YSP20_KKX_pl - 第15页
33 31 19 20 13 6 37 2 2 43 23 30 43 3 10 6 18 32 10 3 43 6 19 15 5 22 8 10 15 19 7 11 15 10 34 29 42 9 15 35 43 12 4 17 10 26 40 12 41 7 10 28 16 23 40 14 25 12 27 39 38 41 21 40 39 36 24 1 1 Shutter Cover KKX-131 1 2-6 …
14
11
5
18
2
16
3
3
8
6
1
7
1
6
20
19
3
4
9
18
5
8
2
10
12
17
20
3
19
12
15
14
11
5
18
2
16
3
3
8
6
1
7
1
6
20
19
3
4
9
18
5
8
2
10
12
17
20
3
19
12
15
Cover Side
Cover
KKX-1305
2-5
OLD
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90990-12J002
SCREW, BIN. HEAD W/W
18
2
90990-12J003
SCREW, BIN. HEAD W/W
4
3
90990-31J006
BOLT, SHOULDER
4
4
91312-05012
BOLT HEX,SOCKET HEAD
2
5
95307-06600
NUT HEXAGON
2
6
95702-04500
NUT FLANGE
10
7
K46-M1374-11
HINGE 2
3
7-1
K46-M1374-12
HINGE 2
1
OK
MK20039-2013/2/13
8
KGS-M1348-00
GAS SPRING
2
9
KGS-M1360-00
BOLT
2
10
KH2-M1324-01
GRIP
1
11
KKX-M1361-00
BRKT.,DOOR 1
1
11-1
KKX-M1361-00
BRKT.,DOOR 1
1
OK
MJ60115-2012/6/25
12
KKX-M13F1-00
FRAME,SIDE COVER
1
12-1
KKX-M13F1-01
FRAME,SIDE COVER
1
NG
MLX0082-2014/12/16
14
KKX-M13F2-00
PANEL,DOOR
1
15
KKX-M13F3-00
COVER,SIDE DOOR 1
1
16
KKX-M13F3-50
COVER,SIDE DOOR 2
1
17
KL0-M1374-00
PLATE 1, SCHMEASAL
1
18
KM0-M1331-01
BRACKET, GAS DAMPER
2
19
KV5-M1130-00
CATCH MG.
2
20
98902-03005
SCREW BINDING HEAD
4
33
31
19
20
13
6
37
2
2
43
23
30
43
3
10
6
18
32
10
3
43
6
19
15
5
22
8
10
15
19
7
11
15
10
34
29
42
9
15
35
43
12
4
17
10
26
40
12
41
7
10
28
16
23
40
14
25
12
27
39
38
41
21
40
39
36
24
1
1
Shutter
Cover
KKX-1311
2-6
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$SSF4-M5-A-P
JOINT
4
2
KKX-M13L3-A0
LINK A ASSY.
2
3
KKX-M13L3-B0
LINK B ASSY.
2
4
90933-02J063
SPACER
2
5
95302-06600
NUT HEXAGON
2
6
91312-03006
BOLT HEX,SOCKET HEAD
12
7
91312-04006
BOLT HEX,SOCKET HEAD
8
8
91312-04008
BOLT HEX,SOCKET HEAD
8
9
91312-04010
BOLT HEX,SOCKET HEAD
2
10
91312-04012
BOLT HEX,SOCKET HEAD
24
11
92902-04200
WASHER,PLAIN
4
12
95302-04600
NUT HEXAGON
6
13
KHT-M9457-10
POST
2
14
KHW-M916H-00
JOINT, CYL.
2
15
KHW-M9265-00
SPACER
8
16
KHW-M926B-00
COLLAR, JOINT
2
17
KHW-M926E-00
NUT
2
18
KKX-M13L1-00
PLATE,SHUTTER 1
1
19
KKX-M13L2-00
GUIDE
6
20
KKX-M13L5-00
PLATE,SHUTTER 2
1
21
KKX-M13L6-00
PLATE,SHUTTER 3
1
22
KKX-M13L7-00
PLATE,SHUTTER 4
1
23
KKX-M13L8-00
PLATE,LINK 1
4
24
KKX-M13L9-00
PLATE,SHUTTER 5
2
25
KKX-M13LA-00
PLATE,SHUTTER 6
2
26
KKX-M13LB-00
PLATE,LINK 2
2
27
KKX-M13LC-00
PLATE,LINK 3
2
28
KKX-M13LD-00
BRKT.,CYLINDER
2
29
KKX-M13LE-00
BRKT.,SENSOR
2
30
KKX-M13LF-00
COVER,SHUTTER 1
1
31
KKX-M13LG-00
COVER,SHUTTER 2
1
32
KKX-M13LH-00
COVER,SHUTTER 3
1
33
KKX-M13LJ-00
COVER,SHUTTER 4
1
34
KKX-M654A-00
SENSOR
2
35
KKX-M9166-00
POST
2
36
KKX-M9258-00
CYLINDER
2
37
KKX-M925C-00
SPRING
2
38
KV7-M926C-01
STOPPER, CYLINDER
2
39
98707-03006
SCREW,FLAT HEAD
16
40
98902-03004
SCREW BINDING HEAD
12
41
98902-03006
SCREW BINDING HEAD
8
42
98902-03008
SCREW BINDING HEAD
2
43
98907-04006
SCREW BINDING HEAD
8
23
41
8
42
1
10
6
29
34
4
24
21
14
19
30
14
37
38
12
42
16
43
35
5
37
11
2
44
7
28
32
6
33
17
15
31
17
39
25
27
9
13
26
22
39
36
18
3
33
40
20
36
SZ-Load Cell
Moving-axis
KKX-1305
3-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90990-26J002
BEARING
1
2
90990-28J092
WASHER,PLAIN
1
3
90990-28J156
WASHER,PLAIN
2
4
90K63-331447
AC SERVO MOTOR
1
5
91312-04008
BOLT HEX,SOCKET HEAD
4
6
91312-04010
BOLT HEX,SOCKET HEAD
6
7
91312-04012
BOLT HEX,SOCKET HEAD
1
8
91312-04016
BOLT HEX,SOCKET HEAD
4
9
91312-04025
BOLT HEX,SOCKET HEAD
8
10
KG2-M9173-00
LOCK NUT
1
11
KG7-M9111-01
PULLEY 1
1
12
KGJ-M3159-01
PLATE R, BRG.
1
13
KGJ-M3169-00
DAMPER,R
2
14
KGY-M7152-00
SPACER,L.C.
2
15
KHT-M2207-00
SHAFT,SPRING
2
16
KHT-M2210-00
PLATE 2,SZ AXIS
1
17
KHT-M2212-00
SPRING,SZ
4
18
KHT-M2213-00
DAMPER,SZ
2
19
KHT-M2217-00
HOLDER,BRG.
1
20
KHT-M2245-00
HOLDER BRKT.2,SHAFT
1
21
KHT-M6533-A0
LOAD CELL ASSY
1
22
KHT-M7531-00
COLLAR
2
22-1
90990-41J156
COLLAR
2
OK
MJY0091-2013/2/14
23
KHT-M9D00-02
BALL SCREW,SZ
1
24
KKX-M2203-00
PLATE,SZ 1
1
25
KKX-M2204-00
PLATE,SZ 2
1
26
KKX-M2207-00
BUSH
2
27
KKX-M2208-00
SHAFT,BUSH
2
28
KKX-M2209-00
BELT,SZ
1
29
KKX-M2210-00
DAMPER,SZ
2
30
KKX-M2219-00
PLATE,SZ MOTOR
1
31
KKX-M2225-00
HOLDER,SPRING
2
32
KKX-M2228-00
BRKT.,HNS.
1
33
KKX-M2230-00
HOLDER,SPRING
4
34
KKX-M2251-00
PLATE,LC
1
35
KV7-M9205-01
PULLEY 1:P22-3GT
1
36
91312-05012
BOLT HEX,SOCKET HEAD
10
37
91312-05014
BOLT HEX,SOCKET HEAD
7
38
91312-05016
BOLT HEX,SOCKET HEAD
2
39
91312-05020
BOLT HEX,SOCKET HEAD
6
40
91312-06012
BOLT HEX,SOCKET HEAD
2
41
91312-06014
BOLT HEX,SOCKET HEAD
2
42
91312-06025
BOLT HEX,SOCKET HEAD
4
43
92902-05200
WASHER,PLAIN
3
44
92A08-04306
SCREW SET
2
