Advanced High Speed Flexible Mounter 10 SECTION ITEM SPECIFICATION REMARK Head Numbe r of spi ndles 10 spin dles Head p itch 15 mm 供料器可同时吸附的间 距 Compo nen t cente ring metho d Fly ing visio n Upw ard visio n Z axi s Mecha…

100%1 / 332
设备规格及名称
9
Board warp limit Upper : 0.5 mm, Lower : 1.5 mm
SECTION ITEM SPECIFICATION REMARK
PCB
transport
system
Type
Dual 3 段独立移送方式，使用平皮带移送 防静电 Belt
Board position fixing
外形基准
Side edge fixer
Reference side
Front side fixed
Rear side fixed
Transport speed 0 ~ 30 m/min. variable, static charge prevention belt
可以根据 PCB 重量及所承载元件调节速度(限于贴装领域)
~ 1 kg：3 s, 1 kg ~ 2 kg：5 s
元件的上下处理能力
Upper : 15 mm, Lower 30 mm
可以处理到 30mm
Buffer function
Front buffer 1 Board range
Board size L460mm 以下,610mm/660mm(LongOption)
Rear buffer 1 Board range
Board size L460mm 以下, 610mm/660mm(LongOption)
Transport direction
Left to Right
Right to Left
Transport height
900 ± 20 mm
952.5 ± 12.5 mm
Adjusting Width Automatic AC servo motor
Back up pin Movable type
可以调节高度, Magnetic attachment
Advanced High Speed Flexible Mounter
10
SECTION ITEM SPECIFICATION REMARK
Head
Number of spindles 10 spindles
Head pitch 15 mm
供料器可同时吸附的间距
Component centering method
Flying vision
Upward vision
Z axis
Mechanism AC Servo motor + Belt & LM guide Motor : 20 W
Travel range Max. 88 mm Stopper to stopper
Resolution 0.003 mm/pulse
Repeatability
±0.01 mm
θ axis
Mechanism Micro Step motor + Belt & Pulley
2 轴连动
Travel range Unlimited
Resolution
0.018˚/pulse Teaching 基准
Repeatability
±0.05˚
Swing mirror
Mechanism AC servo motor + Belt & Cam Motor : 50 W
Travel range
34˚
Resolution
0.018˚/pulse
Repeatability
±0.02˚
Nozzle holder
Clamping method Taper clamp + Ball
No. of clamping ball
3 个
Cushion
没有 Cushion 在 Nozzle 上安装 Cushion
设备规格及名称
11
SECTION ITEM SPECIFICATION REMARK
XY
X axis
Mechanism AC servo motor + Ball screw
Motor : 750 W, Ball screw : 直径 15 mm, 间距 30 mm
Travel range
(a) 759.2 mm, (b) 763.2 mm, (c) 767.2 mm
(a) 741 mm, (b) 745 mm, (c) 751 mm
(a) Working, (b) S/W limit, (c) H/W limit
Resolution 0.003 mm/pulse
Repeatability
±0.01 mm
Feed back system
基于 Rotary encoder 的 Semi closed loop
Maximum velocity 1,800 mm/s
Acceleration capability 30,000 mm/s2
Y axis
Mechanism AC servo motor + Ball screw
Motor : 1,000 W x 2, Ball screw : 直径 20 mm, 间距 30 mm
Travel range
(a) 979.5 mm, (b) 961.5 mm, (c) 987.5 mm
(a) 955.5 mm, (b) 961.5 mm, (c) 971.5 mm
(a) Working, (b) S/W limit, (c) H/W limit
Resolution 0.003 mm/pulse
Repeatability
±0.01 mm
Feed back system
基于 Rotary encoder 的 Semi closed loop
Maximum velocity 1,800 mm/s
Acceleration capability 30,000 mm/s2
