Modular single conveyor D1
Page 37 / 43 22.11.2021
Pos. Item no. Description Part marking
122 00346022-01 HOSE COUPLER L-PK-4
123 00364625-01 TUBE PUN-6X1 800 LONG
124 03031193-01 LIFTING TABLE PCB ASSEMBLY
125 00362766-01 CONVERSION BOARD LIFTING
TABLE
SPARE PART
126 00363111-01 LIGHT BARRIER TRACK A
CONVERS.BOARD LG.
Spare Part
127 00363113-01 LIGHT BARRIER TRACK B
CONVERS.BOARD LG.
Spare Part
128 03037944-01 LIFTING TABLE PLATE ET SPARE PART
129 00356857-01 SPACER FOR LIFTING TABLE
130 03039424-01 COVER CONVERSION BOARD
ASSEMBLY TRAY
131 00367979-01 COVER 2 (CABLE CHANNEL) SPARE PART
132 03039425-01 COVER NO.3 (INTERMEDIATE
BOTTOM)
133 03039426-01 COVER NO.4 (CABLE GUIDE)
134 00367984-01 CABLE CHANNEL 44X30X550
135 00359426-03 CONVERSION PC-BOARD
CONVEYOR
SPARE PART
136 00370925-01 PROTECTION MAT CONVERSION
BOARD BASIC
137 00348626-01 DISTANCE SLEEVE 4,2*7*4 FOR M4
ALU
138 03047316-01 STANDOFF O/O M4X5
139 03047271-01 STANDOFF I/I M4X55
140 03048401-01 STANDOFF I/O M4X12
141 03039372-01 END SWITCH ANGLE
142 00367222-02 POSITION SWITCH BRACKET
143 03039385-01 FASTENER FOR END SWITCH
144 03039519-01 LIMIT SWITCH WIDTH ADJUSTMENT
1
145 00316831-01 MICRO SWITCH V4N T7 SERIES SPARE PART
146 03039520-01 LIMIT SWITCH WIDTH ADJUSTMENT
2
147 00316831-01 MICRO SWITCH V4N T7 SERIES SPARE PART
148 03039521-01 LIMIT SWITCH MOUNTING TUB
149 00316831-01 MICRO SWITCH V4N T7 SERIES SPARE PART
Modular single conveyor D1
Page 38 / 43 22.11.2021
Pos. Item no. Description Part marking
03041835-01 CABLE EXTENSION STEPPING
MOTOR
SPARE PART
03039614-01 CABLE LIFTING TABLE TRACK 1 SPARE PART
180 03037939-01 SIDE PANEL A KPL
181 03037991-01 SIDE PANEL BASIC ASSEMBLY
RIGHT SIDE
182 03037993-01 BASE PLATE RIGHT
183 03060496-01 STOP RIGHT SIDE 1 COMPL.
184 03039049-01 GUIDE RAIL RIGHT SIDE 1 CPL.
185 03039051-01 GUIDE RAIL RIGHT SIDE LASER
186 03039052-01 GUIDE RAIL RIGHT 2 SPARE PART
187 00375332-01 GUIDE RAIL SENSOR SPARE PART
188 00375331-01 GUIDE RAIL SENSOR BB SPARE PART
189 03038414-01 BELT SUPPORT EA
190 03038415-02 BELT SUPPORT AB *
191 00360903-02 TRANSITION PIECE 1 SPARE PART
192 00360904-02 TRANSITION PIECE 2A SPARE PART
193 03037995-01 SUPPORT 1
194 03037997-01 BASE PLATE 1
195 00360422-02 CLAMPING DEVICE
196 03037999-01 INTERMEDIATE PLATE RIGHT
197 03038000-01 BELT SUPPORT PA
198 00364890-01 ACTUATOR, CPL. *
199 00366857-02 DEFLECTION PULLEY,
UNGEARED,INJEC.MOLD.
Spare Part
200 00366858-02 DEFLECTION PULLEY, GEARED
(INJECT.MOLD.)
201 00330692-01 DIN 7991-M4 X 6-8.8
202 00361548-01 STOP *
203 00356847-01 CARRIAGE *
204 00358342-01 DRYLIN N GUIDE CARRIAGE *
205 00356856-01 COVER *
206 00369717-01 DU-TABE *
207 00364873-02 SLIDEWAY LINING *
208 00369731-01 WASHER *
212 03038989-01 COVER CABLE CHANNEL
Modular single conveyor D1
Page 39 / 43 22.11.2021
Pos. Item no. Description Part marking
214 00366857-02 DEFLECTION PULLEY,
UNGEARED,INJEC.MOLD.
Spare Part
215 00366858-02 DEFLECTION PULLEY, GEARED
(INJECT.MOLD.)
216 00360422-02 CLAMPING DEVICE
217 00375330-01 MOUNTING BRACKET MS-EX10-1 SPARE PART
218 03039269-01 LIGHT BARRIER RECEIVER INPUT
BELT
Spare Part
219 00370412-01 LIGHT BARRIER RECEIVER SUNX
EX-13B-PN
220 03039270-01 LIGHT BARRIER RECEIVER
PLACEMENT BELT
Spare Part
221 00370412-01 LIGHT BARRIER RECEIVER SUNX
EX-13B-PN
222 03039271-01 LIGHT BARRIER RECEIVER OUTPUT
BELT
Spare Part
223 00370412-01 LIGHT BARRIER RECEIVER SUNX
EX-13B-PN
224 03039272-01 LB RECEIVER MODULE PLACEMENT
BELT
SPARE PART
225 03039007-01 SENSOR PLATE COMPLETE
03039009-01 LIMIT SWITCH WIDTH ADJUSTMENT
00316831-01 MICRO SWITCH V4N T7 SERIES SPARE PART
229 03038888-01 BOARD HOLDER
230 00359424-01 CONVERSION BOARD TRANSPORT SPARE PART
231 03046875-01 DISTANCE BOLT I/A M3X30
232 00364715S01 COMPRESSION SPRING
0,63X5,63X26
SPARE PART
233 00359284-03 DRIVE UNIT SPARE PART
234 00367172-02 MOTOR MOUNT COMPLETE
235 03009269S01 DC-GEAR MOTOR WITH
SYNCHRONIZING DISC
236 00367173-01 DRIVE SHAFT COMPLETE
237 00355553-01 TOOTHED BELT SYNCHROFLEX 6
AT3/150
WEAR PART
238 00364847S01 TOOTHED BELT SYNCHROFLEX 2.5
T5/1160
WEAR PART
239 00359917S01 TOOTHED BELT SYNCHROFLEX 2.5
T5/1315
WEAR PART
240 00356850S01 TOOTH BELT SYNCHROFLEX WEAR PART
