YSP20_KKX_pl - 第6页
Contents 11. Exterio etc. Section …
43
45
11
43
17
26
47
28
2
20
19
22
16
34
17
37
16
13
24
35
12
43
15
27
24
39
12
25
16
36
11
14
8
4
32
43
22
40
46
37
44
10
13
19
7
5
6
43
7
10
41
7
23
30
1
5
40
9
33
6
40
38
7
31
20
41
16
29
8
21
18
42
3
Blower
Base
KKX-1305
1-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$SC4-M5A
SPEED CONTROLLER
2
2
$TL4-M5
JOINT
3
3
90112-10J025
BOLT,HEX. SOCKET HEAD
4
4
90990-12J001
SCREW, BIN. HEAD W/W
4
5
90990-28J147
WASHER,PLAIN
3
6
90990-28J148
WASHER,PLAIN
3
7
90990-28J149
WASHER,PLAIN
6
8
91312-04008
BOLT HEX,SOCKET HEAD
14
9
91312-04014
BOLT HEX,SOCKET HEAD
8
10
91312-04018
BOLT HEX,SOCKET HEAD
3
11
91312-05008
BOLT HEX,SOCKET HEAD
6
12
91312-05010
BOLT HEX,SOCKET HEAD
4
13
91312-05012
BOLT HEX,SOCKET HEAD
4
14
KGY-M3703-20
ANTI VIB. RUBBER
4
15
KGY-M3710-40
INL. FILTER ELEMENT
1
16
KGY-M3730-00
TUBE 25, BAND
4
17
KHT-M3704-00
PLATE
2
18
KHT-M3731-00
BLOWER
1
19
98702-05010
SCREW FLAT HEAD
6
20
KKX-M3674-01
TUBE 25
2
20-1
KKX-M3674-02
TUBE 25
2
OK
MK30038-2013/3/22
21
KKX-M3675-10
CYLINDER,CL UP
2
22
KKX-M3673-00
GUIDE,HOSE
2
23
KKX-M3702-00
DUCT,AIR
1
24
KKX-M3703-00
JOINT,TUBE
2
25
KKX-M3706-00
STAY,TUBE
1
26
KKX-M3713-00
COVER,FILTER BOX
1
27
KKX-M3714-00
GASKET
1
28
KKX-M3715-00
JOINT,TUBE
2
29
KKX-M3718-00
BRKT.2,CYL.
1
30
KKX-M3745-00
BRKT.,CYL.
2
31
KKX-M3747-10
CYL.,VALVE
4
32
KKX-M3749-00
TUBE 38
1
33
$TL4-M5
JOINT
1
34
KKX-M3750-00
TUBE 38
1
35
KKX-M3751-00
TUBE 38
1
36
KKX-M3752-00
TUBE 38
1
37
KKX-M3761-00
BAND,TUBE
2
38
KKX-M653P-00
SENS.BV1 CLOSE ASSY
1
39
KKX-M653P-10
SENS.BV2 CLOSE ASSY
1
40
91312-06012
BOLT HEX,SOCKET HEAD
8
41
92012-05016
BOLT BUTTON HEAD
12
42
92907-10100
WASHER, SPRING
4
43
KW3-M3690-00
TUBE BAND
7
44
91312-04008
BOLT HEX,SOCKET HEAD
8
45
KKX-M3717-00
BOX,AIR FILTER 2
2
46
KKX-M3725-00
GASKET,BOX
2
47
KH1-M1396-00
WASHER
4
