SIPLACE 80 S/ F/G Service M anual 1 Operational Safety Edition 04/97 1 - 5 1.1.3 Servicing Work on Electro nic Components ATTE NTION (ESD stic ker for label ling e le ct rosta tical ly s ensitiv e dev ices) Electroni c m…
1 Operational Safety SIPLACE 80 S/F/G Service Manual
Edition 04/97
1 - 4
-
The machine operator or the servicing personnel should only carry out work for which they have had ade-
quate training and which they are completely familiar with.
-
You should also comply with the speciall safety regulations which apply in your own country.
1.1.2 Conventions on the Use of Danger Symbols
Qualified or adequately trained persons are considered to be persons who are familiar with the installation,
operation and maintenance of the placement machine and its associated equipment and who have a corre-
sponding qualification such as:
-
Training, briefing or authorization in switching on and off, isolating, grounding or labelling current circuits
and installation parts in accordance with technical safety standards.
-
Training or briefing in accordance with technical safety standards in the care and use of the appropriate
safety equipment.
-
Training in First Aid.
DANGER
OOO
or
QQQ
within the intention of this service manual means that failure to comply with the danger instructions
w i l l
result in death, serious physical injury or considerable damage to property.
WARNING
OO
or
QQ
within the intention of this service manual means that failure to comply with the warning instructions
c a n
result in death, serious physical injury or considerable damage to property.
CAUTION
O
or
Q
within the intention of this service manual means that failure to comply with the caution instructions can result
in minor physical injury or damage to property.
NOTE
within the intention of this service manual indicates an important piece of information concerning the product
or provides a reference to a part of the service manual to which your attention should particularly be drawn.
SIPLACE 80 S/F/G Service Manual 1 Operational Safety
Edition 04/97
1 - 5
1.1.3 Servicing Work on Electronic Components
ATTENTION (ESD sticker for labelling electrostatically sensitive devices)
Electronic modules can be damaged by even slight static electricity. For this reason they are marked with this
symbol.
You should observe the following rules when carrying out servicing work on electronic modules :
●
Switch the machine off and disconnect it from the power supply.
●
Put on an antistatic armband.
●
Do not remove electronic modules from their antistatic envelope until just before you fit them.
●
Do not put the electronic module down on anything except a grounded antistatic mat.
●
Make sure that the components inserted in the IC sockets are seated firmly in the sockets.
●
When fitting the board hold it only by its edges and do not touch either the components or the conductor
tracks on the board.
●
Touch a bare metal surface before fitting the board in the machine.
●
Make sure that all electrical connections have been made correctly.
●
When fitting plugged-in modules make sure that they are seated correctly and firmly in their unit. If this is
not the case, short circuits could occur and the connections burn out.
●
Pack the defective modules in the electrostatic envelopes provided.
1 Operational Safety SIPLACE 80 S/F/G Service Manual
Edition 04/97
1 - 6
