Glue unit G2
Page 17 / 19 18.11.2021
Pos. Item no. Description Part marking
64 00312612-01 KNURLED NUT
65 00316398-01 COMPRESSION SPRING
66 00303551S01 CLAMP RING PK3 SPARE PART
67 00303552S01 COLLET CHUCK SPARE PART
68 00303553S01 O-RING 4*1,5 NBR 62 WEAR PART
69 00312722-01 COMPRESSION SPRING
70 00325254-01 SLEEVE FOR Z-AXIS 10ML
00325197-01 PROXIMITY SWITCH ACTUATOR
72 00307137-03 HOLDER
73 00305903S01 PNEUMATIC CONTROLLER UNIT
SIPLACE 80K
74 00305310-07 PNEUMATIC SYSTEM
75 00306745-02 EVACUATION OF AIR VALVE
76 00306744-02 SOLENOID VALVE: DOSAGE
00319041-01 DUMMY PLUG
78 00305574-06 VALVE FIXING
79 00305456-01 SEALING RING PVC HARD
80 00305562-06 BANJO BOLT
00306398-01 SEALING SPECIAL ORDER
82 00306400-01 COVER
00306401-01 WASHER
00315630S01 O-RING 2X1 NBR 55
85 00318269-01 DISTANCE BOLT
86 00309916-01 NYLON SEALING WASHER
87 00305286-01 QUICK-RELEASE FASTENER
88 00306797-06 CONVERSION PCB ADHESIVE
APPLICATION HEAD
89 00301682-02 SLIDE UNIT
90 00301187-01 CASTING ANGLE
91 00301706-01 SYNCHRONIZING DISK AL 14
T2,5/14-0
92 00323371-03 SPHERICAL ROTATING LINER
93 00305507-01 DRAG ANGLE
94 00301204-01 TOOTHEDBELT SYNCHROFLEX 12 T
2,5/330
96 00301209-01 SHAFT
Glue unit G2
Page 18 / 19 18.11.2021
Pos. Item no. Description Part marking
97 00301223-01 DEEP GROOVE BALL BEARING MINI
98 00301708-01 SYNCHRONIZING DISK
99 00301225-01 DEEP GROOVE BALL BEARING
100 00318239-02 MOTOR UNIT KX-AXIS
101 00306767-01 CABLE:CONVERSION BOARD
102 00301683-01 DRAG ANGLE
103 00301684-01 DISTANCE DISK
104 00301687-01 ELASTOMER SPRING DRM 10 (90
SHORE A)
105 00301688-02 HOLDER
00318545-01 ELASTOMER SPRING DRM 10 (90
SHORE A)
107 00311731-02 SWITCH PLATE
108 00318344-02 MOTOR UNIT KY-AXIS
109 00306768-02 CABLE:CONVERSION BOARD
111 00317591-02 DISTANCE BOLT
112 00307576-03 SHEET
113 00307583-03 SHEET
115 00306920-07 CONVERSION-BOARD SMALL AXIS
116 00319471-03 PROCESSOR BOARD
00318218-01 HANDLE G2
117 00305971-05 CASTING FLANGE
118 00313783-01 FLAT RIBBON HOLDER
119 00320902-01 SPACER FOR NOZZLE TAPERED 0,1
*S=00346996-01
120 00320903-01 SPACER FOR NOZZLE TAPERED
0,15 *S=00346997-01
121 00320904-01 SPACER FOR NOZZLE TAPERED 0,2
*S=00346998-01
122 00320905-01 SPACER FOR NOZZLE TAPERED
0,25 *S=00346999-01
123 00320906-01 SPACER FOR NOZZLE TAPERED 0,3
*S=00347000-01
124 00320895-01 NOZZLE TAPERED 0,3MM
125 00320897-01 NOZZLE TAPERED 0,44MM
126 00320900-01 NOZZLE TAPERED 0,6
127 00320907-01 LOCK WASHER FOR SPACER
Glue unit G2
Page 19 / 19 18.11.2021
Pos. Item no. Description Part marking
128 00306743S02 HEAT EXCHANGER - G2 - 10ML
129 00305554-06 APPLICATOR SPACER 0,10
130 00305555-06 APPLICATOR SPACER 0,15
131 00305556-06 APPLICATOR SPACER 0,20
132 00305557-06 APPLICATOR SPACER 0,25
133 00305558-06 APPLICATOR SPACER 0,30
134 00317870-01 DOSAGE NOZZLE ALU 0,30 PTFE-
COATED
135 00317871-01 DOSAGE NOZZLE ALU 0,44 PTFE-
COATED
136 00317872-01 KLEB 2 DOSAGE NOZZLE ALU 0,6
137 00306921-02 PORTAL CABLE
138 00310091-02 CABLE: CONVERSION BOARD
ADHESIVE APPLICATION HEAD
139 00310092-03 CABLE:CONVERSION BOARD-GLUE
HEA D
140 00304101-03 PCB-COVER PLEXIGLAS _
141 00332567-01 HEAT EXCHANGER
