4 1OM-1610 091 1-001 First of all, please read the paragraphs in "Caution and W arning" and "Safety Precautions" (rst part of this manual). Identifying Icons in Manual Notice This icon shows an impor…
3
1OM-1610
Volume 6 : Component Library
This includes an explanation of component library data and how to create it.
Volume 7 : Multi-Layer Tray Feeder
This section describes the multi-layer tray feeder and operation procedure.
Volume 8 : Recycle Conveyor
This section describes the recycle conveyor and operation procedure.
Volume 9 : Component Library Teaching Function
This section describes the component library data automatic and manual creations.
Volume 10 : Placement Position Teaching Function
This section describes the teaching and collection procedures for the PCB placement
position.
0911-001
4
1OM-1610
0911-001
First of all, please read the paragraphs in "Caution and Warning" and "Safety Precautions"
(rst part of this manual).
Identifying Icons in Manual
Notice
This icon shows an important precautionary or a regulatory item.
Note
This icon shows the descriptions for correct operations of the machine.
Reference
This icon shows the items to be referred to.
Procedure
This icon shows the operation procedures.
Refer to the glossary (Vol. 1) for the denitions of basic words (X/Y Beam Section, Cover
Section, etc.) used in this manual.
5
1OM-1610
Caution and Warning
Limited Warranty
Hitachi represents and warrants the following based on the specications in the instruction
manual as long as this machine is used in accordance with the provided instructions.
(1) Coverage
Should the machine fail or malfunction because of a manufacturing defect in
materials or workmanship, we will repair it free of charge.
(2) Warranty Period
The machine is warranted in normal use for a period of one year (not later than
twelve months) from the date of installation.
(3) Warranty Exclusions
This warranty does not apply in the following cases even within the warranty
period.
(a) Damage caused by failure to provide the specied suitable installation,
operating environment, or maintenance for the machine.
(b) Damage caused by failure to use the specied power source (voltage and
frequency), including abnormal power supply
.
(c)
Damage caused by pipe corrosions and deterioration
due to impurities mixed
into the air supplied by the customer
.
(d)
Damage caused by corrosions in electrical circuits and deterioration of
optical elements due to ambient air mixed with strong corrosive gas.
(e) Damage caused by hardware, software, and auxiliar
ies that are not provided
by us.
(f) Damage caused by failure to handle or maintain the machine properly.
(g) Damage caused by any repair work performed by any party other than the
servicing company approved by us.
(h) Damage caused by failure to move or transport the machine properly after
installation.
(i) Damage caused by unapproved disassembly, modication, or machine
transfer to another place.
(j) Damage caused by a Force Majeure such as, but not limited to, re,
earthquake, storm, ood, lightning, strike, labor dispute, riots, crimes,
terrorism, war, radioactive contamination, toxic substance, or any other
incident beyond our reasonable control.
(k) Damage caused by a computer virus.
0911-001
