7.ヘッド(シリンジ)(BTRG)
7.Head(Syringe)(BTRG)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
76 BTRG0011 1 STAND ｽﾀﾝﾄﾞ AL
77 JRG0391 1 KEY ｷｰ FE
78 NRG0082 1 HOLDER, STOPPER ﾎﾙﾀﾞ ｽﾄｯﾊﾟ AL
79 NRG0381 3 PLATE ﾌﾟﾚｰﾄ FE
80 NRG0400 3 PLATE, RETAINING ﾌﾟﾚｰﾄ 押え FE
81 NRG0390 3 STOPPER ｽﾄｯﾊﾟ OT
82 NRG0370 3 STOPPER ｽﾄｯﾊﾟ FE
83 BTRG0351 1 BKT, SENSOR BKT ｾﾝｻ FE
84 BTRG0361 1 BKT, SENSOR BKT ｾﾝｻ FE
85 BTRG0371 1 BKT, SENSOR BKT ｾﾝｻ FE
86 S3128A 3 SW, PHOTOELECTRIC SW 光電 EZ-18T OT
87 JRG0800 1 BKT, SENSOR BKT ｾﾝｻ OT
88 JRG0811 1 HOLDER ﾎﾙﾀﾞ PL
89 H5269A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2.6X5L FE
90 H5273A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X5L FE
91 H5274A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X6L FE
92 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L FE
93 H5279A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X20L FE
94 K5255T SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X6L FE
95 K5256A SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X8L FE
97 K5202A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M3X3L FE
98 N4018A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X3L FE
99 N4019T SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X5L FE
100 N4021A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X6L FE
101 N4012A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X8L FE
102 H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L FE
103 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
104 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L FE
105 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L FE
106 H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L FE
107 H5292A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X20L FE
108 H5169A BOLT, HEX ﾎﾞﾙﾄ 六角 M4X10L FE
109 N4027A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X5L FE
110 N1085A NUT, HEX ﾅｯﾄ 六角 M6P=1.0 FE
111 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
112 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
GL-541E PARTS LIST
7 - 5
7.ヘッド(シリンジ)(BTRG)
7.Head(Syringe)(BTRG)
7.ヘッド(シリンジ)(BTRG)
7.Head(Syringe)(BTRG)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
113 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
114 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
115 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
116 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
117 W1010A WASHER, CONICAL ﾜｯｼｬ 皿 M-3-L FE
119 N1076A NUT, HEX ﾅｯﾄ 六角 M3P=0.5 FE
120 H3012A 1 FIBER UNIT ﾌｧｲﾊﾞ ﾕﾆｯﾄ FEF-PMDIN-LP25 OT
121 H5276A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X10L FE
122 HRG0602 3 NUT ﾅｯﾄ AL
123 A5018H 1 OIL SEAL ｵｲﾙｼｰﾙ AC0526A0 OT
124 H4520K 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 384-3M-6 OT
125 BTRG0810 1 BKT BKT FE
126 BTRG0820 1 BKT BKT FE
127 K5255H SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X5L FE
129 ABTRG1152 3 JOINT, ROTARY ｼﾞｮｲﾝﾄ ﾛｰﾀﾘ OT
130 BTRG0850 3 CAP ｷｬｯﾌﾟ AL
131 BTRG0860 3 PIPE ﾊﾟｲﾌﾟ FE
132 ABTRG1100 3 PIPE, PIPING ﾊﾟｲﾌﾟ 配管 OT
133 ABTRG0892 3 SYRINGE, SET ｼﾘﾝｼﾞ ｾｯﾄ 半透明ｼﾘﾝｼﾞ OT
134 BTRG0751 3 SYRINGE ｼﾘﾝｼﾞ PL
135 BTRG0870 3 CAP ｷｬｯﾌﾟ PL
136 BTRG0880 3 CAP ｷｬｯﾌﾟ PL
137 K5047Y 3 CONNECTOR ｺﾈｸﾀ POC8-01AL-W OT
139 JRG0710 3 CAP ｷｬｯﾌﾟ OT
140 JRG0720 3 CAP ｷｬｯﾌﾟ OT
142 ABTRG1120 3 FLOAT, SET ﾌﾛｰﾄ ｾｯﾄ OT
143 BTRG0900 3 FLOAT, SEAL ﾌﾛｰﾄ ｼｰﾙ OT
144 BTRG0910 3 FLOAT ﾌﾛｰﾄ OT
145 ABTRG0971 3 SYRINGE, SET ｼﾘﾝｼﾞ ｾｯﾄ 褐色ｼﾘﾝｼﾞ(UV)(ｵﾌﾟｼｮﾝ) OT
146 BTRG0920 3 SYRINGE ｼﾘﾝｼﾞ (ｵﾌﾟｼｮﾝ) OT
147 K5047H 3 CONNECTOR ｺﾈｸﾀ POC8-01AL ･ OT
GL-541E PARTS LIST
7 - 6
7.ヘッド(シリンジ)(BTRG)
7.Head(Syringe)(BTRG)
GL-541E PARTS LIST
8.ピン基準ユニット(オプション)(BTPQ)
8.Reference pin unit(Option)(BTPQ)
8 - 1
8.ピン基準ユニット(オプション)(BTPQ)
8.Reference pin unit(Option)(BTPQ)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
x4.8
20
15
41
13
19
8
7
38
28
30
25
18
23
29
38
6
4
14
17
16
33
24
20
15
41
13
19
9
7
28
38
30
23
25
18
29
38
5
3
14
17
16
33
2
27
37
21
11
10
42
39
33
42
39
32
31
38
22
12
10
32
39
42
33
39
42
35
40
43
26
46
34
33
39
1
36
40
35
40
43
26
46
34
33
39
1
36
40
A
B
A
B
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
