11 Control Unit SIPLACE 80 S/F/G Service Manual
Edition 04/97
11 - 6
11.1.5 Replacing the Hard Disk / Floppy Disk Board
Spare parts
Floppy/winchester AMS-M349-A100, from item no. 00319704-01
●
Disconnect all plug-in connections on the front panel of the station computer (plugs x3, x4 sa, x5 sa; see Fig.
11.1.2).
●
Unscrew and remove the MC board’s front cover mounting screws (2 slotted-head screws) and the hard disk /
floppy disk board mounting screws (4 slotted-head screws).
NOTE
The station computer and the hard disk / floppy disk boards are connected via two short flat ribbon cables.
●
Carefully pull out the station computer and hard disk / floppy disk boards. Place the boards on an ESD-
checked surface.
●
Disconnect the connecting cables between the boards (see the section
Replacing Computer M34
).
●
Insert the new hard disk / floppy disk board in the station computer board.
●
To fit the boards proceed in the reverse sequence of operations.
NOTE
When inserting the connecting plugs make sure you have the correct slots on the front panel. Should you have
lost the setup data for the M44 see Section 11.2.
●
Switch the machine on and install the current station software (see
Adjustment instructions
).
●
Copy the original MA data from the backup copy onto the hard disk.
SIPLACE 80 S/F/G Service Manual 11 Control Unit
Edition 04/97
11 - 7
11.2 Set-Up Configuration of the M34 Station Computer
NOTE
To change the data you will need to use the numerical keypad. This is included in a normal keyboard. The
keys are marked with violet numbers and characters in their top left corner (for example, keys 7-0, U-P, J-ö,
and so on).
Press the Fn key to activate the numerical keypad function of the individual keys.
11.2.1 Configuration Data
11.2.1.1 Screen 1
Date: dd. mmm yyyy
Time: hh:mm:ss
Drive A: 1.44, 3 ½ in.
Drive B: None
Video: EGA / VGA
Post message: Maximize
Quick boot: Disable
Halt on: ALL errors
Security: Disable
Virus Warury: Disable
Booting sequence: A, C
Default speed: High
Disk 0 49 (automatic hard disk detection)
Disk 1 None
11 Control Unit SIPLACE 80 S/F/G Service Manual
Edition 04/97
11 - 8
11.2.1.2 Screen 2
> Bios < Enabled D000: Disabled E000: Disabled
> Video < Enabled D400: Disabled E400: Disabled
Disabled D800: Disabled E800: Disabled
Disabled DC00: Disabled EC00: Disabled
External cache: Enabled Default speed: High
Internal cache: Enabled Slow setting: Fast
COM A: 3F8h
COM B: 2F8h Console rediv: Enable / ANSI
LPT: 378h
Floppy drive: Enabled
IDE: Enabled
11.2.1.3 Screen 3
I/O selection RAM window SMP memory window SMP COM1/2: Disabled
Start address 0000H Start address 0000 00H SMP COM3/4: Disabled
End address 0000H End address 0000 FFH SMP LPT 2: Disabled
