Page 3
OPERATING MANUAL (for Engineers)
Production No.
Kyushu Matsushita Electric Co., Ltd.
2000 printed in Japan
3Y3C-E-EMD00-A01-03
IMPORTANT
Read the instructions and safety precautions presented in this as well as all other applicable manuals before
installing, operating, or servicing the CM88S-M/M1/MU Ultra High-speed Chip Mounter / CM88C-D Ultra
High-speed Chip Mounter or any of its equipment.
This manual was current at the time of publication. However, the Ultra High-speed Chip Mounter and its
equipment undergo a continuous program of performance refinement and improvement. Therefore, the data
in the manual may vary from information furnished with the machine and equipment delivered to you.
This manual is provided for the exclusive and internal use of the customer to whom the applicable machine
has been sold only. Duplication or copying of any part of this manual is strictly prohibited without the express
written consent of Kyushu Matsushita Electric Company, Ltd.
M11E
DO NOT ALLOW ANY PERSON WHO HAS NOT RECEIVED SPECIAL TRAINING
TO OPERATE THE MACHINE.
The machine may be operated improperly and injure you.
Either carry out training by yourself, or consult the manufacturer.
WARNING
Operating Manual (for Engineers)
Ultra
High-speed
Chip Mounter
CM88S-M/M1/MU
CM88C-D
Page 4
3Y3C-E-EMD00-A01-01
This manual is for the installation of High-speed Chip Mounter CM88S-
MU.
Installation manual
Installation manual Installation manual
(Only for CE standard version)
The assembly of each unit is individually indicated by an exploded
view of the parts. Use this for ordering parts or confirming the assem-
bly of the units.
Parts List
Parts ListParts List
This manual is for the machine operators, and describes the operating
procedure, precautions and information which is necessary for safe
and effective operation.
ORGANIZATION OF MANUALS
6 manuals (Nonstandard version: 5 copies) are attached to this machine. They are classified into 5
types (Nonstandard version: 4 types). Use each manual according to the working purpose and person
in charge.
The production data of the line including this machine are programed on PT100-G.
Use the programming manual attached to PT100-G.
Operating manual
Operating manualOperating manual
(for operators)
(for operators) (for operators)
PT100-G Programming manual
PT100-G Programming manualPT100-G Programming manual
This manual is for the engineers who program the production data of
the line, and describes how to create and modify the data by using
PT100-G.
This manual is for the machine engineers, and describes operation
method and teaching of boards and parts.
Operating manual
Operating manualOperating manual
(for engineers)
(for engineers) (for engineers)
This manual is for machine maintenance, and describes the daily
checks, adjustment and replacement of consumable parts.
Troubleshooting is also included.
Maintenance manual (1/2, 2/2)
Maintenance manual (1/2, 2/2)Maintenance manual (1/2, 2/2)
Panasonic
CREATE
PT100-G
Programming Manual
PT100-G Programming manualThis machine’s manuals
Panasonic
CREATE
Panasonic
CREATE
Panasonic
CREATE
Panasonic
CREATE
Panasonic
CREATE
Operating Manual (for operators)
Operating Manual (for engineers)
Maintenance Manual (2/2)
Maintenance Manual (1/2)
Parts List
This
manual
