– 51 –
TRAVERSE CART SECTION(FULL)
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
602 KYF-M86CG-00 09204101 ASSY_CLAMP_LEVER 2
611 KYC-M1843-00 213A1626 SHAFT 1
612 KYB-M3731-00 222Q0211 SPRING_FLAT 4
613 KYC-M183X-00 211FE389 BRACKET 1
614 KYB-M373S-00 222N0157 SPRING_TENSION 1
615 KYB-M372M-00 211E1181 SPACER 2
616 KYC-M186T-00 211FE377 BRACKET 2
617 KYB-M372W-00 216S3266 LEVER 1
618 KYC-M1872-00 216C1051 ROD 1
619 KYC-M184E-00 222H0132 CAM- FOLLOWER 1
620 KYC-M1847-00 222A0168 BUSH BEARING 2
621 92902-05100 221HA005 WASHER 6 SW5
622 97002-04016 221BA008 BOLT,HEXAGON 1
623 92012-05012 221A0446 BOLT_HEX-SCT 4 BUTTAN M5L12
624 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 2 M4L10
625 91312-05025 221AA033 BOLT,HEX.SOCKET HEAD 1 M5L25
626 95302-04700 221FA008 NUT,HEXAGON 1 M4
627 95302-05700 221FA010 NUT,HEXAGON 1 M5
629 90990-02J025 221CA044 SCREW,SET 2 SET M4L10
630 92902-04200 221HA104 WASHER 2 FW4
631 92902-05200 221HA105 WASHER 5 FW5
641 KYC-M1822-00 10150121 ASSY-FB-CYLINDER 1
642 KYC-M185A-00 0921B302 ROD 1
643 KYC-M185S-00 1005AB13 PIPE_FITTINGS 2
644 KYC-M181A-00 0921A05N AIR_LINE_EQPT 2
645 95302-06600 221FA011 NUT,HEXAGON 1 M6
651 KYB-M371C-00 10150122 ASSY-VALVE 1
652 KYB-M3725-00 1005AB0Q PIPE_FITTINGS 1
653 $AN120-M5 225B0059 AIR LINE EQPT 2
662 KYB-M8515-00 1005AB0W PIPE_FITTINGS 3
665 $CPSE7M-6 225F0353 PIPE FITTING 2
668 KYC-M185P-00 0921D302 TUBE_D6 1
674 90990-66J012 221DA207 SCREW,TRUSS HEAD 2 TRS M4L6
675 KYC-M183N-00 211AE054 COVER 1
1304-001
