13 6-Segment Revolver Head (8000) SIPLACE 80S-20/F4 Service Manual
13.5 Z Axis Unit Edition 07/97
13 - 20
13.5 Z Axis Unit
13.5.1 Replacing the ’Z Axis Top’ Sensor
PLEASE NOTE
This work may only be carried out by Siemens service technicians or by the customer’s appropriately trained
personnel.
Spare parts
Positioning unit, from item no. 00321213S02
● Disconnect plug-in connection X10 from distributor board.
● Undo the two recessed-head screws (M2 x 5) and remove the ribbon cable holders.
● Undo the two slotted head screws (M1.6 x 4) and remove the ’z sensor top’ board (see Fig. 13.5.1).
● When re-installing, proceed in the reverse sequence of operations.
● Carry out z-axis zero point correction again (see section 13.5.3).
NOTE
When you fit the ribbon cable holder make sure that you do not pinch the cables.
13.5.2 Replacing the Motor for the Z Axis
PLEASE NOTE
This work may only be carried out by Siemens service technicians or by the customer’s appropriately trained
personnel.
Spare parts
Motor z axis, from item no. 00319891S01
Test equipment
Belt tension measuring device TSM, from item no. 00326015-01
’Measure Belt Tension’ Instructions
● Disconnect plug-in connections X3 and X4 from the distributor board.
● Undo the four hexagon socket head screws (3 x M3 x 5, see pos. 2 Fig. 13.5.1) and 1 M4 x 10 at the motor
mounting (see pos. 6, Fig. 13.5.1).
SIPLACE 80S-20/F4 Service Manual 13 6-Segment Revolver Head (8000)
Edition 07/97 13.5 Z Axis Unit
13 - 21
● Carefully pull the motor to the rear and away.
● To reinstall proceed in the reverse sequence of operations.
CAUTION ∆
!
∆
!
When fitting the z motor, make sure that the toothed belt is correctly seated on the motor pinion.
Adjustment work
● Using the belt tension measuring device, check the belt tension in accordance with the values specified
below:
13.5.3 Recording the Zero Point Correction for the Revolver Head
ZAxis
● Sitest menu → Axes → Z axis → Modify axis data → Positions → Zero point correction.
● Type 0 into the zero point correction line and carry out a reference run with the axis.
● Disable the z axis and move it upwards by hand by the toothed belt.
● Hold the z axis firmly in its top position.
● Sitest menu → Axes → Star axis → Move axis.
● Position the star axis at 21500 ± 2500 digits.
● Sitest menu → Axes → Z axis → Read actual position.
● Press the z axis lightly with your hand against the upper stop. Read off the actual position and make a note
of it.
● Now press the z axis lightly by hand against the lower stop. Once again read off and note down the actual
position.
● Calculate the average of these two values (zero point correction) (X1 + X2) / 2.
● Sitest menu → Axes → Z axis → Modify axis data → Positions → Zero point correction.
● Type in the new zero point correction value.
● Carry out a reference run with the star axis.
● Switch the z axis back on and carry out a reference run with it.
● Check the upper and lower stop once again. Both values should approx. be the same.
● Sitest menu → Store MA file → AXMA.DAT.
Prior to continuous operation
frequency (Hz)
After continuous operation
frequency (Hz)
Z axis toothed belt 185 ± 10 185 ± 10
13 6-Segment Revolver Head (8000) SIPLACE 80S-20/F4 Service Manual
13.5 Z Axis Unit Edition 07/97
13 - 22
13.5.4 Replacing the Toothed Belt for the Z Axis
PLEASE NOTE
This work may only be carried out by Siemens service technicians or by the customer’s appropriately trained
personnel.
Spare parts
Toothed belt Synchroflex 8AT3/201, from item no. 00320001-01
Test equipment
Belt tension measuring device TSM, from item no. 00326015-01
’Measure Belt Tension’ Instructions
Gauge for z axis, from item no. 00331308-01
● Undo the two hexagon socket screws (M2.5 x 8) and remove the toothed belt fastening (see Fig. 13.5.1,
Pos. 5).
● Undo the four hexagon socket screws (M3 x 5) of the motor mounting (see Fig. 13.5.1, Pos. 5).
● Position the new toothed belt over the motor pinion and the counterbearing.
ATTENTION ∆
!
∆
!
When you fit the toothed belt holder make sure that you position the belt correctly on the motor pinion.
● When installing, proceed in the reverse sequence of operations.
Adjustment work
● Remove the front part of the placement head (see section 13.1.6, page 13 - 6).
● Using the belt tension measuring device, check the belt tension in accordance with the values specified
below:
● Using your fingers lift the z axis a little and insert the z-axis gauge in pos. (A) in the bearing race
(see pos. 8, Fig. 13.5.1, page 13 - 24).
The z axis is located 0.3 mm above the bearing race.
● Adjust the upper stop (pos. 7) in a way, that it will touch the toothed belt fastening (pos. 5).
● Fit the front part of the placement head (see section 13.1.6, page 13 - 6).
● Determine the zero point correction value for the z axis (see section 13.5.3, page 13 - 21).
PLEASE NOTE
After installing the placement head, determine the star zero point correction as described in section 13.6.3.
Prior to continuous operation
frequency (Hz)
After continuous operation
frequency (Hz)
Z-axis toothed belt of
revolver head
185 ± 10 185 ± 10
