GL-541E-09 PART LIST - 第41页
GL-541E P ARTS LIST 8 . ピン基準ユニット( オプション) ( B T P Q ) 8 . R e f e r e n c e p i n u n i t ( O p t i o n ) ( B T P Q ) 8 - 1 8 . ピン基準ユニット( オプション) ( B T P Q ) 8 . R e f e r e n c e p i n u n i t ( O p t i o n ) ( B T P Q ) …
7.ヘッド(シリンジ)(BTRG)
7.Head(Syringe)(BTRG)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
113 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
114 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
115 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
116 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
117 W1010A WASHER, CONICAL ﾜｯｼｬ 皿 M-3-L FE
119 N1076A NUT, HEX ﾅｯﾄ 六角 M3P=0.5 FE
120 H3012A 1 FIBER UNIT ﾌｧｲﾊﾞ ﾕﾆｯﾄ FEF-PMDIN-LP25 OT
121 H5276A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X10L FE
122 HRG0602 3 NUT ﾅｯﾄ AL
123 A5018H 1 OIL SEAL ｵｲﾙｼｰﾙ AC0526A0 OT
124 H4520K 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 384-3M-6 OT
125 BTRG0810 1 BKT BKT FE
126 BTRG0820 1 BKT BKT FE
127 K5255H SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X5L FE
129 ABTRG1152 3 JOINT, ROTARY ｼﾞｮｲﾝﾄ ﾛｰﾀﾘ OT
130 BTRG0850 3 CAP ｷｬｯﾌﾟ AL
131 BTRG0860 3 PIPE ﾊﾟｲﾌﾟ FE
132 ABTRG1100 3 PIPE, PIPING ﾊﾟｲﾌﾟ 配管 OT
133 ABTRG0892 3 SYRINGE, SET ｼﾘﾝｼﾞ ｾｯﾄ 半透明ｼﾘﾝｼﾞ OT
134 BTRG0751 3 SYRINGE ｼﾘﾝｼﾞ PL
135 BTRG0870 3 CAP ｷｬｯﾌﾟ PL
136 BTRG0880 3 CAP ｷｬｯﾌﾟ PL
137 K5047Y 3 CONNECTOR ｺﾈｸﾀ POC8-01AL-W OT
139 JRG0710 3 CAP ｷｬｯﾌﾟ OT
140 JRG0720 3 CAP ｷｬｯﾌﾟ OT
142 ABTRG1120 3 FLOAT, SET ﾌﾛｰﾄ ｾｯﾄ OT
143 BTRG0900 3 FLOAT, SEAL ﾌﾛｰﾄ ｼｰﾙ OT
144 BTRG0910 3 FLOAT ﾌﾛｰﾄ OT
145 ABTRG0971 3 SYRINGE, SET ｼﾘﾝｼﾞ ｾｯﾄ 褐色ｼﾘﾝｼﾞ(UV)(ｵﾌﾟｼｮﾝ) OT
146 BTRG0920 3 SYRINGE ｼﾘﾝｼﾞ (ｵﾌﾟｼｮﾝ) OT
147 K5047H 3 CONNECTOR ｺﾈｸﾀ POC8-01AL ･ OT
GL-541E PARTS LIST
7 - 6
7.ヘッド(シリンジ)(BTRG)
7.Head(Syringe)(BTRG)
GL-541E PARTS LIST
8.ピン基準ユニット(オプション)(BTPQ)
8.Reference pin unit(Option)(BTPQ)
8 - 1
8.ピン基準ユニット(オプション)(BTPQ)
8.Reference pin unit(Option)(BTPQ)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
x4.8
20
15
41
13
19
8
7
38
28
30
25
18
23
29
38
6
4
14
17
16
33
24
20
15
41
13
19
9
7
28
38
30
23
25
18
29
38
5
3
14
17
16
33
2
27
37
21
11
10
42
39
33
42
39
32
31
38
22
12
10
32
39
42
33
39
42
35
40
43
26
46
34
33
39
1
36
40
35
40
43
26
46
34
33
39
1
36
40
A
B
A
B
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
8.ピン基準ユニット(オプション)(BYPQ)
8.Reference pin unit(Option)(BTPQ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & ode No. QTY Description Rating Remarks
Materials
1 BTPQ0020 2 BKT BKT FE
2 BTPQ0030 1 PLATE, REFERENCE ﾌﾟﾚｰﾄ 基準 FE
3 PPQ0031 1 SLIDER ｽﾗｲﾀﾞ FE
4 PPQ0041 1 SLIDER ｽﾗｲﾀﾞ FE
5 PPQ0061 1 GUIDE ｶﾞｲﾄﾞ FE
6 PPQ0071 1 GUIDE ｶﾞｲﾄﾞ FE
7 PPQ0081 2 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ FE
8 PPQ0111 1 PIN, DIAMOND-SHAPED (φ3) ﾋﾟﾝ ﾀﾞｲﾔ (φ3） 注2 Note.2 FE
9 PPQ0120 1 PIN, REFERENCE (φ3) ﾋﾟﾝ 基準 (φ3) 注1 Note.1 FE
10 PPQ0142 2 PLATE ﾌﾟﾚｰﾄ FE
11 PPQ0150 1 PLATE, SW ﾌﾟﾚｰﾄ SW FE
12 PPQ0160 1 BKT, SW BKT SW FE
13 PPQ0190 2 SPRING ｽﾌﾟﾘﾝｸﾞ FE
14 PPQ0200 2 CLAMPER ｸﾗﾝﾊﾟ FE
15 PPQ0230 2 COLLAR ｶﾗｰ FE
16 NPB0130 2 PIN ﾋﾟﾝ FE
17 NPB0250 2 SPRING ｽﾌﾟﾘﾝｸﾞ FE
18 K5325A 4 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ M4R-M5-0 OT
19 S1022A 8 CIR-CLIP ｻｰｸﾘｯﾌﾟ ST-EW-4 FE
20 H2025A 2 PIN, SNAP ﾋﾟﾝ ｽﾅｯﾌﾟ SSP-5 FE
21 S4032M 1 SENSOR ｾﾝｻ UM-TR50TV1 OT
22 S4032G 1 SENSOR ｾﾝｻ UM-TL50S OT
23 S2127Z 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ JDAS12X35-CS4HB1 FE
24 Y30742 2 CONNECTOR ｺﾈｸﾀ KQ2U04-00 FE
25 K5077A 2 CONNECTOR ｺﾈｸﾀ M-5J FE
26 BTPQ0010 2 PLATE, ADJUSTING ﾌﾟﾚｰﾄ 調整 FE
27 K5175X SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M2X8L FE
28 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L FE
29 H5277A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X12L FE
30 H5284H BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X60L FE
31 K5178T SCREW, C/R RAN 小ﾈｼﾞ 十穴鍋 M3X12L FE
32 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L FE
33 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
34 N4041A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M5X15L FE
35 H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L FE
36 H5327A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X30L FE
37 W1020A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2M/M FE
GL-541E PARTS LIST
8 - 2
8.ピン基準ユニット(オプション)(BTPQ)
8.Reference pin unit(Option)(BTPQ)
