5.3 Further Features

5.3.1 Station Software 705

SIPLACE Pro 9.3 supports version 705 for the:

 DX series: DX1, DX2 and DX4

 SX series: SX1, SX2 and SX4

 X series: X2, X3, X4, X4I, X4T and X4IT

5.3.2 Automatic Width Adjustment

On stations from station software 704, SIPLACE Pro supports the automatic width adjustment.

The station software offers a manual width adjustment via its user interface.

5.3.3 Refined Time Model for SOKO Nozzles

Depending on the station software version 703, 704 or 705 a refined optimization time model is used

to exactly simulate overlapping axis travelling diagrams.

5.3.4 Option Long Board for DX4 and SX4

From station software 705, long boards can be optimized and produced using the reverse stepping

feature.

5.3.5 01005 Support for 2x8mmX

From station software 605 and 705, the 01005 placement process is supported without any

restrictions.

5.3.6 PCB Barcode Recognition by Means of the PCB Camera

From station software 705, PCB and panel barcodes can be read by means of the PCB camera

(Traceability data).

The barcode scanned at the first station of the line can be passed on to the next placement machine.

Passing on read barcode data is only supported if the placement machines are standing in direct

succession and are not separated e.g. by an inspection conveyor belt.

The barcode data can be described as a barcode fiducial and assigned in the PCB editor. Barcode

fiducials can be scanned on the placement machine and saved as barcode fiducials in SIPLACE Pro.

Note

The feature is activated with the "Reading Barcode with PCB Camera" license.

5.3.7 Alternative Components

From station software 705: In the PCB editor, one or more alternative components can be defined for

each placement position in addition to the default component. Thus, it is possible to describe for one

PCB:

 Components of different manufacturers or / and

 Components with differing component shapes or / and

 Components with different packaging forms and feeders.

The optimization checks the necessary technical constraints such as common nozzle, common

camera, and same feeder class and calculates the number of possible alternatives.

The default component is set up by the optimization within the SIPLACE Pro setup. The possible

alternatives can be shown using the Recipe Analyzer and the Setup report.

The download sends recipes with alternative components, if this feature is activated on all stations in

the line and if a license is present for each station.

Software Versionsbeschreibung Programmiersystem SIPLACE Pro 9.3

Software Version Description Programming System SIPLACE Pro 9.3

As long as the feature is not activated on all stations in the line or not supported by all software

versions in the line, the recipe is sent without alternative component data, i.e., a mixed operation

within a line is not possible.

Notes

1. The feature requires the "Forced Setup Verification" operation mode. The use

of splice sensors is highly recommended, if alternative components will directly

be spliced directly.

2. The feature is activated with the "Alternative Components" license.

3. For further information on this feature and its restrictions please see the user

manual “Alternative Components“ on the product CD.

4. The SiCluster Professional option supports alternative components.

5.3.8 SIPLACE Random Setup

Up to now feeders and components have to be set up exactly on the tracks that have been calculated

by the optimization and assigned by the download.

The SIPLACE Random Setup feature offers the opportunity to set up components on another track of

the same table or even to set up another table in the line. This is only supported for X feeders. Other

feeder types must be set up on the accurate track as described in the setup.

It is not possible changing the setup for a production in process.

Procedure:

1. Create an optimized target setup using the optimization.

2. In the LineControl GUI the "Random Setup" function is enabled in the production plan.

3. A recipe or job with an optimized setup is added to the production plan.

4. Typically, the required components have already been set up on the X feeders in the pre-

setup.

5. The pre-setup-up X feeders are placed on the tables of the line. It is recommended to position

the feeders as accurate as possible with respect to the track of the optimization result.

Note

Deviations of the real setup compared with the target setup leads may lead to

deviations of real and simulated production time and thus to an unequal

utilization within the line.

6. During the download of the recipe to the line, LineControl creates a working copy of the

optimized target setup. Setup Center detects the feeders actually set-up at the station and

enters them into the working copy.

Note

The computer on which the Setup Center application is installed can be

selected in the configuration of the Line Control GUI.

7. LineControl checks if all components of the PCB(s) of the recipe are correctly entered in the

working copy of the setup according to the download settings. If components are missing, they

can be added on their standard X feeder from the optimized setup.

Software Versionsbeschreibung Programmiersystem SIPLACE Pro 9.3

Software Version Description Programming System SIPLACE Pro 9.3

8. The job is sent to the station after a successful integrity and license check.

Notes

The feature requires station software 705. Earlier software versions (605 or 703) were

not tested.

The features "Random Setup" and "Alternative Component" cannot be combined on

one single line.

For further information on this feature and its restrictions please see the user manual

“SIPLACE Random Setup“ on the product CD.

5.3.9 Teaching of Placement Positions

From station software 705, placement position offsets (X, Y and angle) can be taught at the station

and uploaded to SIPLACE Pro.

In the PCB editor, the placement positions to be taught have to be marked. The taught placement

position offsets are taken into account when supplying data to stations with prior software versions

(e.g. station software version 40x and 50x). A change in the placement position offsets is distributed to

other stations in the line that place the placement position of the same name.

Notes

The SIPLACE Pro user "Service" has to have writing access to placement lists.

In addition, the user logged into the station has to have writing access to the placement

list that contains the uploaded placement position.

5.3.10 Split Table at Track and SiCluster Professional

Besides optimizing split tables in SiCluster Professional it is also possible to use this option for the

cluster jobs and their Result Jobs.

5.3.11 Whispering of Barcode Information

Note

The feature can be activated with the "Whispering of Barcodes" license.

5.3.12 Long Board Option

Note

The feature can be activated with the "Long Board Option" license.

5.3.13 Integrity Check for Multiple Jobs

Similar to the Multi Job Optimization and the Multi Cluster Job Optimization there is the Multi Integrity

Check in the Optimizer toolkit. From the structure tree of the recipes the recipes to be checked are

added to a recipe list and optimized in the desired sequence and according to the settings.

At the same time, the optimization starts an adjustable number of processes and thus utilizes the

present multi core processors.

5.3.14 Query Tool

The underlined results of queries can be clicked on. The corresponding object is opened in SIPLACE

Pro Desk.
