Error ID Error Name, Description, Cause, and Remedy
600205 Comp. Recog. Camera oset teach.
Error when Jig pickup started
-----
600206 Comp. Recog. Camera oset teach.
Error in the movement of Jig pickup
-----
600207 Comp. Recog. Camera oset teach.
Error when Jig began to be stored
-----
600208 Comp. Recog. Camera oset teach.
Error in the movement of Jig stored
-----
600209 Comp. Recog. Camera oset teach.
Error when HL-axis began to drop.
-----
60020a Comp. Recog. Camera oset teach.
Error when HL-axis began to rise.
-----
60020b Comp. Recog. Camera oset teach.
Error of Data set for XY Beam.
-----
60020c Comp. Recog. Camera oset teach.
Error of moving for XY Beam.
-----
60020d Comp. Recog. Camera oset teach.
Time-out of moving for XY Beam.
-----
60020e Comp. Recog. Camera oset teach.
Time-out of communication with recognition.
-----
600301 Head Rotate Theta Axis oset
Could not recognize Nozzle
Please conrm that Nozzle is placed and exact Nozzle arrangement data is set.
600302 Head Rotate Theta Axis oset
Error of Recognition Command response.
-----
600303 Head Rotate Theta Axis oset
Could not recognize the section of nozzle shaft
-----
600304 Head Rotate Theta Axis oset
Error of coordinates calculation.
-----
600305 Head Rotate Theta Axis oset
Error when DD-axis began to rotate.
-----
3.13 Auto Teaching
4OM-1751
3-1361701-005
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
600306 Head Rotate Theta Axis oset
Error during rotation of DD-axis
-----
600307 Head Rotate Theta Axis oset
Error when HL-axis and NL-axis began zeroing
-----
600308 Head Rotate Theta Axis oset
Error while HL-axis and NL-axis on zeroing movement
-----
600309 Head Rotate Theta Axis oset
Error of Data set for XY Beam.
-----
60030a Head Rotate Theta Axis oset
Error of moving for XY Beam.
-----
60030b Head Rotate Theta Axis oset
Time-out in XY Beam movement
-----
60030c Head Rotate Theta Axis oset
Time-out of communication with recognition.
-----
60030d Head Rotate Theta Axis oset
Error when L-axis began zeroing
-----
60030e Head Rotate Theta Axis oset
Error of L-axis on zeroing
-----
60030f Head Rotate Theta Axis oset
Error when L-axis began to drop
-----
600310 Head Rotate Theta Axis oset
Error in L-axis dropped
-----
600311 Head Rotate Theta Axis oset
Time-out of the movement of L-axis, Z-axis
-----
600312 Head Rotate Theta Axis oset
Error when Z-axis began to move
-----
600313 Head Rotate Theta Axis oset
Error while Z-axis is moving
-----
600314 Head Rotate Theta Axis oset
-----
-----
4OM-1751
3-1371701-005
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
600401 Head Rotate center oset teach
Can not recognize Glass Jig
Please conrm that Glass Jig is set on Glass Jig place.(Check it because there is
a possibility that nozzle is not on head, or vacuum is not "ON".)
600402 Head Rotate center oset teach
Error of Recognition Command response.
-----
600403 Head Rotate center oset teach
Error of coordinates calculation.
-----
600404 Head Rotate center oset teach
Error when Jig pickup began
-----
600405 Head Rotate center oset teach
Error in the movement of Jig pickup
-----
600406 Head Rotate center oset teach
Error when Jig store began
-----
600407 Head Rotate center oset teach
Error in the movement of Jig store
-----
600408 Head Rotate center oset teach
Error when HL-axis and NL-axis began zeroing.
-----
600409 Head Rotate center oset teach
Error while HL-axis and NL-axis are on zeroing
-----
60040a Head Rotate center oset teach
Error when DD-axis began to rotate
-----
60040b Head Rotate center oset teach
Error while DD-axis is rotating
-----
60040c Head Rotate center oset teach
Error of Data set for XY Beam.
-----
60040d Head Rotate center oset teach
Error of moving for XY Beam.
-----
60040e Head Rotate center oset teach
Time-out in XY Beam
-----
60040f Head Rotate center oset teach
Time-out of communication with recognition
-----
4OM-1751
3-1381701-005
