MODEL TCM-3100J-2
0108-001
127
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
6-2
1 630 053 1954 BASE 1 659J--03B-002
2 630 053 2197 PLATE 1 659J--03B-025
2 -1 630 053 2180 PLATE 1 659J--03B-024
3 411 141 4008 WASHER V 4X9X0.8 4 FW4
4 411 141 2905 WASHER SPR 4 4 SW4
5 630 000 7626 BOLT,HEX-SCT 4 M4X10
6 630 053 2128 BRACKET 1 659J--03B-018
7 630 053 2111 BRACKET 1 659J--03B-017
9 630 000 0252 SENSOR,PHOTO 3 PHS52, PHS53, PHS54
659J--03H-020
10 630 000 0269 SENSOR,PHOTO(CONNECTOR) 3 659J--03H-021
11 411 088 9005 WASHER F 3X6X0.5 6 FWS3 F
12 411 086 4408 WASHER SPR 3 6 SW3 F
13 411 040 7803 SCR PAN 3X12 2 M3X12 PAN
13 -1 411 162 1604 SCR PAN 3X20 2 M3X20 PAN
13 -2 411 054 6809 NUT HEX 3 2 M3 F
14 411 141 4008 WASHER V 4X9X0.8 4 FW4
15 411 141 2905 WASHER SPR 4 4 SW4
16 630 000 7640 BOLT,HEX-SCT 4 M4X14
17 630 053 1985 BRACKET,LOCATE 1 659J--03B-005
18 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
19 411 141 3001 WASHER SPR 6 4 SW6
20 630 000 7916 BOLT,HEX-SCT 4 M6X30
21 630 053 1978 BRACKET,LOCATE 1 659J--03B-004
22 630 053 0568 BALL SCREW 1 659J--03H-002
23 411 141 4008 WASHER V 4X9X0.8 4 FW4
24 411 141 2905 WASHER SPR 4 4 SW4
25 630 000 7664 BOLT,HEX-SCT 4 M4X20
26 630 013 6241 BEARING,UNIT 1 659J--03H-016
27 630 000 7657 BOLT,HEX-SCT 4 M4X16
30 630 053 2135 HOLDER 1 659J--03B-019
31 411 141 4305 WASHER V 6X12.5X1.6 2 FW6
32 411 141 3001 WASHER SPR 6 2 SW6
33 630 000 7916 BOLT,HEX-SCT 2 M6X30
38 630 053 1688 COUPLING 1 659J--03H-007
39 630 091 2968 MOTOR,AC-SERVO 1 SVM5(Y), #SGMAH-08AAA21
659J--03H-009
40 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
41 411 141 3001 WASHER SPR 6 4 SW6
42 630 000 7893 BOLT,HEX-SCT 4 M6X20
44 630 053 2159 COVER 1 659J--03B-021
45 411 051 1708 SCR TRS 4X6 4 M4X6 TRS
46 630 053 8090 MECH PARTS(URETHANES) 1 659J--03H-014
47 630 000 7930 BOLT,HEX-SCT 1 M6X40
48 630 053 2142 SPACER 1 659J--03B-020
49 630 053 8090 MECH PARTS(URETHANES) 1 659J--03H-014
50 630 000 7923 BOLT,HEX-SCT 1 M6X35
51 630 053 1053 GUIDE,LINEAR 2 659J--03H-004
52 630 000 7664 BOLT,HEX-SCT 24 M4X20
61 630 058 8507 PLATE 2 659J--03B-155
MODEL TCM-3100J-2
0108-001
128
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
6-2
62 411 141 4008 WASHER V 4X9X0.8 4 FW4
63 411 141 2905 WASHER SPR 4 4 SW4
64 630 000 7626 BOLT,HEX-SCT 4 M4X10
91 411 141 4107 WASHER V 5X10X1 16 FW5
92 411 141 6705 WASHER SPR 5 16 SW5
93 630 000 7770 BOLT,HEX-SCT 16 M5X20
94 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
95 411 141 3001 WASHER SPR 6 4 SW6
96 630 000 7909 BOLT,HEX-SCT 4 M6X25
