6.1.コンベア(DEQC) 6.1.Conveyor(DEQC) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 82 H4445A 6 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1050ZZ FE 83 H4440A 8 BEARING, MINIA…

100%1 / 66
6.1.コンベア(DEQC)
6.1.Conveyor(DEQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
40 DEQC0510 1 BKT BKT FE
41 DEQC0520 1 SHAFT ｼｬﾌﾄ FE
42 DEQC0530 1 COVER ｶﾊﾞｰ FE
43 DEQC0560 1 BKT BKT FE
44 DEQC0570 1 BKT BKT FE
45 DEQC0580 1 BKT BKT FE
46 DEQC0590 1 BKT BKT FE
47 DEQC0600 1 PLATE ﾌﾟﾚｰﾄ FE
48 DEQC0610 2 PLATE ﾌﾟﾚｰﾄ FE
49 DEQC0620 1 PLATE ﾌﾟﾚｰﾄ FE
50 DEQC0630 1 PLATE ﾌﾟﾚｰﾄ FE
51 DEQC0640 1 PLATE ﾌﾟﾚｰﾄ FE
52 DEQC0650 1 PLATE ﾌﾟﾚｰﾄ FE
53 DEQC0660 1 PLATE ﾌﾟﾚｰﾄ FE
54 DEQC0291 1 BLOCK, JIG ﾌﾞﾛｯｸ 治具 FE
55 DEQC0020 2 GUIDE ｶﾞｲﾄﾞ SSR15WUUC1+390L-Ⅳ OT
56 DEQC0030 2 GUIDE ｶﾞｲﾄﾞ SSR15WUUC1+360L-Ⅳ OT
57 DEQC0070 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ OT
58 DEQC0480 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ BKT1404CSZZ+445.5LC OT
59 DEQC0160 1 COLLAR ｶﾗｰ FE
60 DBPP0350 3 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ FE
61 DBPP0480 2 NUT ﾅｯﾄ FE
63 BHPP1790 4 PULLEY ASSY ﾌﾟｰﾘ ASSY OT
64 BHPP1800 6 PULLEY ASSY ﾌﾟｰﾘ ASSY OT
66 PPT1531 4 PIN, ECCENTRIC ﾋﾟﾝ 偏心 FE
68 GVC0141 5 COLLAR ｶﾗｰ
69 GVC0350 3 COLLAR ｶﾗｰ FE
70 CLN8690 2 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25 13T-2型 追加工 OT
71 IQC5440 1 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ FE
72 IQC5750 1 COLLAR ｶﾗｰ FE
73 IQC5760 1 COLLAR ｶﾗｰ FE
74 BHPP1160 1 SHAFT ｼｬﾌﾄ FE
75 BHPP1210 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ FE
76 BHPP1260 1 COLLAR ｶﾗｰ FE
77 BHPP1080 1 HOLDER ﾎﾙﾀﾞ FE
78 DBPP0330 1 HOLDER ﾎﾙﾀﾞ FE
79 BHPP1810 1 PULLEY ﾌﾟｰﾘ FE
80 K5337G 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS1201F-M5-04 OT
81 S2126L 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CXSM10-K6869-35 OT
XP-141E PARTS LIST
6 - 3
6.1.コンベア(DEQC)
6.1.Conveyor(DEQC)
6.1.コンベア(DEQC)
6.1.Conveyor(DEQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
82 H4445A 6
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1050ZZ FE
83 H4440A 8
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1910ZZ FE
84 S1022A 3
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-4 FE
85 S3034A 3 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 2-Type OT
86 H4123A 2
BEARING
ﾍﾞｱﾘﾝｸﾞ UFL000 FE
87 S3033A 2 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 1-Type OT
88 H4451A 2
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1680ZZ FE
90 N1020C 1
NUT, FINE U
ﾅｯﾄ ﾌｧｲﾝU FU00 FE
91 S3020T 4
SPRING
ｽﾌﾟﾘﾝｸﾞ WF5-30 FE
93 T2010T 1 CHAIN ﾁｪｰﾝ RS25NP 47LINKﾂｷﾞﾃﾘﾝｸﾂｷ OT
94 T2138T 1 CHAIN ﾁｪｰﾝ RS25NP 42LINKﾂｷﾞﾃﾘﾝｸﾂｷ OT
95 M5006E 2 MOTOR ﾓｰﾀ AXHM230K-GFHK11 OT
96 DEQC0760 2 CYLINDER ｼﾘﾝﾀﾞ CXSL10-R7789-2 OT
97 K11384 1
COLLAR
ｶﾗｰ SRW8 OT
98 H2057A 1
PIN, SPRING
ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 4ﾟX15 FE
99 S1003A 1
CIR-CLIP
ｻｰｸﾘｯﾌﾟ RTW19 FE
100 H4104A 2
BEARING
ﾍﾞｱﾘﾝｸﾞ A-2520 FE
101 S1046A 1
CIR-CLIP
ｻｰｸﾘｯﾌﾟ WR19 FE
102 DEQC0410 1 BKT, SENSOR BKT ｾﾝｻ FE
103 DEQC0420 1 BKT, SENSOR BKT ｾﾝｻ FE
104 S40321 4 SENSOR ｾﾝｻ DL-S4R OT
105 DEQC0200 1 BKT, SENSOR BKT ｾﾝｻ FE
106 H5273T
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X4L FE
108 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X6L FE
109 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X8L FE
110 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X10L FE
111 H5277A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X12L FE
112 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X8L FE
113 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X10L FE
114 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X12L FE
115 H5291A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X18L FE
118 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X10L FE
119 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X12L FE
120 H5296Y BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X95L FE
121 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X12L FE
122 H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L FE
123 H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X18L FE
124 H5326A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X25L FE
125 H5361A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M10X30L FE
XP-141E PARTS LIST
6 - 4
6.1.コンベア(DEQC)
6.1.Conveyor(DEQC)
6 - 7
6.2.コンベア (DEQC)
6.2.Conveyor (DEQC)
6.2.Conveyor (DEQC)
6.2.コンベア (DEQC)
XP-141E PARTS LIST
Ref.33-7
Ref.31-1
Ref.31-1
Ref.31-1
Ref.31-1
0.5 1 2 10
ﾀﾃx173.205
87
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
x10
112
127
127
146
131
109
126
130
130
126
109
140
140
104
102
118
128
131
127
114
105
104
104
103
42
G
Z
93
94
80
34
80
81
27
140
111
136
158
46
127
114
56
111
136
125
129
122
164
165
127
183
129
121
129
122
162
44
52
45
127
114
111
43
136
125
129
121
86
127
114
138
127
155
120
4
124
135
182
132
149
149
161
127
114
127
114
137
127
115
148
128
154
141
138
59
114
133
60
68
138
170
150
87
133
113
60
68
138
168
159
160
127
112
122
128
152
135
119
128
40
129
128
154
141
157
135
122
129
184
123
151
134
113
133
83
60
35
185
127
115
127
114
135
122
129
122
78
6
Z
G
95
166
88
88
82
82
41
84
69
85
39
82
84
69
82
85
70
53
C
C
E
A
F
B
38
70
83
68
68
8
5
7
10
11
12
12
98
75
83
74
76
83
99
77
71
100
73
100
72
101
79
14
13
83
83
97
85
82
82
69
84
9
86
83
68
83
90
95
127
147
129
153
155
167
62
F
E
D
A
D
B
Y
Y
Y
3
36
57
58
56
55
55
37
1
2
109
126
130
172
112
127
131
118
128
176
131
127
114
174
130
173
126
109
175
81
182
132
Right to Left Board Flow
180
Vacuum Back Up Pins
(Option)
