– 68 – E2 E2 CUTTER SECTIONN 1 Cover 1304-001 7 4 3 6 2

– 67 –

COVER SECTION

No.

Part No.

Part Name Qty. Detail

Yamaha Hitachi

101 KYC-M1301-00 1015A210 COVER 1

102 KYC-M1304-00 0921B80J COVER 1

103 KYC-M1303-00 0921B80G SHUTTER 1

104 KYC-M1305-00 1015A228 HINGE 1

105 KYC-M186E-00 1015A21Q EDGING 1

106 KYB-M131N-00 1005FG1N BRACKET 1

108 KYB-M131F-00 0920E111 SPRING_CATCHES 2

109 KYB-M130N-00 0929E00K DOORSW_ACTUATOR 1

110 KYB-M131P-00 1005FG1R PLATE 2

111 KYB-M131M-00 1005FG1M BRACKET 1

112 90990-66J012 221DA207 SCREW,TRUSS HEAD 2 TRS M4L6

113 98702-03004 221DA105 SCREW,FLAT HEAD 4 FLT M3L4

114 91312-04008 221AA016 BOLT,HEX.SOCKET HEAD 2 M4L8

115 91312-04006 221AA015 BOLT,HEX.SOCKET HEAD 8 M4L6

116 92902-04200 221HA104 WASHER 4 FW4

117 90990-66J007 221DA202 SCREW,TRUSS HEAD 4 TRS M3L4

118 KYC-M11A0-300 10150229 ASSY_NAME_PLATE 1

119 KYC-M1302-00 0921180W ASSY_NAMEPLATE 1

120 KYB-MD70J-00 0920410T NAME_PLATE 1

1303-001

– 68 –

E2 CUTTER SECTIONN

1 Cover

1304-001

– 69 –

CUTTER SECTIONN

No.

Part No.

Part Name Qty. Detail

Yamaha Hitachi

2 KYC-M3T01-00 1015H237 DUSTCHUTE-TRAY 1

3 90990-66J017 221DA221 RO_MACHIN_SCREW 2 TRS M5L8

4 90990-66J012 221DA207 SCREW,TRUSS HEAD 2 TRS M4L6

6 KYC-M3T00-00 1015H22Y SUPPORT 1

7 90990-01J144 221AA100 BOLT,HEX.S/H WW 4 M4L8

1304-001
