We understand the
needs of those in
electronics packaging
and assembly. As the
original jet dispensing
innovator, we oer
high-quality dispensing
systems, exceptional
jetting technologies,
and the most advanced
closed-loop process
controls in the
industry. With more
than three decades of
experience delivering
value and outstanding
applications expertise,
we are uniquely
positioned to empower
your process.
Features and Benets
• Remarkable Speed and
Accuracy without
Compromise – The
Vantage
®
Series increases
productivity up to 2X
when compared to current
generation platforms. The highly
stable design makes it possible to
dispense with one or two
ASYMTEK IntelliJet
®
Jetting
Systems at signicantly accelerated
speeds without sacricing
dispense accuracy.
• An Expanded Dispense Area –
Provides maximum exibility in a compact
footprint with single-valve dispense areas
up to 470 x 475 mm and dual-valve dispense areas
up to 346 x 475 mm. The Vantage Series is
specically designed for advanced semiconductor
package, electromechanical, and printed circuit
board assembly. This advanced platform is ideal
for applications that involve high-speed or
small-volume dispensing, tight keep out zones,
or dispensing of thin and accurate lines.
Combined with the IntelliJet Jetting System with
ReadiSet
®
Jet Cartridge, the Vantage
Series delivers cutting-edge reliability and
micro-dot jetting up to 1,000 Hz frequency.
ASYMTEK Vantage Series
Advanced Dispensing for Precision
Packaging and Assembly
A completely new software interface that simplies
your programming tasks and provides you with
powerful insight and control over your process.
• Graphical Programming – lets you scan
a workpiece, develop your program, and
visualize the dispensing results on a
virtual canvas prior to dispensing.
• Guided Wizards – provide easy
step-by-step setup instructions.
• Quick-Reference Graphing and
Data Tiles – allow you to control
how system sensor and process
data are displayed.
ASYMTEK CANVAS DISPENSING SOFTWARE
Canvas
®
Graphical Programming
Graphing and Data Tiles
Application Highlights
Built on a robust chassis designed to achieve high accuracy and speed, the Vantage
Series delivers precise
and reliable jetting up to 1,800,000 dots/hr.
Additional application capabilities and specications are available.
For more information, visit our website to nd your local regional oce or representative.
We have several global locations to serve you.
North America
Asia Pacic
EMEA
nordsonasymtek.com/global-locations
info@nordsonasymtek.com
North America Headquarters
2747 Loker Avenue West
Carlsbad, CA 92010-6603, USA
+1.760.431.1919
Ultra-precise placement of
<200 µm uid stream widths
into narrow gaps
Accurate dispense line paths
for volumes <1.5 nL as required
for advanced wafer-level
technology node scaling
Higher throughput and accuracy
with simultaneous dual-valve jetting
and patented* real-time correction
for x, y, and z-axis substrate skew.
*Nordson US Patents 9,707,584 and 10,150,131 and other patents pending.
2020-10-19
