
23 EZ1-969-343-13 HARNESS (C DRV1-C CNT1) ﾊ-ﾈｽ (C DRV1-C CNT1) 1
24 401-57614 PLUSE MOTOR DRIVE (CVD524-K)
PLUSE ﾓｰﾀｰ ﾄﾞﾗｲﾌﾞ (CVD524-K)
1
25 401-57613 PLUSE MOTOR DRIVE (CVD518-K) PLUSE ﾓｰﾀｰ ﾄﾞﾗｲﾌﾞ (CVD518-K) 1
26 401-57614 PLUSE MOTOR DRIVE (CVD524-K) PLUSE ﾓｰﾀｰ ﾄﾞﾗｲﾌﾞ (CVD524-K) 1
27 401-58042 DRV-CV MOTOR CABLE ASM DRV-CV ﾓｰﾀｰ ｹｰﾌﾞﾙｸﾐ 1
28 401-58043 DRV-W MOTOR CABLE ASM DRV-W ﾓｰﾀｰ ｹｰﾌﾞﾙｸﾐ 1
29 401-58044 DRV-BU MOTOR CABLE ASM DRV-BU ﾓｰﾀｰ ｹｰﾌﾞﾙｸﾐ 1
30 401-59490 MOTOR ASSY (CVFR)
ﾓｰﾀｰ ASSY (CVFR)
1
31 401-59489 MOTOR ASSY (CVFL) ﾓｰﾀｰ ASSY (CVFL) 1
32 401-59493 MOTOR ASSY (ADF) ﾓｰﾀｰ ASSY (ADF) 1
33 401-57610 PULSE MOTOR (PKP546N18A) PULSE ﾓｰﾀｰ (PKP546N18A) 1
34 EZ1-492-242-13 SOLENOID ASSY (AIR SUPPLY) ｿﾚﾉｲﾄﾞ ASSY (AIR SUPPLY) 1
35 EZ1-492-253-12 SENSOR ASSY ｾﾝｻ ASSY (ﾀﾂﾁ ｽｲﾂﾁ R) 1
36 EZ1-492-252-12 SENSOR ASSY
ｾﾝｻ ASSY (ﾀﾂﾁ ｽｲﾂﾁ L)
1
37 401-44555 EF ARRANGE CBL BLACKET ASM EF ARRANGE CBL ﾌﾞﾗｹｯﾄｸﾐ 1
38 EZ1-492-225-11 SENSOR ASSY ｾﾝｻ ASSY (ｷﾊﾞﾝ ｱﾘﾅｼ M-FL) 1
39 EZ1-492-226-11 SENSOR ASSY ｾﾝｻ ASSY (ｷﾊﾞﾝ ｱﾘﾅｼ S-FC) 1
40 EZ1-492-226-21 SENSOR ASSY ｾﾝｻ ASSY (ｷﾊﾞﾝ ｱﾘﾅｼ S-FR) 1
41 EZ1-492-213-11 AMPLIFIER SENSOR (FX-502) ｾﾝｻ ｱﾝﾌﾟ (FX-502) 1
42 EZ1-492-207-11 SENSOR FIBER (FT-AL05)
ﾌｱｲﾊﾞ ｾﾝｻ (FT-AL05)
1
43 EZ1-492-208-11 AMPLIFIER SENSOR (FX-501) ｾﾝｻ ｱﾝﾌﾟ (FX-501) 1
44 EZ1-492-207-11 SENSOR FIBER (FT-AL05) ﾌｱｲﾊﾞ ｾﾝｻ (FT-AL05) 1
45 402-07022 SOLENOID VALVE ASSY_SINGLE ｿﾚﾉｲﾄﾞﾊﾞﾙﾌﾞ ASSY (ｼﾝｸﾞﾙ) 1
46 401-61071 HARNESS(PWST FR) ﾊ-ﾈｽ (PWST FR) 1
47 401-61070 HARNESS(PWST FL) ﾊ-ﾈｽ (PWST FL) 1
48 401-61482 SENSOR ASSY(ST)
ｾﾝｻｰ ASSY(ST)
1
49 402-07028 SOLENOID VALVE(ST) ASSY_SINGLE ｿﾚﾉｲﾄﾞﾊﾞﾙﾌﾞ(ST) ASSY (ｼﾝｸﾞﾙ) 1
50 402-07028 SOLENOID VALVE(ST) ASSY_SINGLE ｿﾚﾉｲﾄﾞﾊﾞﾙﾌﾞ(ST) ASSY (ｼﾝｸﾞﾙ) 1
B-24
B7
【RX-7R】SYSTEM DIAGRAM (7)
【RX-7R】SYSTEM DIAGRAM (7)
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
51 EZ1-492-221-12 SENSOR ASSY ｾﾝｻ ASSY (ｶ-ﾄﾘﾂｼﾞｱﾘﾅｼ 1) 1
52 EZ1-492-221-22 SENSOR ASSY ｾﾝｻ ASSY (ｶ-ﾄﾘﾂｼﾞｱﾘﾅｼ 2) 1
53 EZ1-492-221-32 SENSOR ASSY ｾﾝｻ ASSY (ｶ-ﾄﾘﾂｼﾞｱﾘﾅｼ 3) 1
54 EZ1-492-221-42 SENSOR ASSY ｾﾝｻ ASSY (ｶ-ﾄﾘﾂｼﾞｱﾘﾅｼ 4) 1
55 EZ1-492-249-11 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾞﾂｸ ｱﾂﾌﾟ ﾋﾟﾝ 2) 1
56 EZ1-492-363-12 SENSOR ASSY
ｾﾝｻ ASSY (ｺﾞﾐﾊﾞｺ (C) ｱﾘﾅｼ)
1
57 EZ1-969-781-12 HARNESS (BU PIN DET2) ﾊ-ﾈｽ (BU ﾋﾟﾝ DET2) 1
58 EZ1-492-223-11 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾞﾂｸ ｱﾂﾌﾟ ﾘﾐﾂﾄ 1) 1
59 EZ1-492-216-12 SENSOR ASSY ｾﾝｻ ASSY (ｸﾗﾝﾌﾟ 1) 1
60 EZ1-492-216-22 SENSOR ASSY ｾﾝｻ ASSY (ｸﾗﾝﾌﾟ 2) 1
