设备规格及名称
21
SECTION ITEM SPECIFICATION REMARK
In-line signal
(SMEMA
standard)
From next
machine
Busy input (In)
Pin #1 : (+) Input signal
Less than 24V/10mA
Pin #2 : (-)
Ground
Board available
output (Out)
Pin #3 : Contact output
Pin #4 : Contact output
Connector
AMP 206043-1
设备端
AMP 206044-1
外部连接端
From previous
machine
Busy input
(Out)
Pin #1 : Contact output
Pin #2 : Contact output
Board available
input
(In)
Pin #3 : (+) Input signal
Less than 24V/10mA
Pin #4 : (-) Ground
Connector
AMP 206043-1
设备端
AMP 206043-1
外部连接端
Block diagram
Advanced High Speed Flexible Mounter
22
SECTION ITEM SPECIFICATION REMARK
Other
connectors
Tray Feeder 25 Pin D-sub
背面 2 个
Teaching Box 6 Pin round type
正面 2 个
LAN RJ-45 Jack
背面 1 个
认证 认证标示
CE mark, CE name plate
* 各地区适用选项
- 美洲、欧洲 : Standard
- 国内、亚洲 : 选择事项
设备规格及名称
23
2.4. List Of Maintenance
Inspection Item
Refere
nce
Consumables
Replacement
Cycle
Remarks
Required
Time
Inspection
Cycle
No
Product Activity
Tool
Daily
1
Nozzle Inspect and clean Air gun, swab 2 year Occasionally
10
Minutes
2 Dump Box Clean
After use of the
machine
5
Minutes
3
Feeder 및 Feeder Base
Clean Brush, cloth
After use of the
machine
10
Minutes
4 Backup Table Clean Cloth
After use of the
machine
5
Minutes
5 Air Filter Inspect and replace 1 year Occasionally
60
Minutes
6 Mist Seperator Filter Inspect and replace
1 year Occasionally
30
Minutes
Weekly
7 Head Fly Camera Lens Clean
Wrench,Air
spray,swab
5
Minutes
8 Head Mirror Clean Air spray,cloth
5
Minutes
9 Cover Cooling Fan Filter Clean Vacuum cleaner
10
Minutes
10 Solenoid Valve Inspect and replace
C/S 2 years
20
Minutes
11 Head Vacuum Filter Inspect and replace C/S 6 months
30
Minutes
Monthly
12 Head Nozzle Holder Tube Inspect and replace Separate jig C/S
20
Minutes
13 Head Spindle Clean Air gun, cloth
30
Minutes
14 Conveyor Sensor Inspect and clean Swab, cloth
10
Minutes
