YSP20_KKX_pl - 第44页
5 12 11 13 2 12 14 1 8 9 7 10 3 6 4 8 PCB Camera Camera KKX-1305 7-1 OLD NO Parts_No. Parts_Name Q_ty Remarks Compati Revision_No._date 1 91312-04020 BOL T HEX,SOCKET HEAD 2 2 91312-05010 BOL T HEX,SOCKET HEAD 2 3 91312-…
18
3
14
1
16
2
3
4
9
9
7
7
6
6
5
5
15
10
3
8
9
11
3
17
7
12
6
13
4
5
8
9
7
12
6
11
5
10
Duct
MZ Axis
KKX-1208
6-7
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-2N
NYLON CLIP
54
2
90990-11J003
SCREW, PAN HEAD W/W
54
3
91312-05012
BOLT HEX,SOCKET HEAD
8
4
91312-06016
BOLT HEX,SOCKET HEAD
4
5
98702-05010
SCREW FLAT HEAD
8
6
98902-03004
SCREW BINDING HEAD
8
7
KGY-M2475-00
PLATE,NUT CY
4
8
KHT-M2617-00
CABLE DUCT,SY
2
9
KHT-M2623-00
BRACKET,TAPE
4
10
KHT-M2624-00
TAPE 1,SY DUCT
2
11
KHT-M2625-00
TAPE 2,SY DUCT
2
12
KHT-M2626-00
TAPE 3,SY DUCT
2
13
KKX-M2161-00
BRKT.,MY DUCT 1
1
14
KKX-M2161-50
BRKT.,MY DUCT 1
1
15
KKX-M2162-00
BRKT.,MY DUCT 2
1
16
KKX-M2162-50
BRKT.,MY DUCT 2
1
17
KKX-M2163-00
BRKT.,HNS
1
18
KKX-M2163-50
BRKT.,HNS
1
5
12
11
13
2
12
14
1
8
9
7
10
3
6
4
8
PCB Camera
Camera
KKX-1305
7-1
OLD
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
91312-04020
BOLT HEX,SOCKET HEAD
2
2
91312-05010
BOLT HEX,SOCKET HEAD
2
3
91312-05016
BOLT HEX,SOCKET HEAD
2
4
91312-05035
BOLT HEX,SOCKET HEAD
3
4-1
_
1
Delete
MK40082-2013/4/17
5
KHN-M7600-00
FIDUCIAL LIGHT ASSY
1
6
KJX-M7210-00
CCD CAMERA
1
7
KKX-M7801-A0
LENS HOLDER ASSY.
1
8
KKX-M7802-00
HOLDER,LIGHT
1
8-1
KKX-M7802-01
HOLDER,LIGHT
1
NG
MK40082-2013/4/17
9
KKX-M7803-00
BRKT.,HNS.
1
9-1
KKX-M7803-01
BRKT.,HNS.
1
OK
MK40082-2013/4/17
10
KKX-M7804-00
LENS
1
11
90990-28J026
WASHER,PLAIN
2
MK40082-2013/4/17
12
91312-05020
BOLT HEX,SOCKET HEAD
4
NG
MK40082-2013/4/17
13
KKX-M7805-01
PLATE,LIGHT
1
MK40082-2013/4/17
14
KKX-M7810-00
CAMERA ASSY
1
MJ30057-2012/3/14
15
14
12
16
10
8
5
5
6
7
13
6
11
1
3
9
4
2
15
14
12
16
10
8
5
5
6
7
13
6
11
1
3
9
4
2
Mask camera
camera
KKX-1305
7-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
4
2
KHT-M76A0-00
FIDUCIAL LIGHT ASSY
2
3
90990-11J003
SCREW, PAN HEAD W/W
4
4
91312-05025
BOLT HEX,SOCKET HEAD
4
5
91312-05035
BOLT HEX,SOCKET HEAD
8
6
98902-04006
SCREW BINDING HEAD
6
7
99480-05014
PIN,PARALLEL
4
8
KHT-M76B0-00
LENS FID.
2
9
KHT-M7802-00
SATY,FID.LIGHT
2
10
KJX-M7210-10
CCD CAMERA
2
11
KKX-M7601-00
HOLDER,CAMERA
1
12
KKX-M7601-50
HOLDER,CAMERA
1
13
KKX-M7602-00
BRKT.,HNS.
2
14
KKX-M7600-00
MASK CAMERA1 ASSY.
1
15
KKX-M7600-50
MASK CAMERA2 ASSY.
1
16
KKX-M7610-00
CAMERA ASSY
1
MJ30057-2012/3/14
