P-0332-001_MULTI-LAYER_TRAY-FEEDER - 第28页
– 22 – K1 9 Magazine Set Section 1304-001 844 842 856 853 852 851 855 854 843 841 847 846 845 816 802 806 808 803 805 804 8 801 813 809 816 814 810 815 812 807 822 823 824 825 828 830 827 826 829 824 821 829 See Fig. K1-…
– 21 –
ELEVATOR SECTION
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
705 KYC-M170D-00 1015A41E BASE 1
706 KYC-M1769-00 211F8492 BRACKET 1
707 KYC-M174D-00 226F0151 HINGE 1
708 KYC-M1778-00 216S2678 LEVER 1
709 KYC-M1779-00 216S2679 LEVER 1
710 KYC-M177A-00 216S2680 LEVER 2
711 KYC-M1775-00 216B1432 HOLDER 2
712 KYC-M1774-00 216A1159 COLLAR 2
713 KYC-M174X-00 0921E20D BLOCK 2
714 KYC-M1760-00 1015A418 BRACKET 1
715 KYC-M176G-00 211F8700 BRACKET 1
716 91312-03014 221AA009 BOLT,HEX.SOCKET HEAD 1 M3L14
717 KYC-M1766-00 211A8875 COVER 1
718 KYC-M175X-00 1015A400 BLOCK 1
719 90933-13J696 222D0019 BEARING,RADIAL 4
720 KYC-M1743-00 222H0118 CAM- FOLLOWER 2
722 KYC-M170P-00 0921E00C PLATE 1
723 KYC-M173G-00 211D9805 PLATE 1
724 KYC-M173H-00 211D9806 PLATE 1
726 KYC-M171F-00 0921E006 PLATE 2
727 KYC-M1744-00 222L0717 GUIDE_LINEAR 2
728 90990-66J012 221DA207 SCREW,TRUSS HEAD 24 TRS M4L6
729 KYC-M174A-00 226C0111 HANDLE 1
730 91312-03010 221AA007 ROHS;BOLT_HEX-SCT 2
731 91312-03016 221AA010 BOLT,HEX.SOCKET HEAD 1 M3L16
732 91312-04006 221AA015 BOLT,HEX.SOCKET HEAD 2 M4L6
733 91312-04008 221AA016 BOLT,HEX.SOCKET HEAD 6 M4L8
734 91312-04012 221AA018 BOLT,HEX.SOCKET HEAD 4 M4L12
736 91312-04016 221AA020 BOLT,HEX.SOCKET HEAD 4 M4L16
737 91312-04018 221AA337 BOLT,HEX.SOCKET HEAD 2 M4L18
739 91312-05012 221AA030 ROHS_HEX-SCT 4 M5L12
740 91312-05016 221AA031 ROHS_HEX-SCT 11 M5L16
741 91312-05020 221AA032 BOLT,HEX.SOCKET HEAD 4 M5L20
742 91312-05030 221AA034 BOLT,HEX.SOCKET HEAD 4 M5L30
743 91312-05040 221AA036 BOLT,HEX.SOCKET HEAD 2 M5L40
744 91312-06014 221AA240 BOLT,HEX.SOCKET HEAD 8 M6L14
745 95302-04700 221FA008 NUT,HEXAGON 2 M4
746 95302-05600 221FA009 NUT,HEXAGON 3 M5
747 92902-03200 221HA103 WASHER,PLAIN 2 FW3
748 92902-04200 221HA104 WASHER 20 FW4
749 92902-05200 221HA105 WASHER 7 FW5
750 92902-06200 221HA106 WASHER 8 FW6
751 92902-03600 221HA203 WASHER 1 FWS3
753 92902-04100 221HA004 WASHER 2 SW4
754 92902-05100 221HA005 WASHER 4 SW5
756 97002-05016 221BB003 BOLT,HEXAGON 2
757 KYC-M177S-00 221K1003 RING 2 RING C 6
758 91312-05025 221AA033 BOLT,HEX.SOCKET HEAD 1 M5L25
759 KYB-M656F-00 0921E203 ACCESS-WIRING 1
1304-001
– 23 –
ELEVATOR SECTION
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
801 KYC-M174S-00 0921E009 BLOCK 1
802 KYC-M174U-00 0921E00E SHAFT 1
803 KYC-M1768-00 211D9802 PLATE 1
804 KYC-M177L-00 226D0110 GRIP 1
805 KYC-M174T-00 0921E00D COLLAR 1
806 KYC-M177F-00 222M1342 COMPRESSION SPRING 1
807 91312-04012 221AA018 BOLT,HEX.SOCKET HEAD 1 M4L12
808 91312-04020 221AA021 BOLT,HEX.SOCKET HEAD 1 M4L20
809 91312-05012 221AA030 ROHS_HEX-SCT 1 M5L12
810 91312-05020 221AA032 BOLT,HEX.SOCKET HEAD 1 M5L20
811 95302-04700 221FA008 NUT,HEXAGON 1 M4
812 KYB-M65A9-00 221HA302 ROHS_WASHER 1 SW4
813 KYB-M65AA-00 221HA303 ROHS_WASHER 1 SW5
814 92902-05200 221HA105 WASHER 1 FW5
815 92902-04100 221HA004 WASHER 1 SW4
816 92902-05100 221HA005 WASHER 2 SW5
821 KYC-M176D-00 211F8534 BRACKET 1
822 KYC-M1771-00 213D1172 DISK 1
823 KYC-M1770-00 213A1116 SHAFT 1
824 KYC-M184T-00 23G10029 SENSOR_PHOTO 2
825 KYC-M1746-00 222N0109 SPRING_TENSION 1
826 91312-03025 221AA012 BOLT,HEX.SOCKET HEAD 2 M3L25
827 90990-01J133 221AA023 BOLT,HEX.SOCKET HEAD 1 M4L30
828 95302-03700 221FA006 NUT_HEX 2 M3
829 90990-11J010 221DA056 SCREW,PAN HEAD WW 4 PAN M3L8 SW+FWS
830 KYB-M65A9-00 221HA302 ROHS_WASHER 1 BW4
841 KYC-M176X-00 213A1068 SHAFT 1
842 KYC-M174G-00 4M150276 MOTOR-_AC-SERVO 1
843 KYC-M177J-00 223Q0576 PULLEY_TIMING 1
844 KYC-M1748-00 223C0165 COUPLING 1
845 91312-03030 221AA013 BOLT,HEX.SOCKET HEAD 4 M3L30
846 92902-03600 221HA203 WASHER 4 FWS3
847 92902-03100 221HA003 WASHER,SPRING 4 SW3
851 KYC-M176T-00 211G3646 BLOCK 1
852 KYC-M176Y-00 213A1090 SHAFT 1
853 KYC-M1741-00 222D0380 BEARING_RADIAL 3
854 91312-04008 221AA016 BOLT,HEX.SOCKET HEAD 1 M4L8
855 92902-04200 221HA104 WASHER 1 FW4
856 92902-04100 221HA004 WASHER 1 SW4
1304-001
