Base gantry
Page 10 / 12 24.11.2021
Pos. Item no. Description Part marking
30 00332849-01 OVAL HEAD COUNTERSUNK SCREW
M4*35
31 00308083-01 HEXAGON SOCKET HEAD CAP
SCREW
33 00306504-01 HEXAGON SOCKET HEAD CAP
SCREW
34 00337544-01 HEXAGON SOCKET HEAD CAP
SCREW
35 00301040-01 ELASTOMER SPRING 25*10,5*50
(90 SHORE A)
SPARE PART
36 00305650-01 SLEEVE SPARE PART
37 00095142-01 HEXAGON SOCKET HEAD CAP
SCREW
38 00302449-01 HEXAGON SOCKET HEAD CAP
SCREW
39 00342519-01 BENZING U-CLIP U78
40 00845078-01 DIN912-M8 X 30-8.8
41 00095629-01 PARALLEL PIN
42 03006300-01 AIR DISTRIBUTOR, FILTER BLOCK
HS60, CPL.
SPARE PART
45 00845005-01 SOCKET HEX SCREW M2X10 DIN
912 8.8
46 00335170-02 LIMIT PROX.SWITCH1 REFER.POINT
X-AXIS
SPARE PART
47 00343441-05 INCREMENTAL SHAFT ENCODER X-
AXIS
48 00311154-01 HEXAGON SOCKET HEAD CAP
SCREW M3 X 8-8.8
49 00332977-01 INSULATING PLATE F. MOTOR
MOUNT
50 00344065S03 PCB-OPTICAL SYSTEM KST SPARE PART
51 00316823-03 LP ILLUMINATION CAMERA UP SPARE PART
53 00845016-01 HEXAGON SOCKET HEAD CAP
SCREW M3 X 12-8.8
54 00335169-02 LIMIT PROX. SWITCH 2 X-AXIS SPARE PART
56 00337763-01 HEXAGON SOCKET HEAD CAP
SCREW
57 00366932-01 X-BRAKE SPARE PART
58 00337831-01 SLIDING PAD
59 00337832-02 SPRING PLATE
Base gantry
Page 11 / 12 24.11.2021
Pos. Item no. Description Part marking
60 00341247-01 PRESSURE PLATE
61 00341243-01 COMPRESSION SPRING 1.2*6*20.5
62 03000196-01 SPRING TENSIONING SCREW
63 00322556-01 SPRING TYPE STRAIGHT PIN
64 00200656-01 HEXAGON SOCKET HEAD CAP
SCREW
65 00343146-02 STOP PLATE
66 00341646-01 COVER TAPE SPARE PART
67 00345186S01 GUIDE TROLLEY KWVE 25 H *
68 00845076-01 HEXAGON SOCKET HEAD CAP
SCREW M8 X 20-8.8
69 00346226-01 DIN912-M6 X 12-12.9 DACROMET
500
70 00805501-01 CABLE CLIP
73 03000171-01 DAMPER PCB-CAMERA
74 03001827-01 SUPPORT PLATE HS60 COMPL.
75 03001820-02 SUPPORT PLATE HS60 COMPL.
76 03001830-01 CABLE SUPPORT SPARE PART
77 03001828-01 COMBI-CABLE MOUNT COMPLETE SPARE PART
78 03001829S01 FLAT RIBBON CABLE MOUNT FCM3 SPARE PART
80 00343442-05 INCREMENTAL SHAFT ENCODER Y-
AXIS
81 00367013-02 Y-BRAKE OUTSIDE *
82 00342796-02 FRICTION BLOCK SUPPORT
83 00340871-04 FRICTION BLOCK *
84 00343372-02 SPRING PLATE
85 00340874-03 PRESSURE PLATE
86 00325384-01 COMPRESSION SPRING 1.0*6.3*18
87 00315174-01 HEXAGON SOCKET HEAD CAP
SCREW
88 00312509-01 DIN912-M3 X 12-A2-70
89 00845017-01 HEXAGON SOCKET HEAD CAP
SCREW
90 00353803-02 MOUNT FOR BRAKE *
91 03018478-01 PROXIMITY SWITCH MOUNT
97 00335137-02 LIMIT PROX.SWITCH 1 REFER.POINT
Y-AXIS
SPARE PART
