29.26 Technical Reference Manual Chapter Issue 4 May 03
Figure 29-3 Squeegee Assembly
View on Front of Print Carriage
Drive Belt
(in 2 Positions)
Splined Shafts
(in 2 Positions)
Grease Nipple
(in 2 Positions)
35(9(17,9(0$,17(1$1&(
/8%5,&$7,21',$*5$06
Chapter Issue 4 May 03 Technical Reference Manual 29.27
Figure 29-4 ProFlow
Drive Belt
Leadscrew
Linear Bearings
View on Front of Print Carriage
35(9(17,9(0$,17(1$1&(
/8%5,&$7,21',$*5$06
29.28 Technical Reference Manual Chapter Issue 4 May 03
Figure 29-5 Screen Actuators
Y ActuatorX Rear Actuator
X Front Actuator
Machine Front
Plan View on Printhead
Roller Bearing
Striker Plate
