SIPLACE 80S-20/F4/F4-6/F5 Serv ice Manual 1 Operational Safety Edition 04/98 1.1 Information on safety 1 - 7 1.1.6 Safety instr uctions for the coplanarity laser module DANGER Y o u must not make a ny mod ificati ons wha…
SIPLACE 80S-20/F4/F4-6/F5 Service Manual 1 Operational Safety
Edition 04/98 1.1 Information on safety
1 - 7
1.1.6 Safety instructions for the coplanarity laser module
DANGER
You must not make any modifications whatsoever to or tamper with the safety features or coplanarity laser
module (see Fig. 1.1.2).
The coplanarity laser module - without safety
features - corresponds to Laser class 3B (see
Fig. 1.1.3
)
This means danger to eyes and skin!
For this reason the safety features
should under no circumstances
be
circumvented.
Fig. 1.1.3 Identification label for Laser class 3B
To enable the laser module in Laser class 1 to be operated with no danger to eyes and skin the following
safety features have been installed in the machine:
The interlock line is connected in series with the
switches for the protective cover. Even if the
key-operated switch is used to circumvent the
protective devices this particular protective fea-
ture will not be disabled. This means that the
laser module can be operated only within the
closed machine.
Fig. 1.1.4 Identification label for Laser class 1
DANGER
In the event of any modifications or tampering with the module the factory safety warranty will be rendered null
and void. In addition, the user shall be obliged to comply with the guidelines of the Union of Employers’ Liabil-
ity Insurance Associations [Hauptverband der Berufsgenossenschaften] -VBG 93. In other words:
- Registration with the liability insurance association
- Appointment of a laser safety officer
- Drawing up guidelines for the use of the module
K
INVISIBLE LASER RADIATION
DO NOT EXPOSE TO BEAM
LASER CLASS 3 B
1MW MAX., 670 NM;
AS PER IEC 825-1(1993)
LASER CLASS 1
1 Operational Safety SIPLACE 80S-20/F4/F4-6/F5 Service Manual
1.1 Information on safety Edition 04/98
1 - 8
The illustration below shows the location of the safety information for operating the coplanarity laser module of
the SIPLACE 80F
4
, 80F
4
-6 or 80F
5
. This information must be glued onto the cover in the places which are
indicated by arrows so that it is clearly visible (see Fig. 1.1.5
).
Fig. 1.1.5 Safety instructions on the SIPLACE 80F
4
/ F
4
-6 / F
5
.H\WR )LJ
Caution
Invisible laser radiation if the cover is opened
and safety interlock is bypassed
Do not stand in front of the beam
LASER CLASS 1
1
2
