Page 19
SAFETY PRECAUTIONS
Be sure to observe
3Y3C-E-EMD00-A03-01
CAUTION
M27E
DO NOT GIVE A
SHOCK TO THE ELEC-
TRICAL EQUIPMENTS.
There is a risk of an electric
shock, leak or malfunction of
the machine.
USE A JIG TO FIT AND
REMOVE THE
SPRINGS.
Your hands or fingers may be
injured.
M30EB
BE CAREFUL OF THE
CUTTER, HEAD AND
THEIR VICINITY DUR-
ING ADJUSTMENT.
Your head, hands or fingers
may be injured.
M31E
STOP THE CAMSHAFT
AT A STABLE POSI-
TION WHEN REPLAC-
ING THE TAPE CUT-
TER BLADE.
The machine may be actuated
unexpectedly and injure you.
Replace the blade according
to the instructions in MAIN-
TENANCE MANUAL.
M38EB
WEAR A PROTECTIVE
HAT AND GOGGLES
FOR MAINTENANCE
WORK.
Your head or eyes may be
injured while performing main-
tenance work.
M44E
M39E
CARRY OUT PERIODIC MAINTE-
NANCE AND INSPECTION.
If you fail to carry out periodic inspection and
maintenance, the machine cannot exhibit its true
performance. Also, it may break down or produce
defectives.
Periodic inspection and maintenance should be
carried out by a trained person in charge of
maintenance according to the instructions in
MAINTENANCE MANUAL.
BEFORE PERFORMING AUTOMATIC
WIDTH ADJUSTMENT, BE SURE TO
VERIFY NO BOARDS OR OTHER
OBJECTS ARE ON THE CONVEYOR.
Boards or other objects may drop from the con-
veyor, causing damage to the boards or the ma-
chine.
If there are any boards or other objects on the
conveyor, turn OFF the servo switch and remove
them.
M36E
DO NOT DISAS-
SEMBLE THE CAM-
ERA UNIT.
You may be injured or the
machine may break down.
If a breakdown occurs,
consult the manufacturer.
M42E
Page 20
SAFETY PRECAUTIONS
Be sure to observe
Rear view of warning label indicated positions
CM88S-M/M1,CM88C-D (Danger labels)
The following warning labels are pasted on this machine. Follow the instructions on each label. If a label
has come off, put a new one on a proper position. To order a label from the manufacturer, refer to PARTS
LIST.
Label part No.
Front view of warning label indicated positions
0 1 J Q B
feeder tables will have
serious injury.
The labels for safety pasted on the product
M32
3Y3C-E-EMD00-A03-02
4G3C-AA01
3Y3C-AJ01
00DJC2AB
00DJC2AC
0 1 J V B
DANGER
ROTATIONAL
ACTIVE PART
INSIDE
You will have serious
injury if you open the
cover and touch the
active part inside.
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
(Description is the illustration for CM88S-M.)
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
0 1 J Q B
DANGER
WATCH YOUR
HANDS
Caught hands between
right feeder and left
feeder tables will have
serious injury.
0 1 J Q B
DANGER
WATCH YOUR
HANDS
Caught hands between
right feeder and left
feeder tables will have
serious injury.
Page 21
SAFETY PRECAUTIONS
Be sure to observe
CM88S-MU (Danger labels)
The following warning labels are pasted on this machine. Follow the instructions on each label. If a label
has come off, put a new one on a proper position. To order a label from the manufacturer, refer to PARTS
LIST.
Label part No.
0 1 J Q B
feeder tables will have
serious injury.
The labels for safety pasted on the product
M32
3Y3C-E-EMD00-A03-01
Rear view of warning label indicated positions
Front view of warning label indicated positions
4W3C-AA00
4W3C-AD00
00DJC2AB
0 1 J Q B
DANGER
WATCH YOUR
HANDS
Caught hands between
right feeder and left
feeder tables will have
serious injury.
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
00DJC2AC
0 1 J V B
DANGER
ROTATIONAL
ACTIVE PART
INSIDE
You will have serious
injury if you open the
cover and touch the
active part inside.
0 1 J Q B
DANGER
WATCH YOUR
HANDS
Caught hands between
right feeder and left
feeder tables will have
serious injury.
0 1 K 1 B
DANGER
DO NOT OPEN
THE COVER
WHEN
OPERATING
You will have serious
injury if you touch the
active part inside.
