2.ヘッド(DEPH) 2.Head(DEPH) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 41 S3253T 1 SPRING ｽﾌﾟﾘﾝｸﾞ WM12-20 FE 42 H4197Z 2 BEARING ﾍﾞｱﾘﾝｸﾞ 6804ZZP-5 FE 43 H4141L 2 BE…
2.ヘッド(DEPH)
2.Head(DEPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
1 DEPH1015 1 BODY 本体 AL
2 DEPH1040 1 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ AL
3 DEPH3260 1 BKT, MOTOR BKT ﾓｰﾀ AL
4 DEPH1081 1 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ AL
5 DEPH1090 1 NUT, ROUND ﾅｯﾄ 丸 AL
6 DEPH1420 1 PLATE, STIFFENING ﾌﾟﾚｰﾄ 当て AL
7 DEPH1050 1 BKT, BALL SCREW BKT ﾎﾞｰﾙﾈｼﾞ AL
8 DEPH1063 1 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ AL
9 ADEPH8100 1 PISTON ﾋﾟｽﾄﾝ OT
10 ADEPH8400 1 PIPE, PIPING ﾊﾟｲﾌﾟ 配管 OT
12 DEPH3070 4 RETAINER 押え FE
13 DEPH3110 1 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ FE
14 DEPH3120 2 COLLAR ｶﾗｰ FE
15 DEPH3150 1 KEY, PARALLEL ｷｰ 平行 FE
16 DEPH1620 12 SPRING ｽﾌﾟﾘﾝｸﾞ FE
17 DEPH1222 1 GEAR ｷﾞﾔ FE
18 DEPH1231 1 GEAR ｷﾞﾔ FE
19 DEPH1242 1 GEAR ｷﾞﾔ FE
20 DEPH1252 1 GEAR ｷﾞﾔ FE
21 DEPH1260 1 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ FE
22 DEPH1400 1 PULLEY, MOTOR ﾌﾟｰﾘ ﾓｰﾀ AL
23 DEPH1390 1 PULLEY, TIMING ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ AL
24 DEPH1270 1 COLLAR ｶﾗｰ FE
25 DEPH1280 1 COLLAR ｶﾗｰ FE
26 DEPH1290 1 COLLAR ｶﾗｰ FE
27 DEPH1300 1 COLLAR, BEARING ｶﾗｰ ﾍﾞｱﾘﾝｸﾞ FE
28 DEPH1310 1 COLLAR, BEARING ｶﾗｰ ﾍﾞｱﾘﾝｸﾞ FE
29 DEPH1320 1 COVER, TOP ｶﾊﾞｰ ﾄｯﾌﾟ AL
30 DEPH1630 1 PUSHER ﾌﾟｯｼｬ FE
31 DEPH1340 1 SEAL ｼｰﾙ PL
32 DEPH1640 12 PIN ﾋﾟﾝ FE
33 DEPH1430 12 SPRING ｽﾌﾟﾘﾝｸﾞ FE
34 DEPH1440 12 SPRING ｽﾌﾟﾘﾝｸﾞ FE
35 DEPH1600 12 PIN ﾋﾟﾝ FE
36 DEPH1610 12 PIN ﾋﾟﾝ FE
37 DEPH1382 12 PISTON ﾋﾟｽﾄﾝ FE
38 H4044M 2 BEARING ﾍﾞｱﾘﾝｸﾞ B71809C-TPA-P4-UL FE
39 H4269H 1 BEARING ﾍﾞｱﾘﾝｸﾞ 708ATYDFC8P5 FE
40 H4519R 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 288-3GT-9 B939N1 OT
XP-141E PARTS LIST
2 - 2
2.ヘッド(DEPH)
2.Head(DEPH)
2.ヘッド(DEPH)
2.Head(DEPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
41 S3253T 1 SPRING ｽﾌﾟﾘﾝｸﾞ WM12-20 FE
42 H4197Z 2 BEARING ﾍﾞｱﾘﾝｸﾞ 6804ZZP-5 FE
43 H4141L 2 BEARING ﾍﾞｱﾘﾝｸﾞ MF-93 FE
44 H4131D 2 BEARING ﾍﾞｱﾘﾝｸﾞ 698ZZP-5 FE
45 N1025Z 1 NUT, LOCK ﾅｯﾄ ﾛｯｸ ZM20 FE
46 N1029A 1 NUT, LOCK ﾅｯﾄ ﾛｯｸ ZM45 FE
47 N1040N 2 NUT, LOCK ﾅｯﾄ ﾛｯｸ RN8 FE
48 S1047M 1 CIR-CLIP ｻｰｸﾘｯﾌﾟ E-6 FE
49 K1002C 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ UA-25C8X7 OT
50 H4130E 1
BEARING
ﾍﾞｱﾘﾝｸﾞ 608ZZ FE
51 H42253 1 BEARING ﾍﾞｱﾘﾝｸﾞ RA7008UUCSP5TS FE
52 S3011Z 2 SCRAPER ｽｸﾚｰﾊﾟ SER-4 OT
53 DEPH1020 1 SHAFT, SPLINE ｼｬﾌﾄ ｽﾌﾟﾗｲﾝ OT
54 DEPH1030 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ OT
55 SAM6720 1 MOTOR ﾓｰﾀ SGMAH-01A1A21 OT
56 SAM6711 2 MOTOR ﾓｰﾀ SGMAH-01A1A-FJ91 OT
57 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L FE
58 H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L FE
59 H5291A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X18L FE
60 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
61 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
62 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
63 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
65 W1041A
WASHER, CONICAL
ﾜｯｼｬ 皿 M-4-L FE
66 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
67 K5357H SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿
M3X5L FE
68 K5357M SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿
M3X6L FE
69 N4019A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M3X4L FE
70 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L FE
71 N1076A
NUT, HEX
ﾅｯﾄ 六角
M3 P=0.5 FE
72 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L FE
74 ADEPH8201 1 BODY 本体 OT
75 DEPH1530 1 BKT BKT FE
76 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L FE
77 H5301A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X18L FE
78 K5357M SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿
M3X6L FE
79 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
80 W10396 WASHER, FLAT ﾜｯｼｬ 平 3M/MX0.5X6 FE
81 H2093A 1 PIN, PARALLEL ﾋﾟﾝ 平行 4ﾟX8 M6 FE
XP-141E PARTS LIST
2 - 3
2.ヘッド(DEPH)
2.Head(DEPH)
2.ヘッド(DEPH)
2.Head(DEPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
82 DEPH1590 1 SEAL ｼｰﾙ PL
83 DEPH1460 1 COLLAR ｶﾗｰ FE
84 DEPH1410 1 WASHER ﾜｯｼｬ FE
85 DEPH1500 1 COLLAR ｶﾗｰ CO
86 S4040X 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX306-W2A OT
87 DBPH0150 2 BLOCK 駒 CO
88 DEPH1560 24 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟｰ FE
89 DEPH1570 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ FE
90 DEPH1580 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ FE
91 DEPH1511 1 BKT, PIPE BKT ﾊﾟｲﾌﾟ AL
92 DEPH1521 1 BKT, MANIFOLD BKT ﾏﾆﾎｰﾙﾄﾞ AL
93 A5133A 1 O RING Oﾘﾝｸﾞ S11.2 OT
94 H5287A BOLT, HEX SOKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
95 N2034A 2 NIPPLE, GREASE ﾆｯﾌﾟﾙ ｸﾞﾘｽ GP-AM-6 OT
96 H5326A BOLT, HEX SOKET ﾎﾞﾙﾄ 六角穴 M6X25L FE
97 W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H FE
98 N1085A 2
NUT, HEX
ﾅｯﾄ 六角 M6 P=1.0 FE
99 W1013A 2 WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H FE
100 A5178Z 24 O RING Oﾘﾝｸﾞ SS2.5(ﾌｯ素ｺﾞﾑ) . OT
XP-141E PARTS LIST
2 - 4
