【RX-7】P8 ヘッド ASSY-2
【RX-7】P8 Head assy - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 401-55912 HOLDER(2)_BEARING ﾍﾞｱﾘﾝｸﾞﾎﾙﾀﾞ(2) 1
2 401-56141 COLLAR(3)_BEARING ﾍﾞｱﾘﾝｸﾞｶﾗｰ(3) 1
3 401-56142 HOLDER_SHAFT ｼｬﾌﾄﾎﾙﾀﾞｰ 1
4 401-56400 MAIN SHAFT COVER ﾒｲﾝｼｬﾌﾄｶﾊﾞｰ 1
5 401-56410 BEARING(7905UCDB) ﾍﾞｱﾘﾝｸﾞ(7905UCDB) 1
6 401-56458
LOW HEAD CAP SCREW(M3X12)_HEX SOCKET
ﾛｯｶｸｱﾅﾂｷﾃｲﾄｳﾎﾞﾙﾄ(M3x12) 1
7 401-56624 RETAINER(2)_BEARING ﾍﾞｱﾘﾝｸﾞｵｻｴ(2) 1
8 401-60283 NUT_BEARING ﾍﾞｱﾘﾝｸﾞﾅｯﾄ 1
9 401-60284 COLLAR_BEARING NUT ﾍﾞｱﾘﾝｸﾞﾅｯﾄｶﾗｰ 1
10 EZ3-170-255-01 SCREW (M3X3) ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ (M3X3) 2
11 EZ4-454-723-01 LOW HEAD SCREW (M3X8) ﾃｲﾄｳ ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ (M3X8) 6
12 EZ7-683-405-04 BOLT HEXAGON SOCKET 3X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X10 3
13 401-55921 SPACER_RT GEAR RT ｷﾞｱｰｽﾍﾟｰｻｰ 6
14 401-56134 POST(1)_RT SPRING RT ｽﾌﾟﾘﾝｸﾞﾎﾟｽﾄ(1) 6
15 401-56135 POST(2)_RT SPRING RT ｽﾌﾟﾘﾝｸﾞﾎﾟｽﾄ(2) 6
16 401-56163 HOLDER_GEAR RT RT ｷﾞｱｰﾎﾙﾀﾞｰ 1
17 401-56293 GEAR_RT(1) ｷﾞｱｰ RT(1) 1
18 401-56294 GEAR_RT(2) ｷﾞｱｰ RT(2) 1
19 EZ3-681-308-02 BOLT (M2X6) HOLE HEXAGON ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ M2X6 14
20 401-55891 SHAFT_MAIN ﾒｲﾝｼｬﾌﾄ 1
21 401-55892 PLATE_MASK ﾏｽｸﾌﾟﾚｰﾄ 1
22 401-55893 HOLDER_BEARING ﾍﾞｱﾘﾝｸﾞﾎﾙﾀﾞ 1
23 401-55895 RETAINER_BEARING ﾍﾞｱﾘﾝｸﾞｵｻｴ 1
24 401-55909 RETAINER(1)_SEAL ｼｰﾙｵｻｴ(1) 1
25 401-55915 COLLAR_INNER SPLINE ｲﾝﾅｰｽﾌﾟﾗｲﾝｶﾗｰ 8
26 401-55916 COLLAR_BEARING ﾍﾞｱﾘﾝｸﾞｶﾗｰ 1
27 401-56130 HEAD_P8 P8 ﾍｯﾄ 1
28 401-56137 SHAFT_SECOND ｾｶﾝﾄﾞｼｬﾌﾄ 1
29 401-56138 GUIDE_SPOOL ｽﾌﾟｰﾙｶﾞｲﾄﾞ 8
30 401-56181 RETAINER_FILTER ﾌｨﾙﾀｰｵｻｴ 8
31 401-56412 BEARING(6705HW2RUC0) ﾍﾞｱﾘﾝｸﾞ(6705HW2RUC0) 1
32 401-56415 BEARING(S679HWZZSMC3) ﾍﾞｱﾘﾝｸﾞ(S679HWZZSMC3) 16
33 401-56424 MECHANICAL VALVE(MDV23-Z12-0304) ﾒｶﾊﾞﾙﾌﾞ(MDV23-Z12-0304) 8
34 401-56437 O_RING(P20) O ｰﾘﾝｸﾞ(P20) 1
35 401-56438 O_RING(P15) O-ﾘﾝｸﾞ(P15) 1
36 401-56439 O_RING(S28) O-ﾘﾝｸﾞ(S28) 1
37 401-56444 O RING(SOP22)_CAP ｷｬｯﾌﾟ O-ﾘﾝｸﾞ(SOP22) 1
38 401-56445 MINI Y PACKING(MYN-9) ﾐﾆ Y ﾊﾟｯｷﾝ(MYN-9) 1
39 401-56456
SMALL HEAD CAP SCREW(M3X8)_HEX SOCKET
ﾛｯｶｸｱﾅﾂｷｼｮｳｱﾀﾏﾎﾞﾙﾄ(M3X8) 10
40 401-56457 LOW HEAD SCREW(M1.4X3)_PRECISION INST ﾃｲﾄｳｾｲﾐﾂｺﾈｼﾞ(M1.4x3) 16
41 401-56459 LOW HEAD CAP SCREW(M3X6)_HEX SOCKET ﾛｯｶｸｱﾅﾂｷﾃｲﾄｳﾎﾞﾙﾄ(M3x6) 8
42 401-56540 COLLAR_INNER ｲﾝﾅｰｶﾗｰ 1
43 401-56627
LOW_SMALL HEAD CAP SCREW(M3X6)_HEAXGON S
ﾛｯｶｸｱﾅﾂｷﾃｲﾄｳｼｮｳｱﾀﾏﾎﾞﾙﾄ(M3x6) 4
44 401-56639
HEXAGON SOCKET SCREW(M1.6X2)_FLAT TYPE
ﾛｯｶｸｱﾅﾂｷﾄﾒﾈｼﾞ(M1.6x2)ﾋﾗｻｷ 2
45 401-56641 -SET SCREW(M2.3X1.6)_FLAT TYPE ｽﾘﾜﾘﾂｷﾄﾒﾈｼﾞ(M2.3x16)ﾋﾗｻｷ 16
46 401-56647 PAN HEAD SCREW(M1.4X2)_PRECISION INST ｾｲﾐﾂｷｷﾖｳﾅﾍﾞｺﾈｼﾞ(M1.4x2) 16
47 EZ7-683-481-04 BOLT HEXAGON SOCKET 2.5X4 6 ｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ 2.5X4 8
48 EZ7-683-403-04 BOLT HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 8
49 EZ3-278-109-01 SPRING INNER SPLIN ｲﾝﾅ- ｽﾌﾟﾗｲﾝ ﾊﾞﾈ 8
50 EZ3-278-945-01 RETAINER (B) NOZZLE SPRING ﾉｽﾞﾙ ﾊﾞﾈ ｵｻｴ (B) 8
51 EZ3-681-308-02 BOLT (M2X6) HOLE HEXAGON ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ M2X6 2
52 401-55919 SPRINNG(1)_TORSION ﾄｰｼｮﾝﾊﾞﾈ(1) 8
53 401-56290 GEAR_RN(4) ｷﾞｱｰ RN(4) 8
54 401-56291 GEAR_RN(5) ｷﾞｱｰ RN(5) 8
A-55
A17
【RX-7】P8 ヘッド ASSY-2
【RX-7】P8 Head assy - 2
55 401-56612 RETAINING RING CURICENT TYPE(5103-46) ｸﾘｾﾝﾄﾄﾒﾜ(5103-46) 8
56 401-56640
HEXAGON SOCKET SCREW(M2.52.5)_FLAT TYPE ﾛｯｶｸｱﾅﾂｷﾄﾒﾈｼﾞ(M2.5x2.5)ﾋﾗｻｷ
16
57 EZ3-278-152-01 SHOE SET ｾﾂﾄ ｼﾕ- 16
58 401-56148 HOLDER_SPLINE NUT ｽﾌﾟﾗｲﾝﾅｯﾄﾎﾙﾀﾞｰ 1
59 401-56149 NUT_SPLINE ｽﾌﾟﾗｲﾝﾅｯﾄ 1
60 401-56150 SHAFT_SPLINE ｽﾌﾟﾗｲﾝｼｬﾌﾄ 1
61 401-56168 STOPPER_SHAFT ｼｬﾌﾄｽﾄｯﾊﾟｰ 1
62 401-56425 CYLINDER_SPECIAL(SPC1-4-7.5-Z14-007)
ﾄｸｼｭｼﾘﾝﾀﾞ(SPC1-4-6.5-Z14-007)
1
63 401-56637 NUT 2TYPE(M2SUS)_HEXAGON ﾛｯｶｸﾅｯﾄ 2TYPE(M2SUS) 1
64 401-56744 BARB FITTING(M-3ALU-2) ﾊﾞｰﾌﾞﾂｷﾞﾃ(M-3ALU-2) 1
65 401-56422 SPLINE_INNER(LT4XUS+88.5LPF) ｲﾝﾅｰｽﾌﾟﾗｲﾝ(LT4XUS+88.5LPF) 2
66 401-56421 SPLINE_INNER(LT4XUS+88.0LPF) ｲﾝﾅｰｽﾌﾟﾗｲﾝ(LT4XUS+88.0LPF) 2
67 401-56420 SPLINE_INNER(LT4XUS+87.5LPF) ｲﾝﾅｰｽﾌﾟﾗｲﾝ(LT4XUS+87.5LPF) 4
68 EZ3-279-059-02 SPRING (O RING -D#) O RING ﾉｽﾞﾙ O ﾘﾝｸﾞ ﾊﾞﾈ (O ﾘﾝｸﾞ -D*) 8
69 EZ4-719-920-01 BALL ROPE (DIA 2+-0 MICRONE)
ｺｳｷﾕｳ (ﾏﾙ 2+-0 ﾐｸﾛﾝ.JIS B1501*)
16
70 401-56412 BEARING(6705HW2RUC0) ﾍﾞｱﾘﾝｸﾞ(6705HW2RUC0) 1
71 401-56458
LOW HEAD CAP SCREW(M3X12)_HEX SOCKET
ﾛｯｶｸｱﾅﾂｷﾃｲﾄｳﾎﾞﾙﾄ(M3x12) 6
72 401-56604 SHAFT OUTER ASSY ｱｳﾀｰｼｬﾌﾄ ASSY 1
73 SM-6044002-TN SCREW M4X0.7 L=40 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=40 2
74 401-55917 POST_RN SPRING RN ｽﾌﾟﾘﾝｸﾞﾎﾟｽﾄ 4
75 401-55920 SPACER_RN GEAR RN ｷﾞｱｰｽﾍﾟｰｻｰ 4
76 401-56287 GEAR_RN(1) ｷﾞｱｰ RN(1) 1
77 401-56288 GEAR_RN(2) ｷﾞｱｰ RN(2) 1
78 EZ4-454-723-01 LOW HEAD SCREW (M3X8) ﾃｲﾄｳ ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ (M3X8) 4
79 401-55888 COLLAR(2)_BEARING ﾍﾞｱﾘﾝｸﾞｶﾗｰ(2) 1
80 401-56136 SHAFT_CENTER ｾﾝﾀｰｼｬﾌﾄ 1
81 401-56413 BEARING(6704-H-ZZS) ﾍﾞｱﾘﾝｸﾞ(6704-H-ZZS) 1
82 RC-1850001-KP C-RING 20 (18.5) C 形止め輪 20 (18.5) 1
83 WP-0280500-SC WASHER ﾋﾗｻﾞｶﾞﾈ ｺｶﾞﾀﾏﾙ M2.5 8
84 401-56164 BLOCK_MANIFOLD ﾏﾆﾎｰﾙﾄﾞﾌﾞﾛｯｸ 1
85 401-56413 BEARING(6704-H-ZZS) ﾍﾞｱﾘﾝｸﾞ(6704-H-ZZS) 1
86 401-56414 BEARING(6702-H-ZZ) ﾍﾞｱﾘﾝｸﾞ(6702-H-ZZ) 1
87 401-56442 O RING(SOP15)_CAP ｷｬｯﾌﾟ O-ﾘﾝｸﾞ(SOP15) 2
88 401-56443 O RING(SOP20)_CAP ｷｬｯﾌﾟ O-ﾘﾝｸﾞ(SOP20) 1
