User manual SIPLACE D4 4 Setting up and commissioning
From software version SR.605.xx 07/2008 EN Edition 4.3 Setting up the machine
165
4.3 Setting up the machine
4.3.1 PCB conveyor height on the machine
The machine can be set to the following PCB conveyor heights:
830 mm ± 15 mm Standard height 4
900 mm ± 15 mm Option 4
930 mm ± 15 mm Option 4
950 mm ± 15 mm SMEMA option 4
PLEASE NOTE 4
The PCB conveyor height is the distance between the top edge of the PCB conveyor belt and the
bottom edge of the machine feet.
4.3.2 Warning instructions
DANGER 4
Only SIPLACE engineers or qualified people are permitted to set up and commission the machine.
→ Always follow the applicable accident prevention regulations.
→ Never lie beneath the machine in order to attach the machine feet. All the modules and parts
can be fitted from the spaces for the component tables. If you nevertheless have to carry out
assembly work underneath the machine, then you must secure the machine by suitable
means. The fork-lift must not be used as the only support.
→ Make sure that the gantries are positioned over the PCB conveyor area so that you do not
restrict your head movement during assembly, thus excluding the risk of injury.
→ Two people will be needed to adjust the height of the machine:
– one person to carry out the necessary assembly work,
– the other person to watch the raised machine during assembly and ensure that it does not
move.
→ Wear special safety boots to protect your feet.
4 Setting up and commissioning User manual SIPLACE D4
4.3 Setting up the machine From software version SR.605.xx 07/2008 EN Edition
166
4.3.3 Tools and equipment
You will need the following tools and equipment to adjust the height of your machine:
– Single-ended spanner, size 65, item no. 00353827-01
Size 65 for the hexagon lock nut M24 on the machine foot 4
– Allen key, size 10, item no. 00373926-01
for hexagon socket head screws M12 for fixing the spacers for the machine feet 4
– Fork-lift
Fork length: min. 1800 mm 4
Carrying power: min. 6000 kg 4
Width between forks: see Fig. 4.3 - 1
, page 167 4
– Spirit level : Accuracy 0.02 mm/m
– Air cushion transport system: SIPLACE HSxx, item no. 00119002-xx
4.3.4 Presetting the PCB conveyor height
WARNING 4
Please note the following points before you raise the machine in order to avoid irreversible dam-
age to the machine:
– Open the forks just wide enough to position them between the two machine feet (the attach-
ment points are shown in Fig. 4.3 - 1
). The machine feet are 776 mm apart. NEVER increase
the distance between the forks so that the machine is lifted on the side parts of the machine
frame, since this would deform the machine frame.
→ Make sure that the forks are evenly loaded when you lift the machine. A firm support between
the forks and machine will prevent the machine tilting when it is raised. This will also prevent
a one-sided load on the machine feet, which would deform the fixing of the machine feet. We
recommend that a second person watch the machine as it is raised, and make sure that the
machine does not tip to one side when lifted with the fork-lift.
→ Push the forks of the fork-lift under the machine, as shown in Fig. 4.3 - 1
.
User manual SIPLACE D4 4 Setting up and commissioning
From software version SR.605.xx 07/2008 EN Edition 4.3 Setting up the machine
167
4
Fig. 4.3 - 1 Contact surfaces - Forks parallel to the direction of PCB transport
(1) Contact surfaces for the forks of the fork-lift
4
→ With the fork-lift, raise the machine approximately 35 cm.
The machine stands on 6 feet.
– 4 outer machine feet (item 1 in Fig. 4.3 - 2
, page 168) with 4 spacers (item 2 in Fig. 4.3 - 2,
page 168
) for adjusting the height, if necessary.
– 2 middle machine feet (item 3 in Fig. 4.3 - 2
, page 168) with 2 spacers (item 2 in Fig. 4.3 - 2,
page 168
) for adjusting the height, if necessary.
