4OM-1751 1-73 Note The transfer unit type (KYB type or KYX type) for each item can be checked on the screen below . Check here F4A71 Block Name Product Name Part No. Part Name Q'ty Recommended # of years Note(a) Rem…
4OM-1751
1-721903-005
7.2 List of Servicing Parts
7.2 List of Servicing Parts
The following list shows the components requiring maintenance in several years. Use the list as a
reference.
Regarding the maintenance for the following components, consult with our service personnel as
high skill is required for the maintenance.
Block Name Product Name Part No. Part Name Q'ty
Recommended
# of years
Note(a)
Remarks
Head Section
Solenoid Valve KYB-M701U-00 ACCESSORY_SV 30 2
Nozzle Shaft
-Maintenance Assembly
KYA-M860C-00 ASSY_SHAFT_NOZ 30 4
For Nozzle
Shaft Setup
Note (b)
O-Ring for Seal Holder
KYB-M704F-00
KYB-M7028-00
SEAL
SEAL
30
90
3
(SO-008-13)
(SO-010-12)
Packing for Nozzle KYB-M704E-00 SEAL 60 3
DYR-2.5
Custom
O-Ring for Filter KYB-M702B-00 SEAL 60 3 SO-009-5A
Slip Ring KYB-M7027-00 SLIP RING 2 2
Light Projecting Unit KYB-M700T-00 LIGHTING UNIT 2 6
Light Receiving Unit KYB-M7016-00 ASSY SVC UNIT 2 6
Coupling for NL KYX-M702C-000
COUPLING
2 -
3-piece set
replacement
Plate for NL KYX-M702C-200
PL ATE
2 -
Bolt for NL motor 90112-2AJ012
BOLT HEX.SOCKET
HEAD
4 -
NL Motor KYB-M701H-00 MOTOR_AC-SERVO 2 2
Main Section
Touch Panel (Both
Sides)
KYB-M651V-00 DISPLAY 2 4
Vacuum Pump KYB-M8518-000 VACUUM_PUMP 1 2
Side View Image
Processing PCB
KYB-M6535-00 PCB-MOUNT 1 6
Component Recognition
Scope
KYB-M731P-00 STD. CAMERA 2 6
Beam Section
X-Axis Motor Servo
Amplifier
KYB-M652Y-00 UNIT-DRIVER 2 3
BeamSection
X-Axis Motor Servo
Amplifier
KYB-M652Y-00 UNIT-DRIVER 2 3
CutterSection Cutter Block ASSY KYB-M3T04-00
ASSY_CUTTER_
BLOCK
2 2
Cart UC26_
Feeder Cart
IO Board KYB-M371H-00 PCB-MOUNT 2 6
Under the Table UC18_Intensive Board KYA-M8601-00 PCB_MOUNT 2 6
Multi Function
Head
VALVE KYB-M711C-00 VALVE 2 5
Cover Protective Tape KYB-M8607-00 ULTRA _TAPE 1 -
Note
4OM-1751
1-73
Note
The transfer unit type (KYB type or KYX type) for each item can be
checked on the screen below.
Check here
F4A71
Block
Name
Product Name Part No. Part Name Q'ty
Recommended #
of years
Note(a)
Remarks
Transfer
Section
(KYB Type)
Positioning Unit Transfer
Pulley
KYB-M91CV-00 PULLEY_TIMING 4 5
Positioning Unit Transfer Flat
Pulley
KYB-M91B8-00 PULLEY FLAT 2 5
Positioning Unit Transfer Belt KYB-M919E-00 BELT_TIMING 2 3
Input Machine Transfer Belt KYB-M91B0-00 BELT_TIMING 2 3
Output Machine Transfer Belt KYB-M91B6-00 BELT_TIMING 2 3
Stopper Cylinder Assembly KYB-M916H-00 ASSY-STOPPER-L 2 4
Input/Output Machine Flat
Pulley
KYB-M91BM-00 PUULEY_FLAT 5 5
Input Machine Pulley KYB-M91BN-00 PULLEY_FLAT 1 5
Input/Output Machine Pulley KYB-M91AL-00 PULLEY_TIMING 8 5
UB95 High-Speed I/O Board KYB-M91AK-00 PCB-MOUNT 1 6
Transfer
Section
(KYX Type)
Positioning Unit Transfer
Pulley
KYB-M91CV-00 PULLEY_TIMING 4 5
Positioning Unit Transfer Flat
Pulley
KYB-M91B8-00 PULLEY FLAT 2 5
Positioning Unit Transfer Belt KYB-M919E-00 BELT_TIMING 2 3
Input Machine Transfer Belt KYB-M91B0-00 BELT_TIMING 2 3
Output Machine Transfer Belt KYB-M91B6-00 BELT_TIMING 2 3
Stopper Cylinder Assembly KYB-M916H-00 ASSY-STOPPER-L 2 4
Input/Output Machine Flat
Pulley
KYY-M914U-A0 PUULEY_FLAT 8 5
Input/Output Machine Pulley KYB-M91AL-00 PULLEY_TIMING 8 5
UB95 High-Speed I/O Board KYB-M91AK-00 PCB-MOUNT 1 6
T4A19
Note
(a) The recommended year of pieces is the value for reference only.
(b) Do not reuse any bolt removed during maintenance.
1903-005
7.2 List of Servicing Parts
4OM-1751
1304-001 2-A
Chapter 2
Troubleshooting
In this chapter the outlines for each trouble shooting are described.
1. Descriptions for Trouble Shooting
2. Management Information
