Advanced High Speed Flexible Mounter 8 L ight adj ustme nt 16 Level 256 L evel lig ht ma pping → 16 Level Light c ontrol Prog rammable , 3 种 (Outer ligh t, Side ligh t, Coaxi al light) SECTION ITEM SPECIFICATION REMARK U…
Advanced High Speed Flexible Mounter
8
Light adjustment 16 Level
256 Level light mapping → 16 Level
Light control
Programmable, 3 种(Outer light, Side light, Coaxial
light)
SECTION
ITEM
SPECIFICATION
REMARK
Upward
vision
Function Component inspection, System calibration
Camera type
Analog 1360 X 1040 pixel, C-mount
Configuration
Mega FOV 35 mm
最多可以安装 2 Unit
Mega FOV 45 mm
Non-Mega FOV 35 mm
Non-Mega FOV 45 mm
Illumination
Light source LED
Light adjustment 16 Level
4096 Level light mapping → 16 Level
Light control
Programmable, 3 种(Inner light, Outer light, Side
light)
Vision
board
Board Analog camera grabber
(NAIM TECH)SAMCME 1EA, Mega 相机
PCBs
supported
Maximum board size
L460 X W400 mm
L510 X W460 mm
L610 X W460 mm
L610 X W510 mm
L660 X W460 mm
L740 X W460 mm(Left to Right)
Stopper 移动及出入口延长,
Not use Side Tray(STF-100S)
L740 X W460 mm(Right to Left)
Minimum board size
L50 X W40 mm
适用 SM series in-line spec.
L50 X W30 mm
Board thickness
0.38 ~ 4.2 mm
Maximum board weight
2kg
Maximum board size L740 X W460
时适用
3kg
Advanced High Speed Flexible Mounter
10
SECTION ITEM SPECIFICATION REMARK
Head
Number of spindles 10 spindles
Head pitch 15 mm
供料器可同时吸附的间距
Component centering method
Flying vision
Upward vision
Z axis
Mechanism AC Servo motor + Belt & LM guide Motor : 20 W
Travel range Max. 88 mm Stopper to stopper
Resolution 0.003 mm/pulse
Repeatability
±0.01 mm
θ axis
Mechanism Micro Step motor + Belt & Pulley
2 轴连动
Travel range Unlimited
Resolution
0.018˚/pulse Teaching 基准
Repeatability
±0.05˚
Swing mirror
Mechanism AC servo motor + Belt & Cam Motor : 50 W
Travel range
34˚
Resolution
0.018˚/pulse
Repeatability
±0.02˚
Nozzle holder
Clamping method Taper clamp + Ball
No. of clamping ball
3 个
Cushion
没有 Cushion 在 Nozzle 上安装 Cushion
