Installation Manual, Station Software Version 601.03 SP4 Edition 05/2007
3 Requirements
3.1 SIPLACE X series software components
3.1.1 Station computer
The station computer uses the following operating system configuration:
- Microsoft Windows XP Professional (including Service Pack 2 and most recent hotfixes)
3.1.2 Machine components
The following versions of other machine components are required for the station software to function
correctly:
Station computer SIPLACE Vision Machine controller
SIPLACE Pro
Version 601.03 SP4 Version 303.4.4 Version 601.03 SP4 Version 3.2
Caution:
The functional statuses of the station computer, vision and machine controller software must
be compatible.
8 of 89
Installation Manual, Station Software Version 601.03 SP4 Edition 05/2007
Embedded software
Machine type
Subsystem BIOS / application Version File name
X2 X3 X4
BIOS 02.00 A0300200.bhx
Application 1 02.0D A031020D.bhx
Application 2 / X 02.47 A0320247.bhx
Main axes
(A363)
Application 2 / Y 02.47 A0320247.bhx
X X X
BIOS 02.00 A0300200.bhx
Application 1 02.0D A031020D.bhx
Application 2 / star 02.47 A0320247.bhx
Application 2 / Z 02.47 A0320247.bhx
Revolver head axes
(A363)
Application 2 / DP 02.47 A0320247.bhx
X X X
BIOS 02.00 A0300200.bhx
Application 1 02.0D A031020D.bhx
Application 2 / Z 02.47 A0320247.bhx
Twin Head axes
(A363)
Application 2 / DP 02.47 A0320247.bhx
X X
BIOS 02.00 A0300200.bhx
Application 1 02.0D A031020D.bhx
Application 2 / star 02.47 A0320247.bhx
Application 2 / Z 02.47 A0320247.bhx
BIOS / DP
01.04
J0300104.hex
J0400104.hex
C&P20 head axes
(A363)
Application 1 / DP
01.18
J0310118.hex
J0400118.hex
X X X
BIOS 03.3F A040033F.bhx
Application 1 01.0E A041010E.bhx
Application 2 / X 04.6E A042046E.bhx
Main axes
(A364)
Application 2 / Y 04.6E A042046E.bhx
X X X
BIOS 03.3F A040033F.bhx
Application 1 01.0E A041010E.bhx
Application 2 / star 04.6E A042046E.bhx
Application 2 / Z 04.6E A042046E.bhx
Revolver head axes
(A364)
Application 2 / DP 04.6E A042046E.bhx
X X X
9 of 89
Installation Manual, Station Software Version 601.03 SP4 Edition 05/2007
Machine type
Subsystem BIOS / application Version File name
X2 X3 X4
BIOS 03.3F A040033F.bhx
Application 1 01.0E A041010E.bhx
Application 2 / Z 04.6E A042046E.bhx
Twin Head axes
(A364)
Application 2 / DP 04.6E A042046E.bhx
X X
BIOS 03.3F A040033F.bhx
Application 1 01.0E A041010E.bhx
Application 2 / star 04.6E A042046E.bhx
Application 2 / Z 04.6E A042046E.bhx
BIOS / DP
01.04
J0300104.hex
J0400104.hex
C&P20 head axes
(A364)
Application 1 / DP
01.18
J0310118.hex
J0410118.hex
X X X
BIOS 1.04 K0400104.hex
RV head (modular)
Application 1
6.04
K0410604.hex
X X X
BIOS 3.CB K06003CB.hex
RV head (16 bit x serial)
Application 1
2.09
K0610209.hex
X X X
BIOS 03.CB I01003CB.bhx
Twin Head head functions
(2 Prozessor)
Application 1 02.07 I0110207.bhx
X X
BIOS 03.CB I03003CB.bhx
Twin Head head functions
(1 Prozessor)
Application 1 02.07 I0310207.bhx
X X
BIOS
03.CB H01003CB.bhx
C&P20 head
Application 1
01.51 H0110151.bhx
X X X
BIOS
01.01
B0200101.hex
Component table
(CAN, 1MB)
Application 1
01.0B
B021010B.hex
X X X
BIOS
02.01
02.00
B0400201.bhx
B0500200.bhx
Component table (X series)
Application 1
04.0E B051040E.bhx
X X X
BIOS
01.00
01.01
G0200100.hex
G0300101.hex
Tape cutter (CAN 1MB)
Application 1
01.00
01.03
G0210100.hex
G0310103.hex
X X X
