35(9(17,9( 0$,17(1$ 1&( '$,/<0$ ,17(1$1& ( Chapter Issue 4 May 03 Technical Reference Manual 29.5 DAIL Y MAINTENANCE W ARNIN G HARMFUL SUBST ANCE S. CLEANING WIPES AND CLEANIN G SOLUTIONS MA Y CONT AIN …
35(9(17,9(0$,17(1$1&(
6800$5<2)352*5$0
29.4 Technical Reference Manual Chapter Issue 4 May 03
SUMMARY OF PROGRAM
Daily The maintenance schedule is a recommended program which should be carried
out on a daily basis.
Weekly The maintenance schedule is a recommended program which should be carried
out on a weekly basis.
Monthly The maintenance schedule is a recommended program which should be carried
out on a monthly basis (or 45,000 cycles whichever is soonest).
Six Monthly The maintenance schedule is a recommended program which should be carried
out on a six monthly basis (or 260,000 cycles whichever is soonest).
35(9(17,9(0$,17(1$1&(
'$,/<0$,17(1$1&(
Chapter Issue 4 May 03 Technical Reference Manual 29.5
DAILY MAINTENANCE
WARNING
HARMFUL SUBSTANCES. CLEANING WIPES AND CLEANING SOLUTIONS MAY
CONTAIN SUBSTANCES HAZARDOUS TO HEALTH. OBSERVE ALL
MANUFACTURERS’ HEALTH AND SAFETY GUIDELINES. ALWAYS WEAR
APPROVED PROTECTIVE CLOTHING WHEN CLEANING THE MACHINE.
Preparation The machine must be isolated from electrical power and air pressure.
General
NOTE
Any items heavily contaminated requiring thorough cleaning must be re-lubri-
cated in accordance with the appropriate monthly maintenance task.
No. Task Tools Completed Comments
1 Remove any debris from the rising table top
area and clean.
Spatula,
IPA Impregnated
Wipes
2 Remove any debris from the machine surfaces
and clean.
NOTE
Use only soap and water on the machine view-
ing panels.
Spatula,
IPA Impregnated
Wipes
3 Inspect the bearing rails of the following:
a. Print Carriage
b. Paste Dispense Carriage
c. Camera Carriage
Remove any debris and clean as necessary.
Spatula,
IPA Impregnated
Wipes
4 Clean the top of the board at left and board at
right sensors.
Spatula,
IPA Impregnated
Wipes
5 Remove any debris from chase assembly. Spatula,
IPA Impregnated
Wipes
6 Clean the paste dispense drip tray. Spatula,
IPA Impregnated
Wipes
7 Inspect the FormFlex tooling modules for signs
of leaks. If leak found, replace tooling module
(if fitted).
8 Remove any debris from the FormFlex tooling
modules and clean.
Spatula,
IPA Impregnated
Wipes
Estimated time required for daily tasks 8.0 mins
35(9(17,9(0$,17(1$1&(
:((./<0$,17(1$1&(
29.6 Technical Reference Manual Chapter Issue 4 May 03
WEEKLY MAINTENANCE
WARNING
HARMFUL SUBSTANCES. CLEANING WIPES AND CLEANING SOLUTIONS MAY
CONTAIN SUBSTANCES HAZARDOUS TO HEALTH. OBSERVE ALL
MANUFACTURERS’ HEALTH AND SAFETY GUIDELINES. ALWAYS WEAR
APPROVED PROTECTIVE CLOTHING WHEN CLEANING THE MACHINE.
Preparation The machine must be isolated from electrical power and air pressure.
General Remove any build up of dust, solder paste, or other debris from the following
areas of the machine:
NOTE
Any items heavily contaminated requiring thorough cleaning must be re-lubri-
cated in accordance with the appropriate monthly maintenance task.
No. Task Tools Completed Comments
1 Print Carriage:
a. Linear Bearings
b. Belts and Pulleys
Spatula,
IPA Impregnated
Wipes
2 Squeegee/ProFlow Assemblies:
a. Linear Bearings
b. Datum Surfaces
Spatula,
IPA Impregnated
Wipes
3 X and Y Camera Axes:
a. Linear Bearings
b. Belts and Pulleys
Spatula,
IPA Impregnated
Wipes
4 Rail System and Damper Areas:
a. Leadscrews
b. Clatter Bars
Spatula,
IPA Impregnated
Wipes
5 Paste Dispense System:
a. Linear Bearing
b. Drip Tray Mount Screws
Spatula,
IPA Impregnated
Wipes
6 Underscreen Cleaner (if fitted):
a. Linear Bearings
b. Magnet Assemblies
Spatula,
IPA Impregnated
Wipes
7 Rising Table Tool Plate and Magnetic Tooling
Pins.
Spatula,
IPA Impregnated
Wipes
8 Chase Assembly
a. Pulley Assemblies (ASM)
b. Stencil Guide Strips (ASM & standard Chase)
Spatula,
IPA Impregnated
Wipes
