1.5.5.3 Documentation packages, 07/2008 edition
1
1
PLEASE NOTE 1
Further information about the station extensions such as assembly, operation and preventive
maintenance described in Chapter 6 can be found on the SIPLACE homepage. 1
1.5.6 Abbreviations
1
Package contents Language
a
Item no.
DVD product documentation incl. parts catalogs
(PDF and HTML), in German and English
Detailed circuit diagrams folder in German/English
Operating instructions in the ordered language
version
Preventive maintenance in the ordered language
version
Software instructions: First Steps 605 in the ordered
language version
JobGuides / JobPoster
in the ordered language version
Angle gauge / tape gauge in the ordered language
version
German 00195873-01
English 00195874-01
French 00195875-01
Italian 00195876-01
Spanish 00195877-01
Portuguese 00195878-01
Hungarian 00195879-01
Czech 00195880-01
Russian 00195881-01
Polish 00195882-01
Estonian 00195883-01
Finnish 00195884-01
Swedish 00195885-01
Danish 00195886-01
Dutch 00195887-01
T. Chinese 00195888-01
S. Chinese 00195889-01
Korean 00195890-01
Japanese 00195891-01
a) Other language available on request
C&P Collect&Place
C&P12 Collect&Place head with 12 segments
CO Component
DC Dual conveyor
1 Introduction User manual SIPLACE D4
1.5 Important notes on the user manual From software version SR.605.xx 07/2008 EN Edition
28
DCA Direct chip attach
EMC Electromagnetic compatibility
ESD Electrostatically-sensitive group of components
ESD Electrostatic sensitive device
FC Flip chip
GND Ground
IC Integrated circuit
MC Machine controller
OSC Odd shaped components
PA Placement area
PCB Printed circuit board
SC Single conveyor
SC Station computer
SM Dual conveyor in Single conveyor mode
SMD Surface mounted device
VS Vision system
WLAN Wireless Local Area Network
