Error ID Error Name, Description, Cause, and Remedy
511220 Transfer Section's Preparation Error
Upward movement on PCB Stopper(REV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511221 Transfer Section's Preparation Error
Downward movement on PCB Stopper(REV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511222 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(AREV) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511223 Transfer Section's Preparation Error
Upward movement on PCB Stopper(AREV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511224 Transfer Section's Preparation Error
Downward movement on PCB Stopper(AREV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511225 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(BREV) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511226 Transfer Section's Preparation Error
Upward movement on PCB Stopper(BREV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511227 Transfer Section's Preparation Error
Downward movement on PCB Stopper(BREV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511301 Added squeeze error
Added squeeze is not completed.
Open the safety cover and check the placed components. Then, please remove
or revise them.
511401 Automatic correction of missed standard mark
Error in automatic correction of missed standard mark.
Please redo oset teaching of PCB mark position.
511402 Automatic correction of missed standard mark
Timeout of automatic correction of missed standard mark.
Please redo oset teaching of PCB mark position.
511403 Automatic correction of missed standard mark
Error in recognizing standard mark.
Please redo oset teaching of PCB mark position.
T4C14
3.12 Automatic Operation Error
4OM-1751
3-1341701-005
3.13 Auto Teaching
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
600101 P.C.B. recog camera & beam oset teach.
-----
-----
600102 P.C.B. recog camera & beam oset teach.
Error of Recognition Command response.
-----
600103 P.C.B. recog camera & beam oset teach.
Error of coordinates calculation.
-----
600104 P.C.B. recog camera & beam oset teach.
Error of Data set for XY Beam.
-----
600105 P.C.B. recog camera & beam oset teach.
Error of moving for XY Beam.
-----
600106 P.C.B. recog camera & beam oset teach.
Time-out in XY Beam
-----
600107 P.C.B. recog camera & beam oset teach.
Time-out of communication with recognition.
-----
600108 P.C.B. recog camera & beam oset teach.
Recognition failure of checker mark on parts recognition camera.
-----
600109 P.C.B. recog camera & beam oset teach.
Recognition failure of checker on reference pin.
-----
60010a P.C.B. recog camera & beam oset teach.
Recognition failure of checker mark on glass jig.
-----
600201 Comp. Recog. Camera oset teach.
Could not recognize the glass Jig.
Please conrm that Glass Jig is set on Glass Jig place.(Check it because there is
a possibility that nozzle is not on head, or vacuum is not "ON".)
600202 Comp. Recog. Camera oset teach.
The result of Teaching is out of permission values.
Please conrm whether Glass Jig is picked-up correctly or not. Please adjust it
with Teach Plate Oset if not.
600203 Comp. Recog. Camera oset teach.
Error of Recognition command response.
-----
600204 Comp. Recog. Camera oset teach.
Error of coordinates calculation.
-----
4OM-1751
3-1351701-005
Error ID Error Name, Description, Cause, and Remedy
600205 Comp. Recog. Camera oset teach.
Error when Jig pickup started
-----
600206 Comp. Recog. Camera oset teach.
Error in the movement of Jig pickup
-----
600207 Comp. Recog. Camera oset teach.
Error when Jig began to be stored
-----
600208 Comp. Recog. Camera oset teach.
Error in the movement of Jig stored
-----
600209 Comp. Recog. Camera oset teach.
Error when HL-axis began to drop.
-----
60020a Comp. Recog. Camera oset teach.
Error when HL-axis began to rise.
-----
60020b Comp. Recog. Camera oset teach.
Error of Data set for XY Beam.
-----
60020c Comp. Recog. Camera oset teach.
Error of moving for XY Beam.
-----
60020d Comp. Recog. Camera oset teach.
Time-out of moving for XY Beam.
-----
60020e Comp. Recog. Camera oset teach.
Time-out of communication with recognition.
-----
600301 Head Rotate Theta Axis oset
Could not recognize Nozzle
Please conrm that Nozzle is placed and exact Nozzle arrangement data is set.
600302 Head Rotate Theta Axis oset
Error of Recognition Command response.
-----
600303 Head Rotate Theta Axis oset
Could not recognize the section of nozzle shaft
-----
600304 Head Rotate Theta Axis oset
Error of coordinates calculation.
-----
600305 Head Rotate Theta Axis oset
Error when DD-axis began to rotate.
-----
3.13 Auto Teaching
4OM-1751
3-1361701-005
