Advanced High Speed Flexible Mounter
24
15 Cover Cooling Fan Inspect and clean
Flathead Screw
driver, vacuum
cleaner
10
Minutes
16 Cover Cooling Fan Filter Replace Vacuum cleaner 6 months
15
Minutes
17 Control Rack Cooling Fan Inspect and clean
Flathead Screw
driver, Vacuum
cleaner
10
Minutes
18 Head Spindle, Mirror CAM
Cleaning and apply
grease
Brush, cloth
30
Minutes
19 X Frame LM Guide, Ball Screw
Clean and inject
grease
Lubricator,
cloth
60
Minutes
20 Y Frame LM Guide
Clean and inject
grease
Lubricator,
cloth
60
Minutes
21 Y Frame Ball Screw
Clean and inject
grease
Lubricator,
cloth
20
Minutes
22 Conveyor LM Guide, Lead Screw
Cleaning, apply
grease, inject grease
Lubricator,
Brush, cloth
30
Minutes
Others 23 Cover Cleaning Alcohol, cloth
10
Minutes
Advanced High Speed Flexible Mounter
