– 7 – ELE V A TOR S ECTION No. Part No. Part Name Qty . Detail Y amaha Hitachi 181 KYC-M176H-00 21 1FB069 BRACKET 1 182 KYC-M173L-00 21 1FB072 BRACKET 1 183 KYC-M174E-00 226J2305 CABLE VEYOR 1 184 95302-06600 221F A01 1 …
– 6 –
K1
2 Main Frame Section
1304-001
1B4
1B5
1B1
1C2
1B8
1B9
1B6
193
123
192
1A1
1A0
197
194
195
191
1A2
198
199
196
106
12
19
143
129
147
128
1C1
1C0
1B2
1B3
1B7
144
130
125
113
162
141
126
105
144
130
112
143
129
128
119
106
193
192
123
1A1
1A0
197
194
195
191
1A2
198
137
120
120
199
196
137
B
A
185
184
181
185
182
183
184
175
172
174
174
173
171
175
142
118
107
108
109
117
116
115
139
131
133
111
145
134
132
135
114
136
138
117
116
108
131
146
139
110
138
107
118
142
133
111
145
134
132
136
See Fig. K1-8
Key No.705(U)
See Fig. K1-8
Key No.705(D)
B
147
1
1
A
– 7 –
ELEVATOR SECTION
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
181 KYC-M176H-00 211FB069 BRACKET 1
182 KYC-M173L-00 211FB072 BRACKET 1
183 KYC-M174E-00 226J2305 CABLE VEYOR 1
184 95302-06600 221FA011 NUT,HEXAGON 4 M6
185 90990-66J020 221DB006 SCREW,TRUSS HEAD 4
191 KYL-M86H4-00 226E0069 CASTER 1
192 KYC-M173X-00 221E0467 BOLT 1
193 KYC-M177E-00 221G0215 NUT 1
194 KYC-M177B-00 217A0161 CAP 1
195 KYC-M173S-00 211J1634 STAY 1
196 KYC-M1742-00 222D0440 BEARING_RADIAL 1
197 KYC-M1745-00 222M1493 COMPRESION SPRING 1
198 91312-05012 221AA030 ROHS_HEX-SCT 3 M5L12
199 91312-06010 221AA041 BOLT,HEX.SOCKET HEAD 4 M6L10
1A0 91312-06012 221AA042 BOLT,HEX.SOCKET HEAD 1 M6L12
1A1 KYB-M132C-00 221HA304 ROHS_WASHER 1 SW6
1A2 92902-05200 221HA105 WASHER 3 FW5
1B1 KYC-M171H-00 0921E209 CASTER 1
1B2 KYC-M173X-00 221E0467 BOLT 1
1B3 KYC-M177E-00 221G0215 NUT 1
1B4 KYC-M177B-00 217A0161 CAP 1
1B5 KYC-M173S-00 211J1634 STAY 1
1B6 KYC-M1742-00 222D0440 BEARING_RADIAL 1
1B7 KYC-M1745-00 222M1493 COMPRESION SPRING 1
1B8 91312-05012 221AA030 ROHS_HEX-SCT 3 M5L12
1B9 91312-06010 221AA041 BOLT,HEX.SOCKET HEAD 4 M6L10
1C0 91312-06012 221AA042 BOLT,HEX.SOCKET HEAD 1 M6L12
1C1 KYB-M132C-00 221HA304 ROHS_WASHER 1 SW6
1C2 92902-05200 221HA105 WASHER 3 FW5
1304-001
