Software Versionsbeschreibung Programmiersystem SIPLACE Pro 9.3
Software Version Description Programming System SIPLACE Pro 9.3
54
6.3 Troubleshooting
Error Reporting Tool
The error report enables you to send details of errors occurring in SIPLACE Pro to the service
department. For further information please refer to chapter 8.3 Information on the SIPLACE Net Error
Reporter Service on page 58 and to the online help as well as to the Support Media DVD.
Error Reports with the SIPLACE Net Error Reporter Service
The SIPLACE Net Error Reporter Service (on the Support Media DVD) can be started as follows:
Start / Programs / SIPLACE Net / Enterprise Service / SIPLACE Net Error Reporter Service or
via
Help / Error Reporting in the menu for the GUIs.
Follow the instructions on the screen. Thanks a lot for your support.
Problem Solving in Workgroup Mode
If you operate SIPLACE Pro in workgroup mode and if e. g. during the startup of the SIPLACE Pro
LineControl GUI application a message is displayed stating that:
"It was not possible to establish a connection to the SIPLACE Pro Interface. The cause for the error
was: Unknown error (0x80004005)."
Please check, if the following password requirements are met:
the local user data must also be set up on the workgroup server,
the local user must have the same password as on the workgroup server.
Software Versionsbeschreibung Programmiersystem SIPLACE Pro 9.3
Software Version Description Programming System SIPLACE Pro 9.3
55
7 Rectified Errors (Announced in SiScope)
Note:
The rectified errors can be found in the "Readme.txt" file on the installation CD in the
.\Documentation directory.
During installation the "Readme.txt" file is copied to your hard disk into the
.\Documentation subdirectory of the installation path together with all pdf documents.
All installed documents are available via "Start / Programs / SIPLACE Pro /
Documentation"
Software Versionsbeschreibung Programmiersystem SIPLACE Pro 9.3
Software Version Description Programming System SIPLACE Pro 9.3
56
8 Annex
8.1 LINUX/ UNIX Line Computer
The import / export functions of SIPLACE Pro support the following versions of the LINUX / UNIX line
computer:
LRU.501.xx
LRU.502.xx
LRU.503.xx
The following files can be exported from SIPLACE Pro to the line computer:
.be files (Components)
.sgf files (Component Shapes)
.ri- file (Restrictions: Component/Component Shape – Feeder Type)
.qd files (Boards)
.pm files (Fiducials)
.rt files (Setups)
The following files can be imported from the line computer into SIPLACE Pro:
.be files (Components)
.sgf files (Component Shapes)
.ri- file (Restrictions: Component/Component Shape – Feeder Type)
.qd files (Boards)
.pm files (Fiducials)
.rt files (Setups)
8.2 Supported Platform, Station Software and Machine Type
Platform
Station Software
Version
Machine Types
Sirio
705
DX series: DX1, DX2 and DX4
SX series: SX1, SX2 and SX4
X series: X2, X3, X4, X4I, X4T and X4IT
704
X series: X2, X3, X4 and X4I
SX series: SX1, SX2 and SX4
703
X series: X2, X3, X4 and X4I
SX series: SX1, SX2
702
X series: X2, X3, X4 and X4I
701
X4I
