Installation Manual, Station Software Version 601.03 SP4 Edition 05/2007
82 of 89
4.8.6 Setup page "Power Management Setup"
Menu item Comment Selection options Settings Comment
ACPI Function
ACPI version 1.0 is implemented in the BIOS. Statuses
S1 and S3 are supported by the hardware.
Enabled, ACPI is only supported automatically as of
Win98. When installing Win95, ACPI installation must be
initiated by hand.
Disabled means that ACPI is also not supported for an
ACPI-compatible operating system.
Enabled
Disabled
Enabled
Power
Management
This field is the main switch for the power saving modes.
There are three settings:
Max Saving Switches the computer to
power saving mode after a brief
time of inactivity.
Min Saving Works almost exactly in the
same way as Max Saving, but the
inactivity time required for switching
is longer.
User Defined Enables the power saving
mode options to be set individually.
User Define
Min Saving
Max Saving
User Define
Installation Manual, Station Software Version 601.03 SP4 Edition 05/2007
83 of 89
Menu item Comment Selection options Settings Comment
Video Off
Method
This sets the way in which the monitor is switched to
power saving mode. There are three options available:
DPMS (Display Power Management)
enables the BIOS to control
DPMS-capable graphics cards.
Blank Screen Darkens the screen and
should be used with monitors
without Power Management
functions.
V/H Sync+Blank Darkens the screen by switching
off the vertical and horizontal
synchronization.
Blank Screen
V/H Sync+Blank
DPMS
DPMS
Video Off In
Suspend
Specifies whether the monitor interface is switched off in
suspend mode (no sync signals)
No
Yes
Yes
MODEM Use IRQ
This option determines which IRQ registers the ring tone
of the modem for faxing.
NA; 3; 4; 5; 7;9; 10;
11
NA
Suspend Mode
The time is set here before the system switches to
suspend mode.
Disabled;
1 Min; 2 Min;
4 Min; 8 Min;
12 Min; 20 Min;
30 Min; 40 Min;
1 Hour
Disabled
Installation Manual, Station Software Version 601.03 SP4 Edition 05/2007
84 of 89
Menu item Comment Selection options Settings Comment
HDD Power
Down
The time is set here after which the hard disk is switched
to Power Down mode
Disabled;
1 Min; 2 Min;
3 Min; 4 Min;
5 Min; 6 Min;
7 Min; 8 Min;
9 Min; 10 Min;
11 Min; 12 Min;
13 Min; 14 Min;
15 Min
Disabled
CPU THRM-
Throttling
If the system begins to throttle due to a thermal overload,
this is the ratio in percent: switch-off time / (switch-off
time + on time). This value is factory set and cannot be
changed.
87,5%
87,5% Item is Show
Only
Resume by
Alarm
If this option is switched on, the computer is retrieved
from power saving mode at the specified date and time. If
0 is specified as a date, this is done on a daily basis.
Enabled
Disabled
Disabled
Date (of Month)
Alarm
all values between 0
and 31
0
all values
between 0
and 31
Time (hh:mm:ss)
Alarm
valid time
0:0:0
valid time
0:0:0
Reload Global
Timer Events
Every event of a device listed below resets the global
counter for suspend mode, if this is enabled.
Enabled
Disabled
Disabled Menu item
FDD,COM,L
PT Post not
available with
Legacy Free
