A-41 A12 【共通】ヘッド ASSY-3 【 COMMON 】 Head assy - 3
A-40
A11
【共通】ヘッド ASSY-2
【COMMON】Head assy - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ1-492-165-13 SENSOR ASSY (NOZZLE SHAFT) ｾﾝｻ- ASSY (ﾉｽﾞﾙ / ｼｬﾌﾄｹﾝｼｭﾂ) 2
2 EZ4-454-015-01 NUT, PLATE ｲﾀ ﾅﾂﾄ 2
3 EZ4-454-830-01 LOW HEAD SCREW (M3X4) ﾃｲﾄｳ ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ (M3X4) 9
4 EZ4-457-753-01 CONNECT PLATE (2) ﾚﾝｹﾂ ﾌﾟﾚ-ﾄ (2) 1
5 EZ4-465-279-01 HEAD COVE RBRACKET ﾍﾂﾄﾞ ｶﾊﾞ- ﾌﾞﾗｹﾂﾄ 1
6 EZ7-683-000-23 BOLT, HEXAGON SOCKET 2X8 6 ｶｸｱﾅﾂｷ ﾎﾞﾙﾄ 2X8 4
7 EZ7-683-480-24 BOLT, HEXAGON SOCKET 2X5 6 ｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ 2X5 4
8 EZ1-492-167-11 MOTOR ASSY (VALVE) ﾓ-ﾀ- ASSY (ﾊﾞﾙﾌﾞ) 1
9 EZ1-492-168-11 SENSOR ASSY (VALVE) ｾﾝｻ- ASSY (ﾊﾞﾙﾌﾞ) 1
10 EZ1-492-168-11 SENSOR ASSY (VALVE) ｾﾝｻ- ASSY (ﾊﾞﾙﾌﾞ) 1
11 EZ4-454-007-01 VALEV LEVER HOLDER ﾊﾞﾙﾌﾞ ﾚﾊﾞ- ﾎﾙﾀﾞ- 1
12 EZ4-454-008-01 VALVE MOTOR BASE BARCKET ﾊﾞﾙﾌﾞ ﾓ-ﾀ ﾍﾞ-ｽ ﾌﾞﾗｹﾂﾄ 1
13 EZ4-454-010-01 CAM FOLLOWER SHAFT ｶﾑ ﾌｵﾛｱ ｼﾔﾌﾄ 1
14 EZ4-454-014-01 NOZZLE SENSOR BRACKET ﾉｽﾞﾙ ｾﾝｻ- ﾌﾞﾗｹﾂﾄ 1
15 EZ4-454-040-01 LEVER SHAFT ﾚﾊﾞ- ｼﾔﾌﾄ 2
16 EZ4-454-046-01 BEARING (MR83) ﾍﾞｱﾘﾝｸﾞ (MR83) 2
17 EZ4-454-067-01 CAMFLLOWER (CFS3) ﾐﾆﾁﾕｱ ｶﾑﾌｵﾛｱ (CFS3) 1
18 EZ4-454-073-01 LM GUIDE MLC7R45 LM ｶﾞｲﾄﾞ (MLC7R45) 1
19 EZ4-454-715-01 LEVER SHAFT BEARING COLLAR ﾚﾊﾞ- ｼﾔﾌﾄ ﾍﾞｱﾘﾝｸﾞ ｶﾗ- 2
20 EZ4-457-186-01 PLATE, SENSOR BRACKET ｾﾝｻ- ﾌﾞﾗｹﾂﾄ ﾄﾘﾂｹ ﾌﾟﾚ-ﾄ 1
21 EZ4-457-187-01 PLATE, LEVER SENSOR FITTING ﾚﾊﾞ- ｾﾝｻ ﾄﾘﾂｹ ﾌﾟﾚ-ﾄ 1
22 EZ4-457-188-01 LEVER SENSOR DOG ﾚﾊﾞ- ｾﾝｻ ﾄﾞｸﾞ 1
23 EZ4-457-202-01 LEVER BLOCK ﾚﾊﾞ- ﾌﾞﾛﾂｸ 1
24 EZ4-701-529-01 TIE MOUNT (MB1) ﾀｲﾏｳﾝﾄ (MB1) 6
25 EZ4-718-721-01 BOLT HEXAGON SOCKET(M2X3 SUS) ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ (M2X3 SUS) 4
26 EZ7-621-996-05 BOLT HEXAGON SOCKET 2.6X5 6 ｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ 2.6X5 4
27 EZ7-682-247-04 SCREW +K 3X6 +K 3X6 6
28 EZ7-683-404-04 BOLT,HEXAGON SOCKET 3X8 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X8 7
29 EZ7-683-405-04 BOLT,HEXAGON SOCKET 3X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X10 5
30 EZ7-683-480-14 BOLT, HEXAGON SOCKET 2X4 6 ｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ 2X4 1
31 EZ7-684-023-04 N 3 TYPE 2 N 3 TYPE 2 2
32 EZ7-683-403-04 BOLT,HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 14
33 EZ3-681-308-02 BOLT (M2X6), HOLE, HEXAGON ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ M2X6 32
34 401-55272 SLIT (OS-EX10-12) ｽﾘｯﾄ (OS-EX10-12) 1
A-41
A12
【共通】ヘッド ASSY-3
【COMMON】Head assy - 3
A-42
A12
【共通】ヘッド ASSY-3
【COMMON】Head assy - 3
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ1-492-165-13 SENSOR ASSY (NOZZLE SHAFT) ｾﾝｻ- ASSY (ﾉｽﾞﾙ / ｼｬﾌﾄｹﾝｼｭﾂ) 2
2 EZ1-492-166-12 SOLENOID VALVE ASSY (BLW) ｿﾚﾉｲﾄﾞ ﾊﾞﾙﾌﾞ ASSY (BLW) 2
3 EZ1-492-202-12 BATTERY ASSY ﾊﾞﾂﾃﾘ- ASSY 1
4 EZ1-895-367-12 BOARD BACKUP MONITORING ﾊﾞﾂｸｱﾂﾌﾟ ﾓﾆﾀ- ﾎﾞｰﾄﾞ 1
5 EZ4-454-723-01 LOW HEAD SCREW (M3X8) ﾃｲﾄｳ ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ (M3X8) 1
6 EZ4-458-314-01 BATTERY CLIP ﾊﾞﾂﾃﾘ- ｸﾘﾂﾌﾟ 1
7 EZ4-458-495-02 COVER, WIRING ﾊｲｾﾝ ｶﾊﾞ- 1
8 EZ7-627-551-18 SCREW,PRECISION +P 1.4X2 ｾｲﾐﾂﾈｼﾞ +P 1.4X2.0, TYPE 1 4
9 EZ7-683-406-04 BOLT,HEXAGON SOCKET 3X12 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X12 2
10 EZ7-683-421-04 BOLT HEXAGON SOCKET 4X12 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ(C4X12) 3
11 EZ7-683-480-24 BOLT, HEXAGON SOCKET 2X5 6 ｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ 2X5 4
12 EZ7-683-405-04 BOLT,HEXAGON SOCKET 3X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X10 5
13 EZ1-845-163-12 UNIT CAMERA MOVE (QQJ-2216) ｲﾄﾞｳ ｶﾒﾗ ﾕﾆﾂﾄ (QQJ-2216) 1 RX-7 用(P16)
14 402-07918 MOVABLE_CAMERA_UNIT_PROTECT 保護付移動ｶﾒﾗﾕﾆｯﾄ 1 RX-7R 用(P16S)
15 EZ4-453-950-01 PLATE, HEAD BASE ﾍﾂﾄﾞﾌﾞ ﾍﾞ-ｽ ﾌﾟﾚ-ﾄ 1
16 EZ4-453-951-01 PLATE, BOTTOM ﾎﾞﾄﾑ ﾌﾟﾚ-ﾄ 1
17 EZ4-453-952-01 PLATE (1), SIDE ｻｲﾄﾞ ﾌﾟﾚ-ﾄ (1) 1
18 EZ4-453-953-01 PLATE (2), SIDE ｻｲﾄﾞ ﾌﾟﾚ-ﾄ (2) 1
19 EZ4-453-994-01 BLOCK, CLAMP ｸﾗﾝﾌﾟ ﾌﾞﾛﾂｸ 1
20 EZ4-453-997-01 HEAD FIXING BLOCK ﾍﾂﾄﾞｶﾞﾜ ｺﾃｲ ﾌﾞﾛﾂｸ 1
21 EZ4-454-074-01 MINIATURE Y PACKING MYA-8 ﾐﾆ Y ﾊﾟﾂｷﾝ (MYA-8) 1
22 EZ4-457-781-01 STOPPER PIN ｽﾄﾂﾊﾟ- ﾋﾟﾝ 2
23 EZ4-458-768-01 DECOMPRESSION VALVE (MR001) ｹﾞﾝｱﾂﾍﾞﾝ (MR001) 1
24 EZ4-701-529-01 TIE MOUNT (MB1) ﾀｲﾏｳﾝﾄ (MB1) 2
25 EZ4-702-269-01 NIPPLE (M-5H-4), HOSE ﾎ-ｽ ﾆﾂﾌﾟﾙ (M-5H-4) 1
26 EZ4-702-324-01 ELBO (M-5HL-4), HOSE ﾎ-ｽ ｴﾙﾎﾞ (M-5HL-4) 1
27 EZ7-682-247-04 SCREW +K 3X6 +K 3X6 2
28 EZ7-683-403-04 BOLT,HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 14
29 EZ7-683-419-04 BOLT HEXAGON SOCKET 4X8 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X8 2
30 EZ4-454-032-01 SPACER, GEAR ｷﾞｱﾖｳ ｽﾍﾟ-ｻ- 7
31 EZ4-472-629-01 SHAFT, REINFORCE ﾎｷﾖｳﾖｳ ｼﾔﾌﾄ 1
32
EZ4-465-277-01 HEAD CLAMP BLOCK SHIM (T0.1) ﾍﾂﾄﾞ ｸﾗﾝﾌﾟ ﾌﾞﾛﾂｸ ｼﾑ (T0.1) 1
EZ4-465-277-11 HEAD CLAMP BLOCK SHIM (T0.2) ﾍﾂﾄﾞ ｸﾗﾝﾌﾟ ﾌﾞﾛﾂｸ ｼﾑ (T0.2) 2
EZ4-465-277-21 HEAD CLAMP BLOCK SHIM (T0.5) ﾍﾂﾄﾞ ｸﾗﾝﾌﾟ ﾌﾞﾛﾂｸ ｼﾑ (T0.5) 1
33 EZ3-703-360-51 PIN, PARALLEL (DIA. 3X8) ﾍｲｺｳﾋﾟﾝ (ﾌｱｲ 3X8) 4
