Installation Manual, Station Software Version 601.03 SP4 Edition 05/2007
85 of 89
4.8.7 Setup page "PNP/PCI Configuration"
Menu item Comment Selection options Settings Comment
PNP OS
Installed
Yes, if the operating system used is plug and play-
compatible (e.g. Win9x); No, if it is not
No
Yes
No
Reset
Configuration
Data
Enabled instructs the PNP BIOS to reset all devices and
assignments.
Enabled
Disabled
Disabled
Resources
Controlled By
The Manual setting can be used to reserve the interrupts
and DMA, otherwise they will automatically be assigned
by the BIOS (PnP Extension).
If no PNP operating system has been installed, use Auto.
Auto (ESCD)
Manual
Auto
(ESCD)
IRQ Resources
This field is only enabled if the option Manual is enabled
under Resources Controlled By. Pressing the Enter key
will display a submenu in which the interrupts can be
released for assignment by the PNP BIOS (setting
PCI/ISA PnP) or not assigned by the PNP BIOS (setting
Legacy ISA)
PCI/ISA PnP
Legacy ISA
PCI/ISA
PnP
(PCI Device
for Legacy
Free)
With Legacy
Free, the options
are:
PCI Device
Reserved
DMA Resources
This field is only enabled if the option Manual is enabled
under Resources Controlled By. Pressing the Enter key
will display a submenu in which the DMA channels to be
assigned by the PNP BIOS are disabled (setting PCI/ISA
PnP) or not assigned by the PNP BIOS (setting Legacy
ISA)
PCI/ISA PnP
Legacy ISA
PCI/ISA
PnP
Menu item not
available with
Legacy Free
PCI/VGA Palette
Snoop
Color reproduction may be corrupted with some graphics
adapters such as graphics accelerators or MPEG
adapters which do not conform to the VGA standard. In
this case, set Enabled
Enabled
Disabled
Disabled
Assign IRQ for
USB
Enabled assigns a PCI IRQ to the USB controller. Enabled
Disabled
Enabled
Installation Manual, Station Software Version 601.03 SP4 Edition 05/2007
86 of 89
Menu item Comment Selection options Settings Comment
PCI INT A
PCI INT B
PCI INT C
PCI INT D
PCI INT E
PCI INT F
PCI INT G
PCI INT H
Assignment
With this setting, the BIOS can be instructed to assign a
defined IRQ to a PCI interrupt. A prerequisite for this is
that this IRQ is not set to Legacy ISA. When Auto is set,
the BIOS automatically assigns the IRQ.
Auto; 3; 4; 5; 7; 9;
10; 11; 12; 14; 15
Auto
Installation Manual, Station Software Version 601.03 SP4 Edition 05/2007
87 of 89
4.8.8 Setup page "PC Health Status"
This menu item is not available with Legacy Free.
Menu item Comment Selection options Settings Comment
Throttling
Temperature
This setting specifies the internal chip temperature at
which the processor automatically begins thermal
throttling.
110°C/110.00°C
115°C/115.00°C
120°C/120.00°C
110°C/110
.00°C
Ambient
Temperature
Shows the ambient temperature. - -
CPU
Temperature
Shows the CPU temperature. - -
4.8.9 Setup page "Frequency/Voltage Control"
In the "Selection options" column, the setting for fail-safe default is indicated in italics and the setting for optimized default is underlined.
Menu item Comment Selection options Settings Comment
Auto Detect PCI
Clk
If this function is Enabled, only CPCI slots which are also
occupied are clocked.
Enabled
Disabled
Enabled May switch
invisibly, as
specification
only applies to
internal bus 1.
Spread
Spectrum
If this function is Enabled, the average frequency of the
clock cycles generated in the clock synthesizer is
modulated within tight boundaries. This widens the noise
spectrum but lowers the amplitude.
Enabled
Disabled
Disabled
