5OM-1610 091 1-001 2-A Chapter 2 Sensor and Load Layout This chapter indicates where the sensors and loads are located in each section. As this contains highly sophisticated contents, it should carefully be referred to.
5OM-1610
1-20
Pneumatic and Mounting Diagrams
0911-001-
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
φ
4 1
2 Solenoid Valve 1
3 Speed Controller 2
4 Cylinder 1
5 Cylinder 1
Multi Function Nozzle Stocker (Mounting Diagram)
4
2
5
